I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
Video Wall Extenders
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
FCAX08/14/20
Advertisement
Table of Contents
Related Manuals for LEGRAND CHIEF FCAX08
Summary of Contents for LEGRAND CHIEF FCAX08
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation Video Wall Extenders Spanish Product Description German Product Description Portuguese Product Description...
- Page 2 125 lbs 250 lbs product. The information contained in this document is subject (56.7 kg) (113.4 kg) to change without notice or obligation of any kind. Legrand LCM2X1UP400 125 lbs 250 lbs makes no representation of warranty, expressed or implied, (56.7 kg)
- Page 3 Installation Instructions FCAX08/14/20 MODEL Max Weight Allowed Max Weight for EACH Display Capacity of Mounting System WMK-074 125 lbs 750 lbs (56.7 kg) (340.2 kg) WMK-075 100 lbs 900 lbs (45.4 kg) (408.2 kg) NOTE: The FCAX08, 14, 20 have no serviceable parts. NOTE: The UL Listed FCAX horizontal extension brackets may be used with UL Listed FCA2X1U, FCA3X1U, FCA3X1UP, LCM2X2UP, LCM3X2UP,WMK-073, WMK-074, WMK-075, LCM3X1U, LCM3X1UP, LCB2X1U, LCB2X1UP (not included).
- Page 4 FCAX08/14/20 Installation Instructions DIMENSIONS FCAX08 4.00 4.00 101.6 101.6 5.38 136.5 1.27 32.2 1.00 25.4 DIMENSIONS: INCHES [MILLIMETERS] FCAX14 7.00 7.00 177.8 177.8 5.38 136.5 1.27 32.2 1.00 25.4 DIMENSIONS: INCHES [MILLIMETERS]...
- Page 5 Installation Instructions FCAX08/14/20 DIMENSIONS (continued) FCAX20 10.00 10.00 254.0 254.0 5.38 136.5 1.27 32.2 1.00 25.4 DIMENSIONS: INCHES [MILLIMETERS] LEGEND Tighten Fastener Phillips Screwdriver Apretar elemento de fijación Destornillador Phillips Befestigungsteil festziehen Kreuzschlitzschraubendreher Apertar fixador Chave de fendas Phillips Serrare il fissaggio Cacciavite a stella Bevestiging vastdraaien Kruiskopschroevendraaier...
- Page 6 FCAX08/14/20 Installation Instructions TOOLS REQUIRED FOR INSTALLATION 1/8" PARTS B (6) #10-24 x 1 1/2" A (2) [extender bracket] C (1) 1/8"...
- Page 7 Installation Instructions FCAX08/14/20 Assembly And Installation Assemble video wall mount according to installation instructions up to the point of installing displays to rails. x 2 (per extender being installed) Remove ends from rails by removing two screws holding ends to rails. (See Figure 1) Use three #10-24 x 1 1/2"...
- Page 8 P +31 (0) 495 580 852 F +31 (0) 495 580 845 Asia Pacific A Office No. 1 on 12/F, Shatin Galleria 8800-002392 Rev01 18-24 Shan Mei Street 2021 Legrand Fotan, Shatin, Hong Kong www.legrandav.com P 852 2145 4099 05/2021 F 852 2145 4477...
