Summary of Contents for Leica Microsystems EnFocus OCT

  • Page 1 From Eye to Insight EnFocus OCT User Manual 9054-10063_EN - Revision K-00...
  • Page 2 Medical decision remains the responsibility of the clinician. physician or practitioner. Leica Microsystems has made every effort to provide a complete and clear user manual highlighting the key areas of product use. Should additional information Leica Microsystems CMS GmbH...
  • Page 3: Table Of Contents

    EnFocus Configuration for Micoscope Integration 68 Operation Compliance Training 14.1 EnFocus Cart Configuration Calibration 14.2 EnFocus Configuration for Micoscope Integration 73 Draping 14.3 Common to Configurations Device startup Standard Workflow Shutting down the system EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 4 Fundus viewing system compatibility Glare 16.1 Glare Management 16.2 Glare Mask Selection Annex 17.1 Abbreviations 17.2 Glossary 17.3 Principle of operation 17.4 Sampling density and resolution 17.5 Expected positions of equipment and people Quick Reference Guide EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 5: Introduction

    Optional product features Different product features and accessories are optionally available. The availability varies from country to country and is subject to local regulatory requirements. Please contact your local representative for availability. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 6: Safety Notes

    Spectral Domain Optical Coherence Tomography (SDOCT). high. • The EnFocus OCT system is indicated for use as an aid in the visualization of physiologic and pathologic conditions of the eye • The EnFocus is intended for operation in the hospital through non-contact optical imaging.
  • Page 7: Directions For The Operator Of The Instrument

    CAUTION Risk of injury to the patient. The expected service life of the EnFocus OCT system is 7 years. After Do not perform the balancing procedure while a patient 7 years, please contact Leica customer service to arrange for further is underneath the microscope.
  • Page 8 Risk of damage to the EnFocus OCT system. Do not expose this equipment to rain or moisture. NOTICE Risk of damage to the EnFocus OCT scan head due to immersion in a liquid. Do not immerse the scan head in any liquid. Immersion will result in damage to the electronics in the scan head.
  • Page 9 Do not unnecessarily prolong the use of the device for needed to reach the maximum exposure limit. ocular examination. CAUTION Thermal hazard to the cornea and lens. To limit the risk of ocular damage do not unnecessarily prolong the duration of exposure. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 10 Risk of electrical shock for the patient or the operator, or damage to the equipment. Never use a converter adapter to connect the three- pronged AC plug into a two-pronged, ungrounded wall outlet. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 11 Special precautions for Medical Electrical Equipment. Portable and mobile RF communications equipment can affect Medical Electrical Equipment. Only install and put into service this Medical Electrical Equipment according to the EMC information provided in this manual. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 12: Signs And Labels

    EnFocus Cart Installation The following labels are affixed to the back panel of the EnFocus system: EnFocus Cart Installation Systems with 120 V (e.g. for USA) EnFocus Cart Installation Systems with 230 V (e.g. for Europe) EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 13 8 Cautions and Warnings 9 Model Number and Date of Manufacture 10 Product Optical Output Classification 11 CE marking Engine and Interface box rear panels are not visible with the system back panel in place. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 14 Safety notes EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 15 POWERVAR www.powevar.com WARNING: DANGER: CAUTION: AVERTISSEMENT: DANGER: ATTENTION: Please contact POWERVAR Service at North America - 800-369-7179 www.powevar.com International (UK): +44(0) 1793 553980 Model Number: Manufacture Date: P&N 51060-23R S/N 5106023R - 1540019 EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 16 Voltage has the following labels are located on the EnFocus subsystems and system label on the integrating microscope. System Serial Number, UDI & Manufurer Information Module Serial Number Module Model Number and Manufacturing Date EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 17 Safety notes System Information Scanner Model Number, Manufacturing Date, and Manufacturer Information Manufacturer Label EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 18: Enfocus Components

    EnFocus Components EnFocus Components EnFocus Cart Installation The EnFocus OCT cart configuration includes the following components: 1 Screen Accessories • Filter mask M844 2 Keyboard / Mouse 3 Mobile Security Cart circle 4 Optical Engine modified bar • Filter mask Proveo 8 5 Scanner Storage Case •...
  • Page 19 Scanner mounting arm that moves fluidly in X, Y, and Z directions. The scan head of the EnFocus OCT system is intended to be mounted to the optics carrier of compatible surgical microscopes The IEC 60601-1 compliant keyboard is sealed in water-proof for imaging during surgical procedures.
  • Page 20 2.0 USB ports for accessing data on the system and a power The following camera controllers are compatible with the Enfocus switch. There are two 3.0 USB ports at end of the glove box. system: Leica HDC100, Leica HDC300, Panasonic GP-US932, and Sony PMW-10MD. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 21 To make the connection, plug the DB9 female connector on the end The battery full load runtime is 20 minute and the recharge time to of the Microscope communication cable (p/n 10747122) into the 60% is 6-10 hours. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 22 9075-10039, 23 Spectrometer, VHR UPS system is off and not connected to the mains press and 9075-10031, 44 Spectrometer, HR hold the power switch for at least 2 seconds. Scanner 9075-25074 9055-10078 (Scan Head case) EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 23: Enfocus Configuration For Microscope Integration

    The CPU Module provides all of the required processing capability and generates views that may be displayed on connected monitors. The CPU Module has a video input/output, serial, USB, and Ethernet signal connections that are connected when installed in the integrating microscope. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 24: Invivovue Software

    InVivoVue Software Korea, Taiwan, Brazil, Mexico, and China as the device is not a registered radio device in those countries. The EnFocus uses software developed by Leica Microsystems called InVivoVue to control the OCT engine and analyze data collected 4.2.5 Interface Panel from the scan head.
  • Page 25: Device Overview

    The user controls the microscope, including focus and zoom controls, as he/she would normally. When the target structure is The scanning OCT signal beam of the EnFocus OCT is telecentric aligned and focused, the OCT is also aligned. When using an...
  • Page 26: Installation & Removal

    Initial set-up Installation of the scan head is the same for both the Leica M844 Do not use the EnFocus OCT system until a service technician and the Proveo microscopes. To install the scan head: has completed installation and verified system operation is fully Determine the work station layout of the microscope and the functional.
  • Page 27 NOTICE Once the cable has been routed and is secured, re-wind any Risk of damage to the EnFocus OCT scan head during transportation. excess cable onto the cable wraps on the side of the cart and When carrying the scan head, grip the tube  of the scan head.
  • Page 28: Mounting The Enfocus Oct Cable

    Mount the cable cover onto the microscope articulated arm cable with 3 knurled thumb screws. In the absence of a cable duct the EnFocus OCT cable may be Once the scan head has been installed onto the microscope, the secured using cable ties.
  • Page 29: Glare Mask Install And Remove

    You will hear a click when it is fully engaged. To remove the mask, simply pull it out of the slide, gripping the handle firmly. Be sure to replace the dust cover. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 30: Removing The Scan Head

    Once the computer has powered down, turn off the EnFocus device by flipping the switch on the UPS. While standing behind the optics carrier, use ball head Allen key Reinstall the microscope objective lens by carefully threading it EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 31: Removing The Enfocus Oct Cable

    EnFocus. The method for programming the input device can Image and auto sharpen in a single button. be found in the user manual of the microscope. The functions available and the effect that they have on the EnFocus behavior are EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 32 Advance from current preset scan parameters to Workflow the next in the series of presets for the procedure. Change View Changes to next view in series (50:50, Full Screen). OCT Toggle Image Turns Image lock function on/off. Lock EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 33: Operation

    Change View drapes used for surgical microscopes. Leica Microsystems Toggle Overlays On/Off recommends draping the EnFocus OCT device when using in a sterile environment. No unique draping specification is required to Increase Z Position accommodate the EnFocus OCT scan head.
  • Page 34: Standard Workflow

    Risk of injury for the patient. imaging and as soon as the microscope stops moving EnFocus will Ensure the EnFocus OCT scan head is securely attached find the target surface and report how far away from the working to the microscope prior to moving into position above distance the surface is and allow the surgeon to make adjustments the patient.
  • Page 35: Invivovue Software

    Once the computer has completed its shutdown sequence, turn off the master power switch on the front of the UPS. This will Leica Microsystems' InVivoVue software enables a user to acquire, power down the imaging engine and interface box. process, and display images acquired on Leica Microsystems’...
  • Page 36 Advanced users may see options for interacting with the hardware at a low level. X Help menu The help menu has shortcuts for reviewing the user manual and release notes, as well as viewing dialogs with system and installation information. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 37: Primary Functions

    Display Controls and the Patient menu, the status of the DI C800 (intraocular viewing) display is provided when installed. On the right, between the Display Controls and the Surgeon Preference Menu, the mode of the microscope is shown. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 38 Using a mouse, select the overlay and drag the DSC to desired location. Using foot pedal, use the OCT Toggle Footpedal to EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 39 Once collected the scan data may be saved, reviewed, Workflow on the footswitch will advance to the next preset. or discarded by overwriting. 3. Save: Saves the captured scan in the formats and locations defined by user preferences. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 40 If the surface being imaged has low signal strength and a surface with high signal strength is nearby it is recommended to turn Location Lock off and manually adjust the Z-position using footswitch or screen controls. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 41: Surgeon Preferences

    Surgeon Preference when "Save" is selected and selecting "Apply" applies the setting until InVivoVue is restarted. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 42 For data collected in Live Mode, you can choose to save an image of the Scan Data View which saves the view when the Live Mode is stopped. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 43 "VR Mode Off", "VR Mode On with enabled then data is saved without any processing that makes BIOM In", and "VR Mode On with BIOM Out". For these options, the images easily viewable. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 44: Patient Management

    Selecting the microscope user ID will select the surgeon preference and this sets the surgeon in the exam metadata. This procedure may be done when initially creating the preference or at any point selecting an alternate Surgeon Preference will EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 45 Do not leave the system unattended when logged in as Administrator. Double check that you have highlighted the correct patient before deleting the entries. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 46: Data Management

    Engineering View provides options to save data as transportable viewable images with a file header. file types. • .OCU: A Leica Microsystems file format containing the raw spectral data in an array of bytes without a header. 8.5.5 Data Copy •...
  • Page 47 Select each patient for whom you want to retrieve data. the Select All Exams Prior To button. Double-click the name or click the >> button to move it to the All exams in your system that took place before the date you EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 48 Exams from multiple patients may be selected and exported together by repeatedly selecting a patient, select exams and then select another patient. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 49 “Select Site for Display.” When done reviewing the data, use site manager to change back to your local site. You will not be able to acquire new exam data until you return to your local site. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 50: Oct Help Functions

    Software Update: Opens window that allows application and operating system updates from Leica to be installed. Software Restart: Activating button closes and reopens software. Use this button if system is not responsive to specific actions. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 51: Advanced Functions

    Examiner/Physician that the exams should be assign and select Ok. A second window will be generated, asking you to confirm that you want to delete the Examiner/Physician and reassign all exams associ- ated with that person. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 52 . scan, select scan button to capture a single volume to be saved or reviewed or select Abort to stop scanning. Function may be activated by selecting under Menu then Continuous Scan. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 53 Open Preferences> Display Options. each B-scan. Verify that the Display Doppler check box is selected. Enter the number in the box. De-select the check box if you wish to turn off the Doppler display. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 54 They denote the sample width. range, InVivoVue automatically reverts to the value at the nearest end of the range. These lines can be dragged to adjust the range of line samples used to generate the VIP image. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 55: Care And Maintenance

    Inspect the entire length of the connecting cord (wiring) from where it enters the foot pedal switch to where it enters the cart. Look for wear, cuts in the wiring insulation, or loose strain relief connections. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 56: Enfocus Oct System Maintenance

    Inspect the cart casters to ensure they are rotating smoothly the power supply cord. and swivel correctly. Route the power cord through the bottom cutout as shown If any problems are observed, please contact customer service below. for further assistance. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 57 9.5.1 Transport Cart Configuration The EnFocus OCT Cart Configuration has been designed and tested to withstand transfer between rooms including over thresholds. If your system needs to be transferred to another facility that requires the system to be loaded on a vehicle, contact customer service for assistance.
  • Page 58: Disposal

    11 Troubleshooting The respective applicable national laws must be observed for The following potential failure modes for the EnFocus OCT system disposal of the products, with the involvement of corresponding have been identified. Refer to the charts below to identify the disposal companies.
  • Page 59: Hardware Malfunctions

    Delete current scan and add new scan from quick start grid. Damage to scanning mirrors. Contact customer service for repair. Scan only works in one direction. Cables between engine and the scanner Contact customer service for repair. are damaged. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 60: Image Malfunctions

    Contact customer service for verification of the issue, and spectrum has shifted from factory adjustment. repair. installation. Spectrometer misalignment. Contact customer service for verification of the issue, and Determine this by comparing with repair. line spectrum on Test Patient. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 61: Software Malfunctions

    The scan image oscillates abnormally. Close InVivoVue, and restart it. If this does not resolve the problem, contact customer support. Vertical striations appear in the scan Adjust the focus and/or NA. image. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 62: Software Notifications

    No action required. Item infroms user that the function was aborted by user. Image Optimization aborted due to user activity No action required. Item informs user that the function was aborted due to microscope activity. Optimization requires system to be static during optimization function. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 63 While loading the requested file, one or more of files required to open the scan are not available. Check to ensure that the data is in the folder with the data being opened and retry. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 64 Preferences could not be saved because the Error - Need to have a surgeon under surgeon preferences to save preferences. Add a physician is not uniquely identified surgeon and then save the preference. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 65 Error saving B-scan thumbnail file for calipers Error - Failure to save caliper image. Retry save first then try restarting IVV and power cycle system before contacting Leica service with an IVV problem. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 66 Failed to detect touch screen input Error - Touch screen input not working. Use physical keyboard until able to restart IVV. If problem persists, restart microscope before contacting Leica Service. Error only applicable for EnFocus for Microscope Integration. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 67: Checking The Line Spectrum

    This image may be shared with Technical Support to assist with diagnosing imaging problems. An Extended Warranty is offered through Leica Microsystems at the Turn off Line Spectra mode. Either go to Tools and unselect Line time of sale. The extended warranty includes all adjustments, Spectrum or select Menu >...
  • Page 68: Replacement Accessories

    Service and Spares If you are experiencing system issues and have an extended warranty or own a service contract, please have that information available when you contact Leica Microsystems for service escalation. 12.4 Replacement Accessories Several EnFocus accessories available as replacement parts that will...
  • Page 69: Specifications

    This device is considered a non-contact device and therefore there is no applied part. There is no risk of harm associated with loss of function of the device. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 70: Enfocus Cart Configuration

    • IEC 60825-1, Class 1 Laser Product • Further applied harmonized standards: IEC 62366, EN 60825, 13.3.1 Electrical data IEC 62471, EN 62471, EN 980. • Leica Microsystems NC, Inc. holds the management system certificate for the international standard ISO 13485 relating to Power Ratings (VA/ 400W, DC quality management.
  • Page 71: Compliance

    The EnFocus OCT is intended for use in the electromagnetic environment specified below. The customer or the user of EnFocus OCT should assure that it is used in such an environment NOTE: The EMISSIONS characteristics of this equipment make it suitable for use in industrial areas and hospitals (CISPR 11 Class A). If it is used in a residential environment (for which CISPR 11 class B is normally required) this equipment might not offer adequate protection to radio-frequency communication services.
  • Page 72 270; 315 270; 315 If the user of the EnFocus OCT requires that the IEC 61000-4-11 instrument remain functional even after power 0 % UT for 1 cycle at Sync Angle 0 % UT for 1 cycle at Sync Angle...
  • Page 73 To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the EnFocus OCT is used exceeds the applicable RF compliance level above, the EnFocus OCT should be observed to verify normal operation.
  • Page 74 Note 1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies. Note 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects and people. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 75: Enfocus Configuration For Micoscope Integration

    The EnFocus OCT is intended for use in the electromagnetic environment specified below. The customer or the user of EnFocus OCT should assure that it is used in such an environment NOTE: The EMISSIONS characteristics of this equipment make it suitable for use in industrial areas and hospitals (CISPR 11 Class A). If it is used in a residential environment (for which CISPR 11 class B is normally required) this equipment might not offer adequate protection to radio-frequency communication services.
  • Page 76 30 A/m 30 A/m If image distortion occurs, it may be necessary magnetic field according to to position the EnFocus OCT further from IEC 61000-4-8 sources of power frequency magnetic fields or to install magnetic shielding. The power frequency magnetic field should be measured in the intended installation location to assure that it is sufficiently low.
  • Page 77 IEC 60601 test level Compliance level Electromagnetic environment – guidance Portable and mobile RF communications should be used no closer to any part of the EnFocus OCT, including cables, than the Conducted RF - Disturbance 3V RMS outside ISM 3V RMS outside ISM...
  • Page 78: Common To Configurations

    Recommended separation distances between portable and mobile RF communications equipment and the EnFocus OCT The EnFocus OCT is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the EnFocus OCT can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the EnFocus OCT as recommended below, according to the maximum output power of the communications equipment.
  • Page 79: Compatibility With Third Party Devices

    (ISO 15004-2). • Flat surgical contact lens • Leica RUV800 retinal wide-angle viewing system with an The EnFocus OCT device is not for use with the following surgical integrated inverter microscopes: • Microscopes contra-indicated for pediatric use or restricted to Fundus viewing lens systems tend to be of similar but not identical adult use only.
  • Page 80 While the image is sharp, use highest magnification on the microscope and make fine focusing again using the rotating wheel on the FVS; then the image will become sharp and stay parfocal. EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 81: Glare

    Are glare and FOV Use under these Illumination conditions conditions level of acceptable? microscope Install glare mask Are glare and FOV Use under these conditions conditions acceptable? Remove EnFocus Flowchart I: from microscope Glare Management System EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 82 EnFocus installed magnification Refer to Glare Use under these Is glare level Management System conditions acceptable? Refer to Glare Management System Flowchart II: Glare Test Procedure EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 83 EnFocus installed magnification Is glare within Refer to Glare Use under these illuminated FOV Management System conditions acceptable Refer to Glare Management System Flowchart III: Field of View Test Procedure EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 84 0% Main 25% acceptable? acceptable? 0% Main 50% preferences Ottoflex Ottoflex Refer to Glare Refer to Glare Is glare Management System Management System acceptable? Flowchart IV: Use under these conditions M844 Illumination Adjustment EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 85 0% Main 0% Main acceptable? acceptable? preferences 50% Red reflex 25% Red reflex Refer to Glare Refer to Glare Is glare Management System Management System acceptable? Flowchart V: Use under these conditions Proveo Illumination Adjustment EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 86: Glare Mask Selection

    The gray areas in the bar sketch denote areas that receive 50% illumination. Leica Proveo 8 There is only one glare mask for the Leica Proveo 8 microscope. the illumination shape for the Proveo 8 glare mask is shown below: EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 87: Glossary

    Referring to the direction that is parallel to the of an LED. SLDs are well-suited light sources for propagation of light in the system, i.e. parallel to OCT and are used in EnFocus OCT systems. the optical axis of the system. Equivalently referred Tomography The process for generating a volumetric image, or, to as "longitudinal."...
  • Page 88: Principle Of Operation

    17.3 Principle of operation The EnFocus OCT System provides OCT capability without impacting microscope function. When the EnFocus OCT system is attached to the microscope, the OCT is mounted onto the microscope by means of four mounting screw to the microscope optics carrier. The EnFocus OCT system sits below the microscope optics and the microscope objective is then attached to teh EnFocus.
  • Page 89: Sampling Density And Resolution

    Suggested sampling densities for anterior segment imaging Optical Nyquist Optical Nyquist setting Resolution: sampling Resolution: sampling 175mm density 200mm density objective objective 1.00x 31 μm 16 μm 34 μm 17μm 2.50x 15 μm 8 μm 16 μm 8 μm EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 90: Expected Positions Of Equipment And People

    The surgeon may sit on either side of the patient or superior to the patient's head. The EnFocus OCT system has a 10m long tether and may be positioned where the surgeon can best see the monitor. The foot pedal has a cable length of 9 feet [2.7 m] which may impact the...
  • Page 91 Optics carrier and monitor have separate microscope in transport positioning and drapes available. disconnect external cables as needed to move the system. X Turn off power to microscope (for cart based EnFocus, separately turn off its power). EnFocus OCT / 9054-10063_EN / Revision K-00...
  • Page 94 OCT Up OCT Save Change Joystick State OCT Left OCT Right OCT Down OCT Next OCT Scan Procedure OCT Z- OCT Z+ OCT Live/ OCT Mode Freeze On/Off Optimize Autolocate Recommended Foot Pedal Configuration • Enable Auto advance to next pending scan in save preferences •...
  • Page 95 Personalized Foot Pedal Configuration • Must have "OCT Mode On/Off" programmed on a button • Must have "Change View" programmed on a button (Foot switch or handle) • Program desired functions on the microscope and write them onto the corresponding locations for quick reference...
