Jenn-Air JEC8536AD Series Technical Information

https://appliancetechmanuals.com
Technical InformationElectric Cooktop
JEC8536AD*
• Due to possibility of personal injury or property damage, always contact an authorized technician for servicing or
repair of this unit.
• Refer to Service Manual 16022159 for detailed installation, operating, testing, troubleshooting, and disassembly
instructions.
All safety information must be followed as provided in Service Manual 16022159.
To avoid risk of electrical shock, personal injury or death; disconnect power to oven before servicing, unless
testing requires power.
Model
Power Source @ 120/240/208 V
Electrical rating
Amperage
Frequency
Element Wattage @ 240/208 V
6-inch ribbon radiant
6-inch oval ribbon radiant
7-inch ribbon radiant
8-inch ribbon radiant
8-inch ribbon radiant
9/6 inch dual ribbon radiant
Cooktop Surface
Cooktop surface
Product Dimensions in. (cm)
Height
Width
Length
Product Cutout Dimensions in. (cm)
Width
Length
Depth (minimum from top of countertop)
Weight lbs. (kg)
Approximately shipping weight
June 2003
MEC5536BA
!
CAUTION
!
WARNING
Updraft
−
1
JEC8536AD* MEC5536BA*
8.4 kW/6.3 kW 9 kW/6.8 kW
35/30 Amp max. 38/33 Amp max.
60 Hz 60 Hz
1,200 1,200
1,800
1,800
2,000 2,000
N/A 2,200
2,400/1,000 2,400/1,000
Ceran/Eurokera Ceran
3-3/4 (9.5) 3-3/4 (9.5)
21-1/2 (54.7) 21 (53.3)
35-5/16 (89.7) 35-5/16 (89.7)
20-3/8 (51.9) 20-3/8 (51.9)
34-9/16 (87.9) 34-9/16 (87.9)
4-1/8 (10.5) 4-1/8 (10.5)
44 (19.9) 57 (25.8)
N/A
N/A
16022396 Rev. 0
