The camera can show a thermal image or a visible image of the
scene, or a mixed blend of both.
a) 100% Thermal only
b) 100% Visible only.
Thermal and Visible image blending
1. Select "visible" icon using HK2, and turn on with centre
toggle button.
2. Use the navigation buttons to blend the thermal and
visible images.
Alignment
1. Press HK1 to toggle to the alignment icon.
2. Use the navigation buttons to align the thermal and visible
images.
Align right
Align left
InfraRed Integrated Systems Limited
Park Circle Tithe Barn Way Swan Valley Northampton NN4 9BG UK
Tel:
+44 (0) 1604 594 200
Fax:
+44 (0) 1604 594 210
Email:
sales@irisys.co.uk
Web site: www.irisys.co.uk
c) 50% Thermal and
d) PiP
50% Visible.
Aligned image
IPU 40325 Jan 2011
IR16DS Quick Start Guide
Screen
Hotkeys
HK1 - HK4
1. Unpack camera
2. Charge battery if required. The charging point is located
behind the hatch on the side. A full charge should last
approximately 5 hours
3. Press On/Off button to switch on Camera.
4. Remove lens cap and a thermal image
of the scene should appear on the screen.
Getting Started
On/Off
button
4 navigation
Buttons &
Centre toggle
button
Laser Button
