- Page 1 ASCOT ROUND SOFA DINING SET Assembly Instructions for Casual Dining IMPORTANT-RETAIN FOR FUTURE REFERENCE...
- Page 2 GENERAL INFORMATION Assembly Instructions WARNINGS - For domestic and outdoor use only. - We suggest you retain these instructions for future reference. - Keep fittings out of children’s reach and keep children well away from construction area. - Periodically check all fittings and re-tighten as necessary. - Do not sit or stand on your table.
- Page 3 ASCOT ROUND SOFA DINING SET Fixtures and Fittings Components supplied. Please use this guide if you x4 Round Sofas require replacement parts. Visual Dimensions Fixtures and fittings supplied(actual size) 88cm Dimensions 20mm 44Hcm ø 16 X 1.0mm 115mm 0.8Tcm IMPORTANT-RETAIN FOR FUTURE REFERENCE...
- Page 4 ASCOT ROUND SOFA DINING SET Assembly Instructions for Sofa Unbox your sofa sections to begin the assembly process. Turn your sofa base onto its side so you can get to the screw holes underneath. Due to the size of the sofa this may require two persons to assemble.
- Page 5 ASCOT ROUND RISING TABLE Fixtures and Fittings Components supplied. Please use this guide if yo u require replacement parts. Dimensions Visual ø60x0.5cm Fixtures and fittings supplied(actual size) ø35x1.5cm Dimensions 159X0.5cm ø 13x5mm ø ø160X4cm 16x1mm ø4X66mm 66.5X72X37.5cm M6x35mm 79Xø121X46.5cm IMPORTANT-RETAIN FOR FUTURE REFERENCE...
- Page 6 ASCOT ROUND SOFA DINING SET Assembly Instructions for Rising Table Unbox your dining table to begin the assembly process. Lay the table top (4) upside down on a flat surface. Attach the table top section (5) to your table top,this section is what creates the lock in and lock out mechnism for your rising table.
