Summary of Contents for Flock Audio Patch XT
-
Page 1: Cover
USER MANUAL V.1.0.0... -
Page 2: Table Of Contents
TABLE OF CONTENTS Cover...........................1 Table Of Contents.......................2 Thank you from Flock Audio………………………………………………..……………..3 Introduction to the PATCH XT System..……………………..………………..………….4 Important Safety Notices…………….………………………..………………..………….5 What's in the Box...…….………………………..……………..………………..………….6 Front Panel Identifications……..……………..……………………..……………….…….7 Rear Panel Identifications……….……………..…………..………..……………….…….8 Rear Panel Cable Connections………………………………..………………..………….9 Hardware Chassis Measurements……………………………..………………..………..10 Toggle & Control Center....................11 Routing Examples (Pt.1)……………………………….…………………………………..12... -
Page 3: Thank You From Flock Audio
After 2 years of strenuous work and constant focus, Flock Audio the company I started, created the worlds first and most advanced digitally controlled analog audio routing system with features never before possible in conventional analog audio routing. -
Page 4: Introduction To The Patch Xt System
INTRODUCTION INTRODUCTION TO THE PATCH SYSTEM… The Flock Audio PATCH XT System is a digitally controlled, 100% analog audio patchbay routing system. A combination of Software known as the PATCH APP and a 192 Point Connection (96 Inputs & 96 Outputs) PATCH XT Hardware component allows users to easily route and control analog audio routings without having to resort to the use of manual patch cables. -
Page 5: Important Safety Notices
"O". The lifespan of your PATCH XT will not be affected if you continue use. It’s also recommended to keep the system unplugged if not in choose to sleep the unit instead of shutting it down during regular studio use for long extended periods of time. -
Page 6: What's In The Box
WHAT'S IN THE BOX WHAT'S INCLUDED IN THE BOX PATCH 3U HARDWARE HARDWARE INDEX IEC POWER CABLE USB-A TO USB-B (6FT LOCKING) 6 STEP QUICKSTART GUIDE SETUP QR CODE (110V or 220V) PATCH MANUAL WHATS IN THE BOX... -
Page 7: Front Panel Identifications
FRONT PANEL FRONT INDENTIFICATIONS Front Inputs 1-2 Multi-Purpose LED Indicator Neutrik XLR/TRS Combo Jacks Blue LED Indicator (Activated using Software) (Learn more on Page 33) Front Outputs 1-2 Sleep/Wake Button Toggle On/Off Sleep/Wake Mode Neutrik XLR Male Jacks (Activated using Software) PATCH MANUAL FRONT PANEL INDENTIFICATIONS... -
Page 8: Rear Panel Identifications
PROFESSIONAL +4 LINE LEVEL Inputs & Outputs (1-2) NOTE PATCH XT IS DESIGNED WITH A FIXED PROFESSIONAL LINE LEVEL OF +4 TO WORK IN ACCORDANCE WITH OTHER INDUSTRY IMPORTANT: Always ensure that the Power Channels 1-2 can be routed to the STANDARD OUTBOARD PROCESSING HARDWARE. -
Page 9: Rear Panel Cable Connections
NOTE INPUTS & OUTPUTS ON THE REAR PANEL OF THE REQUIRED CABLES FOR OPERATION PATCH XT SYSTEM ARE SEPARATELY DESIGNATED. YOU CANNOT USE AN OUTPUT AS AN INPUT OR VICE VERSA. PLEASE ENSURE TO AVOID RISK OR DAMAGE TO THE... -
Page 10: Hardware Chassis Measurements
HARDWARE CHASSIS MEASUREMENTS CHASSIS DIMENSIONS 425 mm 16.75 in 323.9 mm 12.75 in 133.4 mm FRONT VIEW 5.25 in 482.6 mm 19 in 25 lbs / 11.3 kg (Weight) 482.6 mm 19 in 323.9 mm 12.75 in 133.4 mm REAR VIEW 5.25 in 425 mm 16.75 in... -
Page 11: Toggle & Control Center
Connections to Front Panel PATCH XT BUTTON & OPTIONS When a PATCH XT unit is connected to the Host CPU, a PATCH XT Button Icon will appear/display. The main purpose of this button is to allow the User Right Click PATCH XT Button to remotely “Sleep/Wake”... -
Page 12: Routing Examples (Pt.1)
ROUTING EXAMPLES HARDWARE + SOFTWARE ROUTING EXAMPLE Standard Microphone Routing Example The PATCH Series models are all a +4 Professional line level design. When connecting microphones directly to the PATCH Series hardware, standard audio engineering practices should be exercised such as the understanding that mixing signal levels may or may not exhibit audio level &/or electronic noise floor artifacts. -
Page 13: Routing Examples (Pt.2)
ROUTING EXAMPLES HARDWARE + SOFTWARE ROUTING EXAMPLE Multing Routing Example The PATCH Series models are all a +4 Professional line level design. When connecting microphones directly to the PATCH Series hardware, standard audio engineering practices should be exercised such as the understanding that mixing signal levels may or may not exhibit audio level &/or electronic noise floor artifacts. -
Page 14: Routing Examples (Pt.3)
ROUTING EXAMPLES HARDWARE + SOFTWARE ROUTING EXAMPLE Mixing/Mastering Routing Example Interface (Output) Interface (Output) Compressor Compressor Saturation & Saturation & Harmonics Harmonics Interface (Input) Interface (Input) PATCH MANUAL ROUTING EXAMPLES... -
Page 15: Front Panel Led Indicator
FRONT PANEL LED INDICATOR RING LED INDICATOR - (Solid Illuminated) Powered On, Active Connection to Host CPU - (Slow Fade In/Out) Powered On, Active Connection, But In Sleep Mode (Flash On/Off Repeatedly Fast) System Error/Fault/Overheated etc. (No Illumination) System Powered Off PATCH MANUAL LED INDICATORS... -
Page 16: Install New Firmware
Follow the process and prompts on the firmware installer application on your computer to complete the firmware installation. Once complete, restart your PATCH XT System and the PATCH APP to complete the installation process. Note: If there are any issues installing the new firmware, please contact Flock Audio Support. -
Page 17: Introducing The Xth Cable Hanger
INTRODUCING THE PATCH XT CABLE HANGER RACK HANGER (X2) This is where the XTH Cable Hanger is mounted to the rear of PATCH XT. CABLE SECUREMENT HOLES Holes have been added in XTH's Crossbars so the user can secure their applicable cables to the crossbars with cable ties. -
Page 18: Assembling The Xth Cable Hanger
ASSEMBLING THE PATCH XT CABLE HANGER PATCH MANUAL ASSEMBLING THE XTH CABLE HANGER... -
Page 19: Troubleshooting
Confirm whether the Multi-Purpose LED is illuminated Solid Blue or Flashing. Close the PATCH APP Software and turn off the PATCH XT Hardware Unit. Wait 30 seconds and turn on the PATCH XT Hardware Unit & Reopen PATCH APP Software. -
Page 20: Software & System Requirements
SOFTWARE & SYSTEM REQUIREMENTS Software Compatibility & System Requirements OSX: 10.12 Sierra or Newer Disk Space: Minimum 512 MB available disk space USB: 1x USB 2.0/3.0 Port (Per PATCH Series System) Required USB bandwidth: 5%-10% Memory(RAM): 4GB Minimum (8GB or more recommended) CPU: Intel Core 2 Duo (Minimum) Intel Core i3 ™... -
Page 21: User Notices & Warranty
Flock Audio PATCH XT &/or Death may occur if you open a Flock Audio PATCH XT System and will S y s t e m p u r c h a s e s o n c e t h e h a r d w a r e i s r e g i s t e r e d a t void any active warranty immediately. -
Page 22: End
. c o m PATENT PENDING © 2022 Flock Audio Inc. All Rights Reserved...
