VOIP-500 Series Emergency Phone Quick Installation Guide
I. Introduction
This Quick Installation Guide provides instructions for installation of the VOIP-500 Series
Emergency Phone. It is recommended to read this instruction set completely before starting
any installation.
II. Contents
The VOIP-500 Series Emergency Phone, Figure 1, includes:
QTY
1
6
1
Phone 773.539.1100 • Fax 773.539.1241 • info@talkaphone.com • www.talkaphone.com
Talk-A-Phone, Talk-A-Lert, Scream Alert and WEBS are registered trademarks of Talk-A-Phone Co.
Part Number
Description
VOIP-500
VOIP-500 Phone Assembly
42867
10 -24 Tamper Resistant Screws
86392
Ferrite Core
Figure 1. Front view
Copyright 2010 Talk-A-Phone Co. All rights reserved.
Talk-A-Phone Co. • 7530 North Natchez Avenue • Niles, Illinois 60714-3804
All prices and specifications are subject to change without notice.
Page 1 of 6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VOIP-500 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Talkaphone VOIP-500 Series

Summary of Contents for Talkaphone VOIP-500 Series

  • Page 1 VOIP-500 Series Emergency Phone Quick Installation Guide I. Introduction This Quick Installation Guide provides instructions for installation of the VOIP-500 Series Emergency Phone. It is recommended to read this instruction set completely before starting any installation. II. Contents The VOIP-500 Series Emergency Phone, Figure 1, includes:...
  • Page 2 III. Field Wiring Installation 1. Remove and set aside the VOIP-500 Series Emergency Phone Assembly. 2. Remove the back box from the VOIP-500 Series Emergency Phone Assembly by unfastening the six (6), #6-32 nuts and washers. 3. For PCB (Printed Circuit Board) wiring details, refer to Figure 2.
  • Page 3 Talk-A-Phone Co. • 7530 North Natchez Avenue • Niles, Illinois 60714-3804 Page 3 of 6 Phone 773.539.1100 • Fax 773.539.1241 • info@talkaphone.com • www.talkaphone.com All prices and specifications are subject to change without notice. Talk-A-Phone, Talk-A-Lert, Scream Alert and WEBS are registered trademarks of Talk-A-Phone Co.
  • Page 4 Figure 2. VI. Auxiliary Input/Output 1. The VOIP-500 Series Emergency Phone has three (3) Auxiliary Inputs (dry contact, 10mA @ 8VDC) and three (3) Auxiliary Outputs (dry contact, 120mA @ 120VAC/DC). The Auxiliary Output allows the peripheral equipment such as strobe lights, PTZ cameras, door entry systems etc.
  • Page 5 Talk-A-Phone Co. • 7530 North Natchez Avenue • Niles, Illinois 60714-3804 Page 5 of 6 Phone 773.539.1100 • Fax 773.539.1241 • info@talkaphone.com • www.talkaphone.com All prices and specifications are subject to change without notice. Talk-A-Phone, Talk-A-Lert, Scream Alert and WEBS are registered trademarks of Talk-A-Phone Co.
  • Page 6 VOIP-500 Series Quick Installation Guide Figure 6. Installation of VOIP-500K into ETP-SM Install the VOIP-500 Series Emergency Phone into its appropriate mount (e.g. ETP-SM, as shown in Figure 6), with the six (6) tamper resistant faceplate screws provided. A #10 tamper resistant screwdriver (Talk-A-Phone Model No.
