THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE
APPLICABLE INSTALLATION CODE BY A PERSON FAMILIAR WITH
THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE
HAZARDS INVOLVED
CE PRODUIT DOIT ÊTRE INSTALLÉ SELON LE CODE D'INSTALLATION
PERTINENT, PAR UNE PERSONNE QUI CONNAÎT BIEN LES PRODUIT
ET SON FONCTIONNEMENT AINSI QUE LES RISQUES INHÉRENTS
I.
Introduction
This installation guide provides instructions for installation, programming, and operation of Model
AOR-8 or Model AOR-16. For instructions on installation or programming of Talkaphone Area of
Rescue Call Stations, please refer to the manual for the ETP-100, ETP-110, ETP-400, or ETP-500
Series Analog Call Stations.
It is recommended that this instruction set be read completely prior to the start of any installation.
II.
Contents
Please ensure receipt of each of the included AOR-8 / AOR-16 components:
QTY
Part Number
1
AOR-8 or AOR-16
2
1
Optional components (sold separately) include:
QTY
Part Number
1
AOR-TR16
10
III.
Technical Requirements
General:
115-230 VAC, 50-60Hz power source
Maximum impedance between the Talkaphone Analog Call Stations and the AOR-8 or AOR-16 unit
is 25 Ohms. Maximum cable length will vary depending on wire gauge (See Frequently Asked
Questions, p.9).
For Local Mode Only
No external phone line (i.e. POTS/PSTN line) is required.
Page 1 of 10
Copyright 2017 Talk-A-Phone Co. • 7530 North Natchez Avenue • Niles, Illinois 60714 • Phone 773.539.1100 • info@talkaphone.com • www.talkaphone.com.
All prices and specifications are subject to change without notice. Talk-A-Phone, Talkaphone, Scream Alert, WEBS, and WEBS Contact are registered trademarks of Talk-A-
Phone Co. All rights reserved. All other trademarks mentioned in this document or website are the property of their respective owners and does not imply or indicate any
approval, endorsement, sponsorship, or affiliation with such owners unless such approval, endorsement, sponsorship, or affiliation is expressly indicated.
Area of Rescue Command Unit
Model AOR-8 / Model AOR-16
Description
8- or 16-Station Area of Rescue Command Unit
12VDC, 4.5Ah Backup Battery
Strobe/Siren
Description
Trim Ring for Recess Mounting Model AOR-8 or Model
AOR-16
6-32 Screw for Flush Mount Trim Ring Assembly
Installation Guide
Rev. 6/28/2017
