- Page 1 4CH(2CH)ENCORDER COUNTER ER4C-04, ER2C-04 User's Manual (3164,3165 Ver.5) APPLICATION ELECTRONIC DEVICES TSUJI ELECTRONICS CO.,LTD 3739 Kandatsu-machi Tsuchiura-city Ibaraki-pref 300-0013 Japan Phone +81-29-382-3031 Fax +81-29-832-2662 URL http://www.tsujicon.jp/ E-mail info2@tsuji-denshi.co.jp...
-
Page 2: Table Of Contents
Contents １．Specification･･･････････････････････････････・・・・・････ ２．Panel Layout････・・・・･････････････････････････････ ３．SETUP mode・・・・･･･・・・･････････････････････････ ４．Communication Command･･････････････････････ 5．Firmware Version Up･･････････････････････... -
Page 3: １．Specification
4CH（２CH） ENCORDER COUNTER ＜＜ER4C-04, ER2C-04＞＞ User's Manual １． Specification １） Power Supply AC100V-220V 50/60Ｈｚ ２） Power Consumption 100VA maximam ３） Backup Memory backup by internal batteries during Power off state. (more than 5 years) ４） Counter 32bit 10 decimal digit （-2147483648 ～ 2147483647) ５） Preset Data of LCD indicator are set as present data by Preset SW. -
Page 4: ２．Panel Layout
２． Panel Layout １） Flont Panel(4CH) ① ② ③ ④ ⑤ ⑥ ⑦ ① POWER SW for Power on/off ② LCD indicator ● Scaling Parameter is default value LCD indicate encoder pulse count. (the least significant 7 decimal digit) * if count value is more than +2147483647 or less than -2147483648, the polarity will be reversed upper ：current counter value lower ：preset value（can be changed by ⑤... - Page 5 ２） Rear Panel(4CH） ① ② ③ ④ ① LAN Connector for LAN(10/100BASE-T) ② F3A Fuse holder for AC220V if necessary use 3A midget fuse ③ A,B,C,D ENCORDER Encoder input connector for A,B-phase type incremental Encoder Encoder type selections between Line driver and Open collector are available individually by setting.
-
Page 6: ３．Setup Mode
３．SETUP mode You can setup Encorder Counter in SETUP mode. *When SETUP mode, Encorder Counter stops counting. １） Setting Preparation and Completion Turn on the Power ON SW, and you can use Encorder Couneter in a few seconds. Setting values(MULT-P, DIR, Z-LED, ENCTYPE, LANCTRL, LAN IP:1, LAN IP2, Port no) are kept by battery backup. -
Page 7: ４．Communication Command
４． Communication Command 1) De-limitter is fixed to be CR+LF. 2) Command format except command type will be ignored. explanation command type reply A position counter read request RA±□□□□□□□ (the least significant 7 digit) B position counter read request ＲＢ±□□□□□□□ (the least significant 7 digit) C position counter read request ＲＣ±□□□□□□□... - Page 8 Additional Command(Rev.3～) explanation command type reply A position counter read request RA±□□・・・□□ (10 digit) (10 digit format) B position counter read request ＲＢ±□□・・・□□ (10 digit) (10 digit format) C position counter read request ＲＣ±□□・・・□□ (10 digit) (10 digit format) D position counter read request ＲＤ±□□・・・□□...
-
Page 9: 5．Firmware Version Up
５． Firmware Version Up You can update firmware. When you update firmware, cut connection between Encorder Counter and Encorder for safety. Download version-up software(for Windows) from Tsuji Electronics Homepage(http://www.tsujicon.jp/). ① ③ ⑤ ② ④ Download version-up file fromTsuji Electronics Homepage and extract it. - Page 10 For safety reasons, unplug the appliance from the outlet when you open cover. If you warry, please contact us. ① Turn off POWER ON SW and open the cover. There is DSW1 on Printed Curcuit Board"TEP178". Set DSW1's switch1 on. ②...
