ASSEMBLY MANUAL
AND USER GUIDE
Piper Turbo Arrow IV
PA-28T IV
By 3D AEROWORKS

Advertisement

loading
Need help?

Need help?

Do you have a question about the Piper Turbo Arrow IV and is the answer not in the manual?

Questions and answers

Related Manuals for 3D AEROWORKS Piper Turbo Arrow IV

Summary of Contents for 3D AEROWORKS Piper Turbo Arrow IV

  • Page 1 ASSEMBLY MANUAL AND USER GUIDE Piper Turbo Arrow IV PA-28T IV By 3D AEROWORKS...
  • Page 2 OVERVIEW: This replica of the famous Piper arrow IV is designed for quick and easy construction and printed using light weight PLA (LW-PLA). For best results the canopy should be printed with clear PLA The motor mount and propeller assembly in regular PLA. Designed to suit the 1806 2300kv outrunner on a 2 or 3 blade (5x5) propeller.
  • Page 5 REQUIRED TOOLS: KNIFE LIGHTER SANDPAPER (MEDIUM GRIT) PLIERS CA GLUE SCREW DRIVERS FILE OR RASP DRILL 1mm, 2mm, 3mm bits REQUIRED COMPONENTS: X1 1806 2300KV MOTOR (or similar) X1 6AMP or 15AMP ESC X1 800MAH 2S LIPO OR SIMILAR X4 3.7G MICRO SERVO X1 5x5 PROPELLER BAMBOO SKEWERS 3MM HEAT SHRINK TUBE 3mm...
  • Page 6 ASSEMBLY INSTRUCTIONS After all parts have been printed, some may require to be cleaned as LW-PLA is prone to stringing. Do this by gently sanding back the rough sections with a file, sandpaper or blade until the surface is smooth. All faces which are to be glued to other parts need to be given a light sanding (scuff the surface) to assist with glue adhesion.
  • Page 7 Cut 15mm sections of skewer and place into alignment holes in the fuselage sections. NOTE - It may be required to open up the holes a small amount if the fit is too tight. Do this by using a 3mm drill bit. Gently spin it in reverse as you insert it into the hole. This will ensure the bit does not tear the print.
  • Page 8 From part “fuse 3” remove the inner section of the lead tunnel with a knife or heated metal rod to allow the servo lead for the aileron to pass through. (refer section marked in red) From fuse 4, remove the section marked in red for the elevator pushrod connecting the bellcrank to the elevator control arm.
  • Page 9 INSTALLING THE ELEVATOR DRIVE -Cut a 15mm section of 3mm bamboo skewer and test fit it in the bellcrank seat located inside fuse 4. Trim as required to obtain a good fit. Once happy with the fit, cut the same length of 3mm carbon.
  • Page 10 Fit the elevator bellcrank to fuse 4 with a small amount of hot glue as indicated below. Glue fuse 4 to the remaining fuse sections. Glue the “Vertical stabilizer lower” section to the fuse using the 3mm skewer as a guide. You may need to remove some material from the top of this section where the push rod is required to pass through.
  • Page 11 Glue the “elevator races” to the “Vertical stabilizer upper front” section. Be sure that the back edge of the race is square with the “Vertical stabilizer upper front” section. Test fit the 3mm carbon square tube in the elevator control arm. Make sure the fitment is tight.
  • Page 12 Cut a 100mm length of 3mm square carbon tube and test fit it to the tail section through the elevator control arm. Next feed the small “bearing liners” onto the carbon tube and press them into each race. The bearing liners and races should have a neat fitment with as little play as possible to reduce slop in the elevator.
  • Page 13 Note the correct neutral position of the elevator control arm relative to the elevator! Glue the sections of the wings together. Glue the wings to the fuselage NOTE – if using 3mm x 0.6mm carbon strip, now is the time to install it.
  • Page 14 Run a string through the aileron servo wire tube from the mount hole for the aileron servo to the wing root. Leave enough length so that you will be able to feed the string through the fuse later. Install all servos using a small amount of hot glue to secure them in place. The aileron servos mounting tabs will need to be trimmed.
  • Page 15 Place a drop of CA in the hinge slot of the control surface and insert the hinge. Be sure that the hinge is perpendicular to the control surface. Then bend the hinges to 90deg back and forward a few times to make sure they are appropriately loose. See below Glue the rudder and ailerons in place.
  • Page 16 RUDDER and ELEVATOR Install the magnets to both the fuselage and the canopy using CA. Place the motor mount in the slot provided on the firewall. Note the orientation of the mount with the small raised sections at the top. Secure it in place with two m2 x10mm screws into the lower holes only.
  • Page 17 Install the motor to the motor mount. The motor mount holes may need to be pre-drilled with a 3mm drill bit. Secure the motor mount with the final two m2 x10mm screws. The top two screws are first fed from the front of the aircraft through the cowling mounts, then through the firewall and finally through the motor mount.

  • Page 18: Front View

    The holes on either side of the motor slot are for the ESC wires to pass through into the battery compartment of the model. Fit the front cowling to the rear cowling using CA glue. Glue the front and rear section of the canopy together. ** IF NOT USING LANDING GEAR SKIP AHEAD TO STEP 42 ** Cut a 122mm section of 2mm wire and bend according to the diagram below.

  • Page 19: Side View

    SIDE VIEW Fit a 25-30mm foam wheel and secure with an M2 wheel stop collar.
  • Page 20 Insert the gear leg into the wing as pictured below. (different aircraft pictured below but the method is the same) Apply a small amount of hot glue to the outer bend of the leg (red circle on image above. This will hold it in place but also allow it to be removed if desired. Fit the wheel and secure it with a shaft collar.
  • Page 21 From the fuselage section near the nose, remove the over extrusion lump from the floor. (marked in red) Insert a length of 2mm wire through the nose leg hole and place the nose gear washers over the wire (small washer in the slot on the belly of the model and the larger washer glued to the floor of the battery bay.
  • Page 22 Cut a mm length of 2mm wire and bend according to the diagram below.
  • Page 23 Place an M2 wheel stop collar over the top of the nose gear leg and secure the collar with 17mm protruding out the top. The grub screw should also be aligned with the neutral forward position of the gear leg. Then insert the leg into the slot. Press an M2 wheel stop collar into the nose gear steering arm and fit the assembly over the nose gear leg.
  • Page 24 Connect up the rudder servo with the nose gear steering as pictured below. BALANCING AND CG Fit the battery using Velcro as required and balance the aircraft inverted on the CG marking points located 40mm aft of the leading edge at the wing root. RANGE OF TRAVEL: NORMAL FLIGHT: Elevator...
  • Page 25 LAUNCHING: It was found that the safest and most successful launch technique for this model was the under-arm style. The aircraft should be launched at approximately 20deg nose up at 50% to 75% power. Too steep and the aircraft will stall, too shallow and it will contact the ground. PARTS LINKS: X1 1806 2300KV MOTOR https://de.aliexpress.com/item/1005001967159663.html?spm=a2g0o.productlist.0.0.50e356a...
  • Page 26 X1 6 or 12 AMP ESC https://de.aliexpress.com/item/4000386815523.html?spm=a2g0o.productlist.0.0.1c473d223Ir Gp5&algo_pvid=9f2b4b45-10fa-4a99-be62-60fa498b1648&algo_exp_id=9f2b4b45-10fa-4a9 9-be62-60fa498b1648-0&pdp_ext_f=%7B%22sku_id%22%3A%2210000001581643929%22 %7D&pdp_pi=-1%3B7.51%3B-1%3BEUR+4.70%40salePrice%3BEUR%3Bsearch-mainSear X1 800MAH 2S LIPO OR SIMILAR (min weight = 35g) https://hobbyking.com/de_de/turnigy-800mah-2s-20c-lipo-pack-parkzone-compatible-pkz103 2.html?queryID=4b8d81603995f8a7c3e19502ea16c97e&objectID=18658&indexName=hbk_l ive_products_analytics X4 3.7G MICRO SERVO https://www.aliexpress.com/item/32965734270.html?spm=a2g0o.productlist.0.0.57d95e97a WNNAJ&algo_pvid=4824ea1c-06ed-43e8-b6c7-9737d1226dbe&algo_expid=4824ea1c-06ed -43e8-b6c7-9737d1226dbe-0&btsid=0bb0623415991458444523660eb7bd&ws_ab_test=sea rchweb0_0,searchweb201602_,searchweb201603_ X2 BAMBOO FOOD SKEWERS (3mm diameter) HEAT SHRINK TUBE 3mm https://hobbyking.com/en_us/turnigy-3mm-heat-shrink-tube-black-1mtr-1.html?queryID=c16c 094bb26b18e39fabcb12a93a96cb&objectID=46911&indexName=hbk_live_magento_en_us_ products...
  • Page 27 X2 x 200mm carbon strip 3mm x 0.6mm (optional) https://www.aliexpress.com/item/32576381076.html?spm=a2g0o.productlist.0.0.4e922cc3nR 6757&algo_pvid=500714e5-ce74-4e52-a1b0-e349cac3f595&algo_expid=500714e5-ce74-4e 52-a1b0-e349cac3f595-7&btsid=0bb0623e15991463277515177efc08&ws_ab_test=searchw eb0_0,searchweb201602_,searchweb201603_ m2 x10mm screws https://www.ebay.com.au/itm/400PCS-M2-M2-6-Pan-Head-Self-Tapping-Screws-Assorted-Kit -Stainless-Steel-Black/254399626404?hash=item3b3b663ca4:g:CLEAAOSwQLZdsqkd&frce ctupt=true M2 PUSH ROD (200mm MINIMUM LENGTH) (ONLY REQUIRED FOR FIXED GEAR OPTION) https://de.aliexpress.com/item/4000682811650.html?spm=a2g0o.9042311.0.0.27424c4dO7Q M2 WHEEL STOP COLLAR https://de.aliexpress.com/item/32367176766.html?spm=a2g0o.productlist.0.0.103f8bdcGo69 MK&algo_pvid=269e7532-755e-49b1-963f-c5fc23d25ace&algo_exp_id=269e7532-755e-49b 1-963f-c5fc23d25ace-2&pdp_ext_f=%7B%22sku_id%22%3A%2266304162649%22%7D&pd p_pi=-1%3B2.18%3B-1%3BEUR+5.01%40salePrice%3BEUR%3Bsearch-mainSearch X1 3mm SQUARE CARBON TUBE (100mm length) https://de.aliexpress.com/item/4001086603237.html?spm=a2g0o.9042311.0.0.27424c4d9tDz...
  • Page 28 Thank you for supporting us! We hope you enjoy many hours of flying your micro PA-28T IV. If you have any questions regarding the build process or set-up of your model, please contact us at: Aeroworks3d@outlook.com...
