Sunjoy S-DN2096SST Assembly Instructions

Assembly Instructions

Item No.: S-DN2096SST

IMPORTANT

Thank you very much for choosing Sunjoy Group.

Please take time to read these instructions thoroughly and follow each step carefully for safe and easy

operation. Keep this manual for future reference.

We would like to hear from you with any comments or suggestions. You can call us toll-free at

1-866-578-6569 anytime 24 hours / 7 days a week,

You can also send the email to

amazon@sunjoygroup.com

or visit

www.sunjoyonline.com

to get tech. assistance or to place your

Cautions:

replacement part order form.

Production Number: 2018xxxx

Table of Contents

Need help?

Do you have a question about the S-DN2096SST and is the answer not in the manual?

Page 1 Assembly Instructions Item No.: S-DN2096SST IMPORTANT Thank you very much for choosing Sunjoy Group. Please take time to read these instructions thoroughly and follow each step carefully for safe and easy operation. Keep this manual for future reference. We would like to hear from you with any comments or suggestions. You can call us toll-free at...
Page 2 Part List Description Remarks Upper Seat Base Cushion Ottoman Ottoman Cushion Table Top Table Frame Table Leg 1 Table Leg 2 Hardware Pack Extra Description Nut M6 Bolt M6x20 Bolt M6x15 Flat Washer M6Wrench Step 1: Assembly of Chair 1. Connect Upper Seat (A) to Base (B) with Nut (AA), Bolt (BB) and Flat Washer (DD).
Page 3 2. Put the Cushion (C) on the Chair. 3. Put Ottoman Cushion (E) on the Ottoman (D). 4. Put the Ottoman (D) under the Chair like photo. Step 2: Assembly of Table H (I) 1. Insert the Table Leg 2 (I) into Table Leg 1 (H). 2.
Page 4 3. Put the Table Top (F) on the assembled Table like photo. Limited Warranty: The item is warranted to be free from defects in material or workmanship for a period of twelve (12) months. However, we do not reimburse for transportation or delivery costs, nor compensate the individual or any outside party for assembling or disassembling the product.
