  • Page 1 RapidScan ST-5 series User Manual...
  • Page 2 Notice: Please make sure that there are no children around while using the reader.

  • Page 3: Installation

    1.Installation • Connect to power • Press power button to power on reader • Login UI will appear after reader is power on & activated completely. USB port x 1 With USB pen-drive user can do data output and F.W update...
  • Page 4 2.Login in: input ID/PW to log in...
  • Page 5 3. Operation UI Battery status Profile selection Sample info : Preset Analysis: Click to get Instant sample information analysis result Delay Analysis: Can set time for delay analysis Image of test Real Time Analysis Click to activate automatic analysis. Channel indication Indication of channel # of Result columns single or multi channel kit.
  • Page 6 4. Analysis Select profile Select test kit for analysis Click Analysis or Delay Analysis Wait for reader to analyze result. Result & image will be presented within 1 minute. To check each channel’s result please click this icon to select other channel 1/1: means single channel kit 1/3: means 1...
  • Page 7 5. Setting About: Present reader’s software and hardware version Profile: To import / delete/ calibrate each profile Date/Time: Reset date/time here if it is not correct User: set authentication of user level Sleep: LCD screen sleep mode setting Advanced: Advance setting of reader...
  • Page 8 6. Setting: Profile Profile: Show current selected profile USB import: Using USB pen-drive to import profile. QRCode Import: Insert QR code card to reader & press this button to upload profile Calibration: Insert calibration chart to do calibration Delete: Selected profile would be deleted by pressing this icon...
  • Page 9 7. Setting: USB Import USB import: Using USB pen-drive to import profile. Step 1. Save profile file to your USB pen-drive under “ini” folder Step 2. Connect USB pen-drive to reader, Step 3. Press “USB Import” to upload profile Step 4. You will see the profile in USB pen-drive showing on reader’s UI Step 5.

  • Page 10: Setting Date & Time

    8. Setting: Date/Time Setting Date/Time by pressing each column...

  • Page 11: Setting: User

    9. Setting: User User: Present current selected user account name Add: Adding new user account Edit: Editing user account information such as name, password and login- level Delete: Deleting user account...

  • Page 12: Setting: Sleep

    10. Setting: Sleep Set sleep mode by selecting time from list. SW includes a list of time settings, ranging from one minute to Never.

  • Page 13: Setting: Advanced

    11. Setting: Advanced Update F/W: Use USB pen-drive to update F/W of reader by click this icon Network: To set this reader’s parameters when reader become Web UI mode Web UI mode: Go to web UI mode can let user use cell phone or laptop to operate reader Export Debug: Use pen-drive to save debug data for vendor to do debug...
  • Page 14 AP Mode In AP mode, ST5 works as a host. In this condition, your mobile need to open WiFi and find the network name “RapidPlantsSTD”. After your mobile connect to this network, you can use your web browser (like Chrome) at your mobile to type in IP address 192.168.0.1 or you can use IPFinder App to enable the interface of ST5 web server.

  • Page 15: Client Mode

    Client Mode It is a client device to connect to your office WiFi router. When the ST5 needs to connect to internet, we should set it as Client Mode. ST5 can go through your office WiFi LAN to reach internet. ①...
  • Page 16 Client Mode When finishing setting Client Mode, use IP Finder to locate the IP adress. After that, users can use the web browser to login. Click here to search the device.
  • Page 17 12. Database Date: Select date to search data ^ Arrow: to move menu upward v Arrow: to move menus downward Export: Use USB pen-drive to export select data...

  • Page 18: Power Off

    13. Power Off Press Power button Select “Log Out” to Log in page Select “Power Off” to turn off reader Select “Back” to resume operation page...
  • Page 19 RapidScan ST5-series user manual Pacific Image Electronics Co., Ltd 7F, No. 239, Sec. 1 Datong Rd., Xizhi Dist., New Taipei City 221, Taiwan Tel: +886-2-8692-1800 (GMT +08:00) Fax: +886-2-8692-1860 Email: sales@scanace.com.tw...
