SFP Installation

To install the SFP transceivers:
1. Slide the SFP into the cage socket until it
2. Lift the latch to lock the SFP
SFP
2
Tx
Rx
To remove the SFP transceivers:
1. Lower the latch to unlock the SFP
2. Pull the SFP out of the cage socket carefully
SFP
16
clicks into place
Cage Socket
1
Cage Socket
1
Latch
2

Setup Options

Set up your device locally. Choose one of the following options to complete
your setup.
GUI
A
An easy-to-use GUI, compatible with most web browsers.
To minimize scrolling, the screen resolution should be at least
Local Setup
1280 x 1024 pixels.
FortiExplorer
B
FortiExplorer for iOS is a
configure, manage, and
Smartphone Setup
provisions, deploys, and monitors Security Fabric components
such as FortiGate, FortiWiFi, and
Command Line Interface (CLI)
C
An alternate configuration tool from the web-based manager that
uses a terminal emulation
Local Setup
batches of commands from a text file or
Requires a console cable (available for purchase).
user-friendly iOS application that helps you
monitor appliances. FortiExplorer rapidly
FortiAP devices.
application to type commands or upload
configuration script.
