- Page 1 Paramont Cameras User Manual: PAR 4MP Series...
- Page 2 Notes on Safety This product is intended to be supplied by a Listed Power Unit, marked with 'Limited Power Source', 'LPS' on unit, output rated minimum 12V/2 A or POE 48V/ 350mA or AC24V (depending on models), no more than 2000m altitude of operation and Tma=60 Deg.C.
- Page 3 Disclaimer With regard to the product with internet access, the use of product shall be wholly at your own risks. Our company shall be irresponsible for abnormal operation, privacy leakage or other damages resulting from cyber attack, hacker attack, virus inspection, or other internet security risks;...
- Page 4 Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 5 2012/19/EU (WEEE directive): The Directive on waste electrical and electronic equipment (WEEE Directive). To improve the environmental management of WEEE, the improvement of collection, treatment and recycling of electronics at the end of their life is essential. Therefore, the product marked with this symbol must be disposed of in a responsible manner.
-
Page 6: Table Of Contents
Table of Contents Introduction ........................1 Network Connection ...................... 2 LAN ........................2 2.1.1 Access through IP-Tool ................2 2.1.2 Directly Access through IE ............... 4 WAN ........................5 Live View ........................8 Network Camera Configuration ................. 10 System Configuration ................... 10 4.1.1 Basic Information ................... - Page 7 Network Camera User Manual 4.5.6 802.1x ..................... 43 4.5.7 RTSP ....................... 43 4.5.8 UPNP ...................... 44 4.5.9 Email ...................... 44 4.5.10 FTP ......................45 4.5.11 HTTPS ....................46 4.5.12 QoS ......................47 Security Configuration ..................48 4.6.1 User Configuration ................. 48 4.6.2 Online User .....................
-
Page 8: Introduction
Network Camera User Manual 1 Introduction Main Features Max. resolution : 2592×1520@30fps/25fps ICR auto switch, true day/night 3D DNR, true WDR ROI coding Video exception detection, intrusion detection (human/vehicle classification), line crossing detection (human/vehicle classification), region entrance detection (human/vehicle classification), region exiting detection (human/vehicle classification), light and sound alarm ... -
Page 9: Network Connection
Network Camera User Manual 2 Network Connection Connect IP-Cam via LAN or WAN. Here only take IE browser for example. The details are as follows: 2.1 LAN In LAN, there are two ways to access IP-Cam: 1. access through IP-Tool; 2. directly access through IE browser. - Page 10 Network Camera User Manual For example, the IP address of your computer is 192.168.1.4. So the IP address of the camera shall be changed to 192.168.1.X. After modification, please enter the password of the administrator and click the “Modify” button to modify the setting. ...
-
Page 11: Directly Access Through Ie
Network Camera User Manual The system will pop up the above-mentioned textbox to ask you to change the default password. It is strongly recommended to change the default password for account security. If “Do not show again” is checked, the textbox will not appear next time. 2.1.2 Directly Access through IE The default network settings are as shown below: IP address: 192.168.226.201... -
Page 12: Wan
Network Camera User Manual ② Open the IE browser and enter the default address of IP-CAM and confirm. ③ Follow directions to download and install the Active X control. ④ Enter the default username and password in the login window and then enter to view. 2.2 WAN ... - Page 13 Network Camera User Manual IP Setup ③ Go to the router’s management interface through IE browser to forward the IP address and port of the camera in the “Virtual Server”. Router Setup ④ Open the IE browser and enter its WAN IP and http port to access. (for example, if the http port is changed to 81, please enter “192.198.1.201:81”...
- Page 14 Network Camera User Manual ① Go to ConfigNetworkPort menu to set the port number. ② Go to Config NetworkTCP/IPPPPoE Config menu. Enable PPPoE and then enter the user name and password from your internet service provider. ③ Go to Config NetworkDDNS menu. Before configuring the DDNS, please apply for a domain name first.
-
Page 15: Live View
Network Camera User Manual 3 Live View After logging in, the following window will be shown. The following table is the instructions of the icons on the live view interface. Icon Description Icon Description Focus/Zoom adjustment (only Original size available for the models with motorized lens Fit correct scale SD card recording indicator... - Page 16 Network Camera User Manual Icon Description Icon Description Zoom in Region exiting indicator Zoom out Intrusion indicator Those smart alarm indicators will flash only when the camera supports those functions and the corresponding events are enabled. In full screen mode, double click on the mouse to exit or press the ESC key on the keyboard. Click AZ control button to show AZ control panel.
-
Page 17: Network Camera Configuration
Network Camera User Manual 4 Network Camera Configuration In the Webcam client, choose “Config” to go to the configuration interface. Note: Wherever applicable, click the “Save” button to save the settings. 4.1 System Configuration 4.1.1 Basic Information In the “Basic Information” interface, the system information of the device is listed. 4.1.2 Date and Time Go to ConfigSystemDate and Time. -
Page 18: Local Config
Network Camera User Manual 4.1.3 Local Config Go to ConfigSystemLocal Config to set up the storage path of captured pictures and recorded videos on the local PC. There is also an option to enable or disable the bitrate display in the recorded files. Additionally, the local smart snapshot storage can be enabled or disabled here. - Page 19 Network Camera User Manual Video Quota: Set the capacity proportion of record files on the SD card. Schedule Recording Settings 1. Go to Config System Storage Record to go to the interface as shown below. 2. Set record stream, pre-record time, cycle writing. Pre Record Time: Set the time to record before the actual recording begins.
- Page 20 Network Camera User Manual increments. Green means scheduled. Blank means unscheduled. “Add”: Add the schedule for a special day. Drag the mouse to set the time on the timeline. “Erase”: Delete the schedule. Drag the mouse to erase the time on the timeline. Manual Input: Click it for a specific day to enter specific start and end times.
-
Page 21: Image Configuration
Network Camera User Manual 4.2 Image Configuration Image Configuration includes Display, Video/Audio, OSD, Video Mask and ROI Config. 4.2.1 Display Configuration Go to ImageDisplay interface as shown below. The image’s brightness, contrast, hue and saturation and so on for common, day and night mode can be set up separately. The image effect can be quickly seen by switching the configuration file. - Page 22 Network Camera User Manual smoggy or rainy environment to get clear images. Lens Distortion Correction: When the image appears distortion to some extent, please enable this function and adjust the level according to the actual scene to correct the distortion. Auto Iris: If your camera is auto Iris, please enable it.
-
Page 23: Video / Audio Configuration
Network Camera User Manual Set full time schedule for common, day, night mode and specified time schedule for day and night. Choose “Timing” in the drop-down box of schedule as shown below. Drag “ ” icons to set the time of day and night. Blue means day time and blank means night time. -
Page 24: Osd Configuration
Network Camera User Manual Bitrate: it can be adjusted when the mode is set to CBR. The higher the bitrate, the better the image quality will be. Video Quality: It can be adjusted when the mode is set to VBR. The higher the image quality, the more bitrate will be required. -
Page 25: Video Mask
Network Camera User Manual Set time stamp, device name, OSD content and picture overlap here. After enabling the corresponding display and entering the content, drag them to change their position. Then click the “Save” button to save the settings. Picture Overlap Settings: Check “OSD Content1”, choose “Picture Overlay”... -
Page 26: Roi Configuration
Network Camera User Manual To set up video mask: 1. Enable video mask. 2. Click the “Draw Area” button and then drag the mouse to draw the video mask area. 3. Click the “Save” button to save the settings. 4. Return to the live to verify that the area have been drawn as shown as blocked out in the image. -
Page 27: Lens Control
Network Camera User Manual 1. Check “Enable” and then click the “Draw Area” button. 2. Drag the mouse to set the ROI area. 3. Set the level. 4. Click the “Save” button to save the settings. 4.2.6 Lens Control Within this section, zoom and focus can be controlled. If the image is out of focus after a manual adjustment, one key focus can be used to set the focus automatically. -
Page 28: Alarm Configuration
Network Camera User Manual 4.3 Alarm Configuration 4.3.1 Motion Detection Go to AlarmMotion Detection to set motion detection alarm. -
Page 29: Other Alarms
Network Camera User Manual 1. Check “Enable” check box to activate motion based alarms. If unchecked, the camera will not send out any signals to trigger motion-based recording to the NVR or CMS, even if there is motion in the video. Alarm Out: If selected, this would trigger an external relay output that is connected to the camera on detecting a motion based alarm (This function is only available for the models with the alarm output interface). - Page 30 Network Camera User Manual 2. Click “Enable” and set the alarm holding time. 3. Set alarm trigger options. The setup steps are the same as motion detection. Please refer to motion detection chapter for details. SD Card Error When there are some errors in writing SD card, the corresponding alarms will be triggered. ...
-
Page 31: Alarm In
Network Camera User Manual 2. Click “Enable” and set the alarm holding time. 3. Trigger alarm out. When the IP address of the camera is in conflict with the IP address of other devices, the system will trigger the alarm out. ... - Page 32 Network Camera User Manual 1. Click “Enable” and set the alarm type, alarm holding time and sensor name. 2. Set alarm trigger options. Alarm Out: If selected, this would trigger an external relay output that is connected to the camera when the sensor alarm is triggered (This function is only available for the models with Alarm Out interface).
-
Page 33: Alarm Out
Network Camera User Manual 4.3.4 Alarm Out This function is only available for the models with Alarm Out interface. Go to ConfigAlarmAlarm Out. Alarm Out Mode: Alarm linkage, manual operation, day/night switch linkage and timing are optional. Alarm Linkage: Having selected this mode, select alarm out name, alarm holding time at the “Alarm Holding Time”... -
Page 34: Alarm Server
Network Camera User Manual 4.3.5 Alarm Server Go to AlarmAlarm Server interface as shown below. Set the server address, port, heartbeat and heartbeat interval. When an alarm occurs, the camera will transfer the alarm event to the alarm server. If an alarm server is not needed, there is no need to configure this section. -
Page 35: Light Alarm
Network Camera User Manual ② Select the voice and then set the warning times and volume as needed. Warning times: it ranges from 1 to 50. ③ Click “OK” to save the settings. 4.3.7 Light Alarm Go to Alarm Light Alarm interface as shown below. -
Page 36: Exception
Network Camera User Manual At any time of day or night, please make sure the image of the camera is clear and with adequate and even light, avoiding overexposure or too much darkness on both sides. 4.4.1 Exception This function can detect changes in the surveillance environment affected by the external factors. -
Page 37: Line Crossing
Network Camera User Manual Drag the slider to set the sensitivity value or directly enter the sensitivity value in the textbox. Click “Save” button to save the settings. The sensitivity value of Scene Change Detection: The higher the value is, the more sensitive the system responds to the amplitude of the scene change. - Page 38 Network Camera User Manual 1. Enable line crossing detection and select the snapshot type and the detection target. Save Panoramic Picture: If it is enabled, the detected panoramic pictures will be captured and saved to the SD card when there are targets detected. Save Target Cutout: If it is enabled, the detected target cutout pictures will be captured and saved to the SD card when there are targets detected.
-
Page 39: Intrusion
Network Camera User Manual A<-B: The alarm will be triggered when the intruder/vehicle crosses over the alarm line from B to A. Click the “Draw Area” button and then drag the mouse to draw a line in the image. Click the “Stop Draw”... - Page 40 Network Camera User Manual 1. Enable intrusion detection and select the snapshot type and the detection target. Save Panoramic Picture: If it is enabled, the detected panoramic pictures will be captured and saved to the SD card when there are targets detected. Save Target Cutout: If it is enabled, the detected target cutout pictures will be captured and saved to the SD card when there are targets detected.
-
Page 41: Region Entrance
Network Camera User Manual Set the alarm area number on the right side. Up to 4 alarm areas can be added. Click the “Draw Area” button and then click around the area where you want to set as the alarm area in the image on the left side (the alarm area should be a closed area). Click the “Stop Draw”... - Page 42 Network Camera User Manual 1. Enable region entrance detection and select the snapshot type and the detection target. Save Panoramic Picture: If it is enabled, the detected panoramic pictures will be captured and saved to the SD card when there are targets detected. Save Target Cutout: If it is enabled, the detected target cutout pictures will be captured and saved to the SD card when there are targets detected.
-
Page 43: Region Exiting
Network Camera User Manual Set the alarm area number on the right side. Up to 4 alarm areas can be added. Click the “Draw Area” button and then click around the area where you want to set as the alarm area in the image on the left side (the alarm area should be a closed area). Click the “Stop Draw”... - Page 44 Network Camera User Manual 1. Enable region exiting detection and select the snapshot type and the detection target. Save Panoramic Picture: If it is enabled, the detected panoramic pictures will be captured and saved to the SD card when there are targets detected. Save Target Cutout: If it is enabled, the detected target cutout pictures will be captured and saved to the SD card when there are targets detected.
-
Page 45: Network Configuration
Network Camera User Manual Set the alarm area number on the right side. Up to 4 alarm areas can be added. Click the “Draw Area” button and then click around the area where you want to set as the alarm area in the image on the left side (the alarm area should be a closed area). Click the “Stop Draw”... -
Page 46: Port
Network Camera User Manual Test: Test the effectiveness of the IP address by clicking this button. Use PPPoE-Click the “PPPoE Config” tab to go to the interface as shown below. Enable PPPoE and then enter the user name and password from your ISP. Either method of network connection can be used. -
Page 47: Server Configuration
Network Camera User Manual RTSP Port: The default port is 554. Please change it as necessary. 4.5.3 Server Configuration This function is mainly used for connecting network video management system. 1. Check “Enable”. 2. Check the IP address and port of the transfer media server in the ECMS/NVMS. Then enable the auto report in the ECMS/NVMS when adding a new device. -
Page 48: Snmp
Network Camera User Manual Create domain name. After the domain name is successfully applied for, the domain name will be listed as below. 3. Enter the username, password, domain you apply for in the DDNS configuration interface. 4. Click the “Save” button to save the settings. 4.5.5 SNMP To get camera status, parameters and alarm information and remotely manage the camera, the SNMP function can be used. - Page 49 Network Camera User Manual 2. Check the corresponding version checkbox (Enable SNMPv1, Enable SNMPv2, Enable SNMPv3) according to the version of the SNMP software that will be used. 3. Set the values for “Read SNMP Community”, “Write SNMP Community”, “Trap Address”, “Trap Port”...
-
Page 50: 802.1X
Network Camera User Manual 4.5.6 802.1x If it is enabled, the camera’s data can be protected. When the camera is connected to the network protected by the IEE802.1x, user authentication is needed. To use this function, the camera shall be connected to a switch supporting 802.1x protocol. The switch can be reckoned as an authentication system to identify the device in a local network. -
Page 51: Upnp
Network Camera User Manual “rtsp://IP address: rtsp port/profile1?transportmode=mcast”. Sub stream: The address format is “rtsp://IP address: rtsp port/profile2?transportmode=mcast”. Third stream: The address format is “rtsp://IP address: rtsp port/profile3?transportmode=mcast”. Audio: Having entered the main/sub stream in a VLC player, the video and audio will play automatically. -
Page 52: Ftp
Network Camera User Manual Sender Address: sender’s e-mail address. User name and password: sender’s user name and password. Server Address: The SMTP IP address or host name. Select the secure connection type at the “Secure Connection” pull-down list according to what’s required. -
Page 53: Https
Network Camera User Manual Server Name: The name of the FTP server. Server Address: The IP address or domain name of the FTP. Upload Path: The directory where files will be uploaded to. Port: The port of the FTP server. User Name and Password: The username and password that are used to login to the FTP server. -
Page 54: Qos
Network Camera User Manual * If there is a signed certificate, click “Browse” to select it and then click “Install” to install it. * Click “Create a private certificate” to enter the following creation interface. Click the “Create” button to create a private certificate. Enter the country (only two letters available), domain (camera’s IP address/domain), validity date, password, province/state, region and so on. -
Page 55: Security Configuration
Network Camera User Manual Video/Audio DSCP: The range is from 0 to 63. Alarm DSCP: The range is from 0 to 63. Manager DSCP: The range is from 0 to 63. Generally speaking, the larger the number is, the higher the priority is. 4.6 Security Configuration 4.6.1 User Configuration Go to ConfigSecurityUser interface as shown below. -
Page 56: Online User
Network Camera User Manual live video. Advanced user has the same permissions as an Administrator except for; user, backup settings, factory reset, and upgrading the firmware. 5. Enter the MAC address of the PC in “Bind MAC” textbox. If this option is enabled, only the PC with the specified MAC address can access the camera for that user. -
Page 57: Block And Allow Lists
Network Camera User Manual An administrator user can kick out all the other users (including other administrators). 4.6.3 Block and Allow Lists Go to ConfigSecurityBlock and Allow Lists as shown below. The setup steps are as follows: Check the “Enable address filtering” check box. Select “Block/Allow the following address”, IPv4/IPv6/MAC and then enter IP address or MAC address in the address box and click the “Add”... -
Page 58: Maintenance Configuration
Network Camera User Manual choose one of them or any combination of them when setting the password. Medium Level: 9~15 characters, including at least two of the following categories: numbers, special characters, upper case letters and lower case letters. Strong Level: 9~15 characters. Numbers, special characters, upper case letters and lower case letters must be included. -
Page 59: Upgrade
Network Camera User Manual Click the “Reboot” button to reboot the device. Timed Reboot Setting: If necessary, the camera can be set up to reboot on a time interval. Enable “Time Settings”, set the date and time and then click the “Save” button to save the settings. 4.7.3 Upgrade Go to ConfigMaintenanceUpgrade. -
Page 60: Search
Network Camera User Manual 5 Search 5.1 Image Search Click Search to go to the interface as shown below. Images that are saved on the SD card can be found here. Local Image Search Choose “Picture”—“Local”. Set time: Select date and choose the start and end time. Click to search the images. - Page 61 Network Camera User Manual Click to return to the previous interface. SD Card Image Search Choose “Picture”—“SD Card”. Set time: Select date and choose the start and end time. Choose the alarm events at the bottom of the interface. Click to search the images.
-
Page 62: Video Search
Network Camera User Manual Icon Description Icon Description Close: Select an image and click Close all: Click this button to this button to close the image. close all images. Save: Click this button to select Save all: Click this button to the path for saving the image on select the path for saving all the PC. -
Page 63: Sd Card Video Search
Network Camera User Manual Icon Description Icon Description Play button. After pausing the video, click this button Pause button to continue playing. Stop button Speed down Speed up Watermark display Enable / disable audio; drag the slider to adjust the volume after enabling audio. - Page 64 Network Camera User Manual Select the alarm events at the bottom of the interface. Select mix stream (video and audio stream) or video stream as needed. Double click on a file name in the list to start playback. The time table can be shown in 24H/12H/2H/1H format by clicking the corresponding buttons.
- Page 65 Network Camera User Manual Click “Set up” to set the storage directory of the video files. Click “Open” to play the video. Click “Clear List” to clear the downloading list. Click “Close” to close the downloading window.
-
Page 66: Appendix
Network Camera User Manual Appendix Appendix 1 Troubleshooting How to find the password? A：Reset the device to the default factory settings. Default IP: 192.168.226.201; User name: admin; Password: 123456 Fail to connect devices through IE browser. A: Network is not well connected. Check the connection and make sure it is connected well. B: IP address is not available. - Page 67 Network Camera User Manual No sound can be heard. A：Audio input device is not connected. Please connect and try again. B: Audio function is not enabled at the corresponding channel. Please enable this function.
