TSUJI ELECTRONICS NCT08-01B User Manual

8ch counter/timer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
　　8CH COUNTER/TIMER
　　　NCT08-01B
　　　USER'S MANUAL
3091 (rev 3) 2014.02.18
APPLICATION OF ELECTRONIC DEVICES
TSUJI ELECTRONICS CO.,LTD
3739 Kandatsu-machi Tsuchiura-city
Ibaraki-Pre 300-0013 Japan
Phone +81-(0)29-832-3031
Fax
+81-(0)29-832-2662
URL http://www.tsujicon.co.jp
E-mail　info2@tsuji-denshi.co.jp

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NCT08-01B and is the answer not in the manual?

Questions and answers

Related Manuals for TSUJI ELECTRONICS NCT08-01B

Summary of Contents for TSUJI ELECTRONICS NCT08-01B

  • Page 1 　　8CH COUNTER/TIMER 　　　NCT08-01B 　　　USER'S MANUAL 3091 (rev 3) 2014.02.18 APPLICATION OF ELECTRONIC DEVICES TSUJI ELECTRONICS CO.,LTD 3739 Kandatsu-machi Tsuchiura-city Ibaraki-Pre 300-0013 Japan Phone +81-(0)29-832-3031 +81-(0)29-832-2662 URL http://www.tsujicon.co.jp E-mail　info2@tsuji-denshi.co.jp...
  • Page 2 ＮＣＴ０８－０１B　Command List（Available ＬＡＮ，ＵＳＢ） The contents written by blue character is available for V1.02 - . See the section 5. Firmware Update regarding firmware update. COMMAND FUNCTION DETAIL ALM？ alarm read read out the cause of overflow CLAL clear all clear timer and 8 channel counters CLPC clear preset counter clear preset counter (CH7)
  • Page 3 (Available for firmware V1.04 or later.) Command for All reply mode ALL_REP? read all reply mode setting Confirm "all reply mode" is active or not. ALL_REP_EN All reply mode enable Reply is "OK" or "NG" even if the command doesn't require a reply. ALL_REP_DS All reply mode disable No reply, if the command doesn't require...
  • Page 4 Synchronous data acquisition common commands STOP Gate synchronous data stop gate synchronous data acquisition acquisition STOP GSTS? Gate synchronous data read out the status of gate synchronous data acquisition Status read acquisition GSDAL? Gate synchronous data read out all gate synchronous data acquisition all data read Reply: 10 digits in dec GSDALH?

  • Page 5: Table Of Contents

    CONTENTS １．Specification ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ １－１．Abstract ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 6 １－２．Appearance ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ １－３．Block diagram ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ ２．Before using ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ ２－１．Select input signal level for count ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ ２－２．Setting LAN communication ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 　２－２－１．Preparation for setting ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 　２－２－２．Change setting of network ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 　２－２－３．Turn back PC set data ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・...
  • Page 6 ４．Counter data acquisition commands ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ ４－１．About count data acquisition commands ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ ４－２．Preparation for data acquisition commands ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ ４－２－１．Clear current data address ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ ４－２－２．Clear current data address and all stored data ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ ４－２－３．Set and read gate synchronous data acquisition current data address ・・・・・・・・・・・・・・・・・・・・・・...

  • Page 7: １．Specification

    It's possible to store counting data which synchronized with ON/OFF of GATE IN signal or inner clock up to 10,000 memory address. (clock can preset ON time and OFF) １－２．Appearance 　 ③ COUNTER/TIMER NCT08-01B TTL IN START COUNT 　① STOP 　②...

  • Page 8: １－３. Block Diagram

    STOP: When upward edge signal is "ON" ("H"), counting action stopped. (INPUT) Normally (not connected) STOP signal is "L". GATE: When GATE signal goes "L", count action stopped during this level. (INPUT) When it goes "H", count action starts again. Normally (not connected) GATE signal is "H".

  • Page 9: ２．Before Using

    ２．Before using ２－1．Select input signal level for count NCT08-01B can select count input signal from TTL or NIM on each channels. Default setting is TTL. If you are going to change input signal settings, remove the four screws that hold the left cover in place and then remove the left cover.

  • Page 10: ２－２－２．Change Setting Of Network

    C:\Windows>ping 192.168.1.55 Pinging 192.168.1.55 with 32 bytes of data: Request timed out. Request timed out. Request timed out. Request timed out. C:\Windows> In this case please retry the connection again after confirming the cable connection. 　２－２－２．Changing setting condition for net-work Once you check connection is correct, enter new IP address and new telnet port NO of NCT08-01.
  • Page 11 IP Address : (192) 192.(168) 168.(001) 1.(55) 50 Set Gateway IP Address (N) N Netmask: Number of Bits for Host Part (0=default) (0) Change telnet config password (N) N Set IP address as above（Above is the sample for setting 192.168.1.50 ) Set Gateway IP address if you need.

  • Page 12: ２－２－３．Turn Back Pc Set Data

    Select 9, then finished setting works Change Setup: 0 Server configuration 1 Channel 1 configuration 3 E-mail settings 5 Expert settings 6 Security 7 Factory defaults 8 Exit without save 9 Save and exit Your choice ? In these setting items, only IP address must be set. Other items may be no change to set. If you enter wrong number by mistake, you'd better to restore above data.

  • Page 13: ２－４．Connect Communication Cables

    ２－４．Connect signal cables 　２－４－１．Connect communication cables Connect the communication cable to USB port or LAN port on rear panel. There is no need to connect both side, but there will be no problem even if connect both side. If connected both side, latest command will be valid to the unit. 　２－４－２．Connect count signal Connect count signal cable to CH0 to CH7 LEMO connector which are on front panel.

  • Page 14: ３．Communication Commands

    ３．Communication commands ３－１．Communication commands Command characters are ASCII data. The delimiter of communication command is CR+LF in transmit and receive case. From firmware V1.04, "all reply modes" have been added to answer for "OK" or "NG", even if the command doesn't require a reply. Please see the section 3-7. ３－２．Read-out commands for counter set and the status of setting 　３－２－１．Stop enable by count value Type of command...

  • Page 15: ３－２－５．Setting And Readout Of Preset Counter

    　３－２－５．Setting and readout of preset counter Type of command ＳＣＰＲdddd・・・・ To set preset value dddd・・・・・ in decimal to preset counter. Unit is Kcts. Maximum value is 4,294,967 Kcts. ＳＣＰＲＦdddd・・・・ To set preset value dddd・・・・・ in decimal to preset counter. Unit is cts. Maximum value is 4,294,967,295 cts.

  • Page 16: ３－４．Read-Out And Clear Commands For Counter And Timer

    ３－４．Read-out and clear commands for counter and timer 　３－４－１．Read-out and clear commands for all counter and timer Type of command ＲＤＡＬ？ To read all counter channels and timer in decimal. Reply 1234567890 2345678901 3456789012 ・・・・・ 0123456789 These data are 10 digit in decimal. The data order is CH0 CH1 CH2 ･･････...

  • Page 17: ３－４－３．Read-Out And Clear Commands For Timer

    ３－６．Inquiry of software version information Type of command ＶＥＲ？ To inquiry about software version information Example 1.00 10-06-25 NCT08-01B Reply is in order, version number, date and type of the unit. (The same firmware is used in CT08-01B.) Type of command ＶＥＲＨ？...

  • Page 18: ３－７．Other Commands

    ３－７．Other commands (a) Type of command ＦＬＧ？０　　ＦＬＧ？１　　ＦＬＧ？２ Each command show the contents of unit. Reply for command "FLG?0" ｂ７： ｂ６： ｂ５： ｂ４： ｂ３： Counter number 3 overflow ｂ２： Counter number 2 overflow ｂ１： Counter number 1 overflow ｂ０： Counter number 0 overflow Reply data "04"...

  • Page 19: All Reply Mode

    (d) All reply mode (available for V1.04 or later) Regarding "all reply mode", NCT08-01B's reply is "OK" if the command has been processed. On the other hand, NCT08-01B's reply is "NG" if the command haven't been processed. Regarding the case of "OK", it shows that the processing has been advanced.

  • Page 20: ４－２．Preparation For Data Acquisition Commands

    (GATE EDGE MODE) This mode is available for hardware version 1～ (HD-VER 1～). 　　Count data is stored on the memory at the falling edge of GATE signal. 　　Counter starts at the first falling edge of GATE signal after STRT command. START(COMM) "H"...

  • Page 21: ４－２－４．Set And Read Gate Synchronous Data Acquisition End Data Address

    Inputting "STOP" command, data acquisition stops immediately. ４－４　Synchronous internal clock data acquisition commands In this mode, data acquisition is synchronized by clock generated by NCT08-01B. It's necessary to preset the value of clock ON time and clock OFF. External gate input signal works gate signal during data acquisition operation.

  • Page 22: ４－４－２　Set And Read Synchronous Timer Off Time

    (Just after turn on power, it's stop condition) Entering this command after preparation of section 4-2-1～3 and 4-3-1～2, NCT08-01B starts synchronous clock signal data acquisition. It stores signal data from current data address to end data address synchronized by clock signal.

  • Page 23: ４－５－３．Read Out All Stored Data（０～Current Data Address

    ４－５－３．Read out all stored data（０～current data address） Type of command ＧＳＤＡＬ？ Read out all stored data from 0 to current data address. Current data address is set the next address to end data address just after data acquisition. ch2　・・・・ timer Reply example: 00123, 00456, 07890, ・・・・・...

  • Page 24: ４－５－５．Amount Of Time For Data Downloading

    ＧＳＣＲＤＨ？uvwｘｘｘｘｙｙｙｙ Read out acquired data from data address of xxxx to yyyy in hexadecimal. ４－５－５．Amount of time for data downloading NCT08-01B uses serial communication (38400BAUD) for LAN interface. The data download speed via LAN is about 3,800 characters (3.8KB) per second.

  • Page 25: ５．Firmware Update

    5．Firmware update For NCT08-01B it's possible to upgrade firmware via communication tools. Here is an overview of operation. It's possible to use USB and LAN communication. You can download software for update and its user's manual from following URL. http://www.tsuji-denshi.co.jp/download_file/lan_rs_file_send.EXE 　...

  • Page 26: ６．Synchronous Drive Of Multi Units

    Similarly, if you use several NCT08-01B,you will acquire 8n channel data with gate signal data acquisition. 7．Regulations and guidelines Regarding NCT08-01B when it receives data read command, it stops count and timer action for 120 ns. This stopping period is essential to get latest data to latch 32 bits count data.

  • Page 27: ８．Interface With External Devices

    ８．Interface with external devices ５Ｖ LEMO TTL IC GATE INPUT LEMO TTL IC START, STOP TTL IC SLIDE SW TTL LEVEL LEMO CH0～CH8 COUNT IN NIM LEVEL RECEIVER NIM LEVEL 27/28...

  • Page 28: ９．Performance And Specifications

    1cts ～ 4,294,967 Kcts or cts Count mode single mode By start trigger or "STRT" command, NCT08-01B counts input pulse once within preset time or count. Count stops immediately by stop trigger or "STOP" command. If you prohibit preset timer stop and count, count operation never stop unless using stop trigger or "STOP"...
