　　8CH COUNTER/TIMER
　　　NCT08-0２
　　　USER'S MANUAL
2766 (rev 3.)
APPLICATION OF ELECTRONIC DEVICES
TSUJI ELECTRONICS CO.,LTD
3739 Kandatsu-machi Tsuchiura-city
Ibaraki-Pre 300-0013 Japan
Phone +81-(0)29-832-3031
Fax
+81-(0)29-832-2662
URL http://www.tsujicon.co.jp
E-mail　info2@tsuji-denshi.co.jp

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NCT08-02 and is the answer not in the manual?

Questions and answers

Related Manuals for TSUJI ELECTRONICS NCT08-02

Summary of Contents for TSUJI ELECTRONICS NCT08-02

  • Page 1 　　8CH COUNTER/TIMER 　　　NCT08-0２ 　　　USER'S MANUAL 2766 (rev 3.) APPLICATION OF ELECTRONIC DEVICES TSUJI ELECTRONICS CO.,LTD 3739 Kandatsu-machi Tsuchiura-city Ibaraki-Pre 300-0013 Japan Phone +81-(0)29-832-3031 +81-(0)29-832-2662 URL http://www.tsujicon.co.jp E-mail　info2@tsuji-denshi.co.jp...
  • Page 2 ＮＣＴ０８－０2　COMMAND TABLE (To: LAN, USB) COMMANDS CONTENTS OF COMMANDS 　　　　DETAILES OF COMMANDS ＡＬＭ？ alarm read inquiry the contents of overflow ＣＬＡＬ clear all clear timer and 8 channel counters ＣＬＰＣ clear preset counter clear preset counter (CH7) ＣＬＴＭ clear timer clear timer ＣＬＣＴｘｘ...

  • Page 3: Table Of Contents

    CONTENTS １．Specifications ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ １-１．Abstract ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ １-２．Appearance ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ １-３．Block diagram ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ ２．Before using ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ ２－１．Select input signal level for count ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ ２－２．Setting LAN communication ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 　２－２－１．Preparation for setting ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 　２－２－２．Changing setting condition for net-work ・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 　２－２－３．Turn back PC set data ・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 　２－２－４．Connecting test ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・...

  • Page 4: １．Specifications

    8×ｎ channels. It's possible to control by LAN or USB communication. The NCT08-02 is made as an upgrade model of NCT08-01. The commands are almost the same of the NCT08-01. *) The preset value is round down to multiple number of eight.

  • Page 5: １-３．Block Diagram

    STOP: When upward edge signal is "ON" ("H"), counting action stopped. (INPUT) Normally (not connected) STOP signal is "L". GATE: When GATE signal goes "L", count action stopped during "L" level. (INPUT) When it goes "H", count action starts again. Normally (not connected) GATE signal is "H".

  • Page 6: ２－２－２．Changing Setting Condition For Net-Work

    In this case please retry the connection again after confirming the cable connection. 　２－２－２．Changing setting condition for net-work Once you check connection is correct, enter new IP address and new telnet port NO of NCT08-02. (If default NO is OK, you don't have to do this operation.) Default IP address is 192.168.1.55, and default port NO is 7777.
  • Page 7 ｔｅｌｎｅｔ　１９２．１６８．１．５５　９９９９ NO 9999 is port set number of NCT08-02. Click OK button and screen changed to telnet mode immediately. ＭＡＣ　ａｄｄｒｅｓｓ　００２０４Ａ８０Ｆ１Ｂ６ ←　It depends on the type of unit. Ｓｏｆｔｗａｒｅ　ｖｅｒｓｉｏｎ　０１．５（０３１００３）ＸＰＴＥ ←　It depends on the type of unit. Ｐｒｅｓｓ　Ｅｎｔｅｒ　ｔｏ　ｇｏ　ｉｎｔｏ　Ｓｅｔｕｐ　Ｍｏｄｅ　 Push Return button in 3sec.

  • Page 8: ２－２－３．Turn Back Pc Set Data

    By installing this software, connecting is done like a COM port connection. Switch on a NCT08-02, connect USB cable, then there will be message box that shows "New hardware device was found". According to PC directions, specify the folders of downloaded driver software.

  • Page 9: ２－４－２．Connect Count Signal

    　２－４－２．Connect count signal Connect count signal cable to CH0 to CH7 LEMO connector which are on front panel. It' s possible to count maximum 8 channel signals. 　２－４－３．Start signal (TTL positive logic) TTL positive logic signal starts counting action. The width of start signal pulse must be more than 100ns. It's possible to check the count start status by LED lamp on front panel.

  • Page 10: ３－２－２．Stop Enable By Timer Value

    　３－２－２．Stop enable by timer value Type of command ENTS Enable to stop count by timer. When timer value reach to preset timer value, count action automatically stopped. 　３－２－３．Disable auto stopping by counter value or timer va Type of command DSAS Disable to stop count by counter (CH7) or timer.

  • Page 11: ３－２－６．Setting And Readout Of Preset Timer

    　３－２－６．Setting and readout of preset timer Type of command ＳＴＰＲdddd・・・・ To set preset value dddd・・・・・ in decimal to timer. Unit is ms. Maximum timer set value is 1,099,511,627 ms. ＳＴＰＲＦdddd・・・・ To set preset value dddd・・・・・ in decimal to timer. Unit is μs. Maximum timer set value is 1,099,511,627,775　μs.

  • Page 12: ３－４－２．Read-Out And Clear Commands For All Counter

    ｏｖｅｒ００００－－ It means no overflow. [0000 0000] ３－６．Inquiry of software version information Type of command ＶＥＲ？ To inquiry about software version information Reply example 1.00 07-01-05 NCT08-02 Reply is in order, version number, date and type of the unit. 11/15...

  • Page 13: ３－７．Other Commands

    ３－７．Other commands (a) Type of command ＦＬＧ？０　　　　 ＦＬＧ？１ ＦＬＧ？２ Each command show the contents of unit. Details are as these. Reply for command "FLG?0" ｂ７： ｂ６： ｂ５： ｂ４： ｂ３： Counter number 3 overflow ｂ２： Counter number 2 overflow ｂ１： Counter number 1 overflow ｂ０：...

  • Page 14: ４．Firmware Update

    　 session begins. After 5s, "COUNT" LED lamp turns off then this session will be done. ⑥　Stop "Tera Term" then cut off the line TCP/IP or USB, turn off power line of NCT08-02. Turn on power of NCT08-02 again, the firmware version will be new.

  • Page 15: ５．Synchronous Drive Of Multi Units

    　　This procedure activate more than one unit at the same timing chart. ６．Regulations and guidelines (a) Regarding NCT08-02 when it receives data read command, it stops count and timer action for 120 ns. This disable period is need to get latest data to latch 48 bits count data.

  • Page 16: ８．Performance And Specifications

    LEMO NIM LEVEL RECEIVER COUNTER CH0～CH8 COUNT IN NIM LEVEL ８．Performance and specifications Power NIM AC85V～132V 0.2A, DC +6V:0.4A, -6V:0.3A Counter Input level 　Current Level -12mA～-36mA:"1" -4mA～+20mA:"0" Input Ｚin = 50Ω 　　 　Count frequency　More than ５００ＭＨz Input connector 　LEMO ERA00250 Channels 　０～７channels (ＣＨ７...
