2021-6651
2022-01-31
For use only by Restrain trained operators. B100 Restrain Generator is a proprietary delivery
device which produces ethylene gas from Restrain Fuel upon activation within the device.
B100 Restrain Generator
Only use Restrain Fuel for the B100 Restrain Generator
READ THE LABEL AND OPERATING MANUAL BEFORE USING
KEEP OUT OF REACH OF CHILDREN
PREVENT ACCESS BY UNAUTHORIZED PERSONNEL
REGISTRATION NO. 34153
PEST CONTROL PRODUCTS ACT
Restrain Company Ltd. (UK address)
Unit 7 The Forum, Minerva Business Park
Lynchwood, Peterborough, United Kingdom PE2 6FT
Restrain Netherlands BV (Netherlands address)
Minervum 7030, 4817 ZL Breda, The Netherlands
Canadian Representative:
DEVICE
COMMERCIAL
Registrant:
+44 (0)173 337 2526
N2 Compliance Ltd.
106 Milson Crescent
Guelph, Ontario
Canada N1C 1G5
(519) 837-0629
Advertisement
Table of Contents
Related Manuals for Restrain B100
Summary of Contents for Restrain B100
- Page 1 B100 Restrain Generator DEVICE COMMERCIAL For use only by Restrain trained operators. B100 Restrain Generator is a proprietary delivery device which produces ethylene gas from Restrain Fuel upon activation within the device. Only use Restrain Fuel for the B100 Restrain Generator...
-
Page 2: Table Of Contents
TABLE OF CONTENTS GENERAL INFORMATION: ........................3 SAFETY AND HANDLING: ........................3 PRECAUTIONS ........................... 3 DIRECTIONS FOR USE: ......................... 4 APPLICATION INSTRUCTIONS: ......................4 ENVIRONMENTAL PRECAUTIONS: ...................... 5 STORAGE ............................5 DISPOSAL ............................5 NOTICE TO USER: ..........................5 OPERATING MANUAL ..........................6 PREFACE ............................ -
Page 3: General Information
GENERAL INFORMATION: The intended use of the B100 Restrain Generator is for the conversion of Restrain Fuel to ethylene gas to accelerate ripening in greenhouse tomatoes. The B100 Restrain Generator has been developed to produce the recommended level of ethylene gas for use in greenhouse tomatoes. The B100 Restrain Generator uses Restrain Fuel at three settings: 1.44 L/24 hours, 2.88 L/24 hours and 4.32 L/24 hours to produce the... -
Page 4: Directions For Use
APPLICATION INSTRUCTIONS: Follow all safety precautions and use directions listed in the B100 Restrain Generator Operators Manual for the correct unit placement. Follow all generator program prompts/settings for the application requirements. Follow the instructions in the B100 Restrain Generator Operators Manual for proper use, maintenance and clean-up procedures. -
Page 5: Environmental Precautions
The setting for the B100 Restrain Generator (1.44 L/24 hrs., 2.88 L/24 hrs. or 4.32 L/24 hrs.) to produce the recommended level of ethylene gas will be determined by the total greenhouse volume. -
Page 6: Operating Manual
For use only by Restrain trained operators. is a proprietary delivery device B100 Restrain Generator which produces ethylene gas from Restrain Fuel upon activation within the device. READ THE LABEL AND OPERATING MANUAL BEFORE USING KEEP OUT OF REACH OF CHILDREN... - Page 7 For information about settings, maintenance and repairs not provided for in this user manual, please contact the technical department of your supplier. This user manual has been compiled with all possible care. Restrain assumes no responsibility for any errors in this manual and/or the consequences of an erroneous interpretation of the instructions.
- Page 8 associated drawings and diagrams.
-
Page 9: Preface
During the lifetime of the machine, engineering improvements may result in the need to revise this manual. It is then at the discretion of Restrain, if a revision or new version of this manual is required. The following table describes the main changes for each document version of this manual. - Page 10 V1.1 November 20219 Minor revisions...
-
Page 11: Introduction
Furthermore, this will void the warranty and lease contract. Contact the manufacturer if anything needs replacement. • Always use Restrain Fuel supplied by the manufacturer. The machine has been thoroughly tested with this specific fuel. If you use any other type of fuel, this may negatively affect the operation and life expectancy of the machine. -
Page 12: Intended Use
INTENDED USE The machine is intended for indoor use only. The maximum storage area size depends on the standard of construction, room air leakage, and the target level of ethylene concentration. When the room is too small, too much ethylene will remain inside. This will damage the crops TECHNICAL SPECIFICATIONS The following specifications apply to the machine: Description... -
Page 13: Description
DESCRIPTION This chapter describes the B100 Restrain Generator and its functions. Item Function Handles Use the handles to carry the machine. Program selection knob Use the program selection knob to select the required pump speed. Reset button Use the reset button to restart the machine after a thermal error. -
Page 14: Workings Of The Machine
WORKINGS OF THE MACHINE The machine has an internal catalyst. The temperature of the catalyst reaches a high temperature. The Restrain Fuel is pumped into the machine, the heat of the catalyst will vapourize the fuel, which then turns into ethylene. -
Page 15: Safety
Workers must wear a long-sleeved shirt, long pants, chemical-resistant gloves, socks and shoes during application, clean-up and repair of Restrain Ethylene Generator Model B100. A respirator with a NIOSH- approved organic-vapour-removing cartridge with a prefilter approved for pesticides, or a NIOSH- approved canister approved for pesticides is required if levels of ethylene oxide are above permissible levels (ACGIH TLV - TWA 1 ppm). - Page 16 At the rear of the machine Warning sign "This side up" At the right side of the machine Text sign "Restrain Fuel ONLY" At the front of the machine Make sure that the safety signs are always clearly recognizable and legible. Replace them if...
- Page 17 Always adhere to the safety warnings in this manual. Failure to do so may result in serious personal injury or material damage. • Restrain Fuel is extremely flammable. Do not smoke or use open fire, a radio or a mobile phone when you handle the fuel.
-
Page 18: Transport
Carefully open the packaging. Remove all materials from the box. Make sure that all ordered parts have been delivered: • B100 Restrain Generator Place the machine This task describes where and how to place the machine. Place the machine in the premises that needs treatment. - Page 19 Prepare the Restrain Fuel jerrycan This task explains how to prepare the Restrain Fuel jerrycan for use with the machine. Restrain Fuel is extremely flammable. Do not smoke or use open fire, a radio or a mobile phone when you handle the fuel.
-
Page 20: Operation
OPERATION This chapter explains how to operate the machine. Start the machine If necessary, start the machine as follows: Plug in the mains power supply cord into the electrical socket. The Power light will turn green. The heater is warming the catalyst. This takes approximately 40 minutes. Select the required programme: •... -
Page 21: Maintenance And Cleaning
Turn off the machine This task describes how to turn off the machine. Disconnect the machine from the mains power supply. The machine remains hot for at least 6 hours. Wait until the machine has cooled down sufficiently before you handle or transport the machine. Emergency situations In case of an emergency situation: Unplug the machine from the mains power supply. -
Page 22: Storage
STORAGE Store any unused Restrain Fuel in its original container in a cool, dry place. Store this product away from food and feed. Store out of reach of children, preferably in a locked storage area. You can store the machine for later use. -
Page 23: End Of The Lease Contract
Remove the tube from the Restrain Fuel jerrycan. Store or dispose of the Restrain Fuel according to local laws and regulations. Do not return Restrain Fuel to the manufacturer. Restrain Fuel is highly explosive and can only be shipped under specific conditions. - Page 24 PMRA Approved Label 2019-6925 2021-10-25 Restrain NL bv Minervum 7030 4817 ZL Breda +31 (0)653 86 92 21 www.restrain.eu.com dirk.garos@restrain.eu.com...
