TM
NEO ANGLE
Neo Angle Shower System Installation Guide for Basic & Hinged Packages
Congratulations on the purchase of your new shower package. This guide will give you
the instructions on the installation of your new shower.
Medici showers are ideal for an experienced "DIYer". Please read through this entire installation guide
before beginning your installation. If you feel you can not confidently install this shower by yourself hire a
licensed contractor, handyman, or professional installer that can do it for you. Installation time may vary
depending on your experience, complexity of shower, and "Pre-Install Prep Work" which may include:
plumbing and/or drain relocation, bathroom demolition, and squaring up studs and floor.
Watch our Installation and Product Videos on americanbathfactory.com/pages/videos
Prior to demolition, scheduling your installer, or building your shower, double check that you have all the
parts from the factory. Some applications may require a licensed plumber or contractor. Do not use
any product spec sheets to begin installation before receiving product. These spec sheets are for
reference only. Use actual product measurements only. The diagrams throughout this guide illustrate a
42" x 42" shower with a hinged door. Depending on the size of the shower purchased, actual parts may
vary in size and look from the diagrams shown.
Our goal is to help you achieve a quick and successful shower installation.
See the clock in each section for estimated installation time.
Please inspect shipment thoroughly upon receipt and before starting the installation.
Missing or damaged hardware and tiles should be reported within 24 hours of receiving this
shipment. If you need assistance, call 1-800-454-2284 Mon - Fri from 7:15am - 4 pm (PT)
ABF Neo Basic Hinged Install Guide Rev J
Advertisement
Related Manuals for American Bath Factory Medici showers NEO ANGLE
Summary of Contents for American Bath Factory Medici showers NEO ANGLE
- Page 1 NEO ANGLE Neo Angle Shower System Installation Guide for Basic & Hinged Packages Congratulations on the purchase of your new shower package. This guide will give you the instructions on the installation of your new shower. Medici showers are ideal for an experienced "DIYer". Please read through this entire installation guide before beginning your installation.
- Page 2 TIME TIME PRE-INSTALLATION TEAR DOWN PRE-INSTALLATION TEAR DOWN 8-16 HRS 8-16 HRS This shower system is designed to be installed on a level, bare floor. It is necessary for any existing shower to be completely removed. Tear out and remove all old material to expose the 2 x 4 wall studs. Clean up the shower area, removing all dust and old material from the area.
- Page 3 TIME REQUIRED 2 x 4 STUDS ALIGNMENT & POSITIONING ½ to 1 HR Using the pan and wall panels, you will be able to check to make sure your 2 x 4 studs are in the needed position and supported adequately. You will see in extra 2 x 4 studs are added to the door and glass side thresholds for extra (dia.
- Page 4 TIME REQUIRED SETTING PAN ½ HR 1. Now that the drain is installed onto the pan and has dried, dry fit the pan and your drain for alignment. Check to make sure the 2" drain pipe is in the center of the pan drain hole and that the 2"...
- Page 5 TIME REQUIRED SIDE CASINGS 1/2 - 1 HR B - Wall Glass Panel Casing Trim 1. Locate the side casings & caps. (dia. 8) To help with the side casing installation, use a level and draw a plumb line from the inside of the pan threshold up to the top of the shower. Do this on both sides.
- Page 6 TIME REQUIRED WALL PANEL/LINER INSTALLATION 3-4 HR A - Inspecting Wall Panels/Liners Inspecting panels at this point will give you confidence that the wall panels are straight and square from the factory. When installing wall panels, you may need to make adjustments to the panels to accommodate for unevenness of your existing walls.
- Page 7 WALL PANEL/LINER INSTALLATION A - Inspecting Wall Panels/Liners Inspecting panels at this point to make sure wall panels shipped OK from the factory. When installing wall panels, you may need to make adjustments to the panels to accommodate for unevenness of your existing walls or panels. Sistine Stone wall panels are made to be flexible and may have a slight bow.
- Page 8 GLASS DOOR HANDLE & HINGE INSTALLATION Handle Door The door handle (A) will be located on the outside of shower glass. Be careful not to rest the edges of the door on hard surfaces. Tempered glass is very strong and impact resistant but its weakest point is impact on the edges.
- Page 9 D - Install Threshold Hinge Bracket. diagram 20a Next, Install Threshold Hinge Bracket. (dia. 15). Decide what side do you want the door glass panel to open, left or right? Place bracket into notch of pan threshold step and tight to the glass panel.
- Page 10 E - Dry Fit Door/Header (continued) 2. Next, have the other person place the center header section into position. Align the hole in the header center section with the hinge pin and align the glass channels with the glass panels. 3.
- Page 11 inside shower I - Install Door Sweep glass (continued) panel We have provided 2"door stop: door 1. This is located just above the door sweep, push H seal on to bottom of door (Diag. 18) Optional Door Seals Most showers do not need seals on the door and seams of the glass and prefer a diagram 18 h-seal clean no plastic seal frameless glass appearance.
- Page 12 GROUT Your American Bath Factory shower has a non-porous surface, which makes it easy to clean. Decorative lines in the shower wall panels and Sistine Stone floor accents (e.g. 4x4 Diamond) can be grouted if preferred, but it is not necessary.
