MojoDesk 16724 Installation Manual

Installation guide: Fixed - Height Side Table

Attention: The drawings below are for guidance only and they may differ slightly from the product and fittings received. Please contact our
customer service department if there are any missing tools or installation problems.
C
A x12 B x4 x2
M6x16 M8x50 5x5/4x4 Allen key

Component List

No. Part Qty No. Part
1 2
2
Feet Left column
3 4
1
Right column Left beam
5 1 6
Right beam Intermediate tube
7 2
Supporting plate
技术参数
16724 (Black)
Product Model
16725 (Grey)
150 lb
Max. Load Capacity
Height
Width 48" - 60"
Tabletop Dimensions
Depth 24"
mojodesk.com/help
D E F G
x2 x2 x10
M8 M6x10 ST4.2x19 Cushion

Installation Diagram

Qty 6
4
1
7
1
2
1
1
STEP1
A x8
M6x16
C x1
5x5
29"
STEP2
C x1
4x4
D x2
M8
E x2
x10
M6x10
7 STEP3
B x4
5
M8x50
3
C x1
5x5
1
C
Install feet
A
①
②
Install beam assembly
C
E
⑥
⑤
Insert intermediate tube into left and right columns(4&5) to a proper position. Then use 4*4 Allen key to tighten C
screw D and E.
Connect beam assembly and column
assembly
C
B
Beam assembly
Column assembly
③
Connect foot (1) to feet(2&3) and then lock
them by using screw A and 5*5 Allen key C.
D
④
Fix the beam assembly on
column (2) & (3) and use 5*5
Allen key C to screw screw B
