X-Clamp
For PRIME X Vacuum Wax Injectors
OPERATIONS MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Yasui X-Clamp and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ROMANOFF Yasui X-Clamp

Summary of Contents for ROMANOFF Yasui X-Clamp

  • Page 1 X-Clamp For PRIME X Vacuum Wax Injectors OPERATIONS MANUAL...
  • Page 2 74-269X-SC - X-Clamp for Yasui Prime X Wax Injector Systems - The manufacturer shall in no event liable damage resulting from improper use, negligence to follow the warnings and cautions in the instructions manual or the labels the machine, unskillfulness, use of non-original optional consumable accessories/ spare parts, non-authorized modification.

  • Page 3: Table Of Contents

    CONTENTS 1. SAFETY INFORMATION 2. INTRODUCTION 2-1. SPECIFICATION LABEL 2-2. WORKING CONDITIONS 2-3. INSTALLATION 2-4. TRANSPORTATION 2-5. PRODUCT INFORMATION 3. INSTALLATION 3-1. ACCESSORIES 3-2. PLACE 3-3. Z axis adjustment 3-4. Y axis adjustment 4. FUNCTION 5. OPERATION...

  • Page 4: Safety Information

    74-269X-SC - X-Clamp for Yasui Prime X Wax Injector Systems 1. SAFETY INFORMATION WARNING 1. Do not look into wax injection nozzle by bare eyes because unexpected discharge of molten wax from the nozzle may cause eye burn. Be sure to always place a rubber mold or a pan in front of wax injection nozzle to block molten wax flow so as to prevent accidental flow of molten wax into the eyes or over the skin.

  • Page 5: Introduction

    74-269X-SC - X-Clamp for Yasui Prime X Wax Injector Systems 2. INTRODUCTION 2-1. SPECIFICATION LABEL 1) The principal specifications label of this machine is affixed on the side of X Clamp. 2) When ordering spare parts, specify the production serial number that is printed on that label.

  • Page 6: Installation

    74-269X-SC - X-Clamp for Yasui Prime X Wax Injector Systems 3. INSTALLATION 3-1. ACCESSORIES 74-265-AJ2 Please review this list to ensure all parts are included without damage.

  • Page 7: Place

    74-269X-SC - X-Clamp for Yasui Prime X Wax Injector Systems 3-1. ACCESSORIES 1) It is dangerous to hold any part of upper clamp when removing it from the box or while transporting. The upper clamp can be easily removed from lower clamp unit. As such, the lower clamp unit may become accidentally undone and fall on your foot.
  • Page 8 74-269X-SC - X-Clamp for Yasui Prime X Wax Injector Systems 4) You may use the supplied mirror to assist your installation of the nozzle cover on the right or left side. This will allow you to confirm the nozzle position and sprue gate of the rubber more easily.

  • Page 9: Z Axis Adjustment

    74-269X-SC - X-Clamp for Yasui Prime X Wax Injector Systems Connect each corresponding tube from clamp unit with barb joints. CAUTION Do not power on the unit while right panel is open 3-3. Z axis adjustment 1) The PRIME X has a new acrylic jig with an adjustable Z axis. This new jig eleminates the need of having several acrylic jigs for each mold.

  • Page 10: Y Axis Adjustment

    74-269X-SC - X-Clamp for Yasui Prime X Wax Injector Systems CAUTION Do not touch anything around the rubber mold or clamp stage. Be cautious of hot wax. ** Sprue former: Strongly recommended when vulcanizing rubber for optimal fitting. SKU: 98-132 (large) or 98-133 (small) 3-4.

  • Page 11: Function

    74-269X-SC - X-Clamp for Yasui Prime X Wax Injector Systems 4. FUNCTION Maintenance and configuration menu via the FUNCTION button As previsously ounlined in PRIME X instruction manual, you will need to edit the system’s configuration using the FUNCTION menu under P10 to configure your X-Clamp. Navigate to the FUNCTION display by holding the [FUNCTION] button down.

  • Page 12: Operation

    74-269X-SC - X-Clamp for Yasui Prime X Wax Injector Systems 5. OPERATION SHOOTING PRCEDURE 1) Power ON the machine before starting. 2) Select the desired memory preset. 3) Check temperature, pressure and other settings. 4) Place your rubber mold onto the acrylic jig, then place the jig onto the clamp stage.
  • Page 13 74-269X-SC - X-Clamp for Yasui Prime X Wax Injector Systems NOTES...
  • Page 14 74-269X-SC - X-Clamp for Yasui Prime X Wax Injector Systems...
