WATSON DESKING
Step 1
Center stiffener tube in
pocket. Position 2
clamping brackets
(WFG# 490154F) on the
ends of the tube and the
3rd bracket in the
center. align brackets to
pilot holes and secure
with 3/4" wood screws
provided.
Step 2
Attach legs next. Align
holes in leg brackets to
the threaded inserts in
worksurface.
Attach legs to top with
1/4-20 machine screws
provided.
Page 1 of 2
800.426.1202
www.watsondesking.com
PRODUCT INSTALLATION:
Desk Assembly
INS50100
MIRO
Advertisement
Table of Contents
Related Manuals for Watson Desking MIRO
Summary of Contents for Watson Desking MIRO
- Page 1 PRODUCT INSTALLATION: WATSON DESKING Desk Assembly Step 1 Center stiffener tube in pocket. Position 2 clamping brackets (WFG# 490154F) on the ends of the tube and the 3rd bracket in the center. align brackets to pilot holes and secure with 3/4" wood screws provided.
- Page 2 PRODUCT INSTALLATION: WATSON DESKING Desk Assembly: Verve Step 3 Align the two halves of the verve table top. Step 3 Slip the 3 joint connectors into the pockets and use the thin rod provided to tighten the ball shaped nuts. Make sure the top of the two halves of the worksurface are tight and flush.
