Operation and Maintenance Manual
HP6-606
Foot
Control
!
For Your Safety:
Read this Manual before operating your Foredom Micromotor Power Tool.
Always wear eye protection while using the Foredom Micromotor Handpiece.
Do Not Submerge Handpiece in Liquids!
K.1040
High Speed Rotary Brushless Micromotor
HP6-933
Cradle
HP4-417 Control
H.MH-140
Handpiece
Advertisement
Table of Contents
Related Manuals for FOREDOM K.1040
Summary of Contents for FOREDOM K.1040
- Page 1 Operation and Maintenance Manual HP6-606 HP4-417 Control Foot Control HP6-933 H.MH-140 Cradle Handpiece For Your Safety: Read this Manual before operating your Foredom Micromotor Power Tool. Always wear eye protection while using the Foredom Micromotor Handpiece. Do Not Submerge Handpiece in Liquids!
- Page 2 SAFETY INSTRUCTIONS: A Micromotor Handpiece is a high speed rotary power tool which can be dangerous and cause serious injury if it is not used properly. • ALWAYS wear proper eye and face protection. • WEAR a dust protector to prevent the inhalation of harmful dust or debris from grinding, carving or other •...
- Page 3 OPERATING INSTRUCTIONS Be sure the On/Off Power Switch on back lights up when you are ready to work. The switch on the back must be in the ON position for the handpiece to run in any setting. Always turn the Dial to ‘0’ and On/Off Switch to the Off position when not in use. FORWARD/REVERSE MODE: With the Speed Dial at ‘0’, select the handpiece rotation / Press To Run...
-
Page 4: Changing Accessories
NOTE: CAUTION: Never run the handpiece There are 2 DOTS on the metal ring – one will line up with the Unlock symbol and when the collet is open or in the the other dot will line up with the Lock symbol intermediate position. - Page 5 INSTALLING/CHANGING COLLETS Accessory Collet removed Nosecone Nosecone Wrench Wrench Turn off the power switch with the collet in 5. To install the collet, first, remove the Nose- the Locked or closed position. cone Wrench. Make sure one of the dots on 1.
-
Page 6: Maintenance
HP6-993 Collet Wrench Great way to use smaller diameter shank accesso- ries without changing the collet. Available from your HP6-933 Handpiece Cradle favorite Foredom dealer or: HP6-610 Handpiece Holder www.foredom.net HP6-101 Fuse GDB 5 Amp, 250V, 5mm x 20mm HP6-117B Collet for 1/8”... -
Page 7: Error Codes
The green (or green and flammable vapors are present. yellow) conductor in the cord is the grounding wire. Store your Foredom power tools in a DRY, Never connect the green (or green and yellow) wire clean, dust-free area, and out of the reach to a live terminal. -
Page 8: Repair Services
Limited Warranty Foredom warrants its product to be free of defects in material or work man ship for a period of two years after purchase. Blackstone Industries, LLC d/b/a Foredom Electric Company warrants, to the original purchaser only, that its products will be free from defects in material or workmanship for the applicable period of time indicated above following the purchase date.
