CESSNA AIRCRAFT COMPANY
MODEL 680
INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG
Subject
Forward
Maintenance
Parts
Table of Contents
Lavatories
Aft Vanity ......................................................................................................... 25-40-01 ............... 25-40-02
Aft Bulkhead Closet ........................................................................................ 25-40-03 ............... 25-40-04
Toilet Installation ............................................................................................. 25-40-07 ............... 25-40-08
CONTENT
Original Issue

Advertisement

loading
Need help?

Need help?

Do you have a question about the 680 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cessna 680

Summary of Contents for Cessna 680

  • Page 1 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG Subject Forward Maintenance Parts Table of Contents Lavatories Aft Vanity ......................25-40-01 ....25-40-02 Aft Bulkhead Closet ..................25-40-03 ....25-40-04 Toilet Installation ..................... 25-40-07 ....25-40-08 CONTENT...
  • Page 2 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG AFT VANITY - MAINTENANCE General A. The aft vanity is located in the aft portion of the cabin on the left-hand side. The vanity has toekick and accent lighting, a water system, storage drawers, trash container and can contain electrical outlets.
  • Page 3 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG AFT VANITY WATER SYSTEM OPERATION - MAINTENANCE (10) Remove two (2) plugs, bolts and washers securing vanity to floorboard attach brackets and tag for reinstallation. (11) Move vanity inboard by first tilting top inboard, then move bottom inboard enough to disconnect electrical wiring and remove drain hose.
  • Page 4 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG AFT VANITY WATER SYSTEM OPERATION - MAINTENANCE Aft Vanity Water System Operation The vanity water system consists of a water tank, pump, water faucet and supply lines. The water tank is located in the bottom-center compartment of the vanity and is easily removed for filling.
  • Page 5 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG 16,24,25,26 16,24,25,27 1,4,22 1,4,22 8,9,10 DETAIL Page 25-40-02-01 Original Issue...
  • Page 6 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG Part Number Description Vendor 4479324-1 VANITY CABINET ASSEMBLY CLE106-01 LIGHT ASSY (5 ea) 0GZF3 CO35-32 SMALL OVAL BAR SINK GBKP C3-205P DOOR LATCH GRABBER (2 ea) 94222 DALCLP-100...
  • Page 7 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG 39,45 44,57 DETAIL Page 25-40-02-01 Original Issue...
  • Page 8 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG Part Number Description Vendor 4479324-1 VANITY CABINET ASSEMBLY - Continued 12589-39 RH SIDE TANK BRACKET 4W953 12614-1 2 GAL. WATER TANK 4W953 1281012-10 SLIDE ASSY - 10 INCH (4 ea)
  • Page 9 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG AFT BULKHEAD CLOSET - MAINTENANCE General A. The aft bulkhead closet is located in extreme aft portion of cabin. The aft bulkhead closet is built in three sections that are separated during removal/installation. It is necessary to first remove the mirror/veneer cover panels before closet can be split.
  • Page 10 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG AFT CLOSET - MAINTENANCE (14) Remove screws joining left-hand section to center section. A vertical row of six (6) screws is found along outside edge where left-hand section and center section meet. Remove screws and tag for reinstallation.
  • Page 11 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG AFT CLOSET - MAINTENANCE (17) Replace vanity switch bezel. (18) Replace toilet fascia and upholstery. (19) Replace aft vanity. (20) Replace aft dividers. (21) Replace cabin and lavatory PSU fascias.
  • Page 12 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG DETAIL Page 25-40-04-01 Original Issue...
  • Page 13 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG Part Number Description Vendor 4479557-1 AFT BULKHEAD CLOSET ASSY NAS451-52 BUTTON PLUG (2 ea) 4479061-18 CLOSEOUT PANEL (2 ea) 4479061-20 J-BOX ACCESS PANEL ASSY (Refer to Chapter 25 in the IPC)
  • Page 14 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG DETAIL Page 25-40-04-02 Original Issue...
  • Page 15 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG Part Number Description Vendor 4479543-3 AFT BULKHEAD CLOSET ASSY-LH 1435-M09-F16-632 HEX STANDOFF MALE/FEMALE (3 ea) 04729 4479010-15 SPRING PIN CLOSEOUT ASSY (Refer to Chapter 25 in the IPC)
  • Page 16 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG DETAIL Page 25-40-04-03 Original Issue...
  • Page 17 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG Part Number Description Vendor 4479472-7 LIGHT ASSY LTBLK-1X2-02 LIGHT BLOCK 0GZF3 LTBLK-1X3-01 LIGHT BLOCK (2 ea) 0GZF3 4479472-8 LIGHT MOUNTING PLATE NOTE: Parts not available as complete installations.
  • Page 18 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG DETAIL Page 25-40-04-04 Original Issue...
  • Page 19 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG Part Number Description Vendor 4479533-4 AIRSHOW 410-4000 MODULE 4479533-5 COVER PANEL ASSY 4479533-9 BRACKET ASSY 4479256-8 BRACKET ASSY 4479533-5 COVER PANEL ASSY 4479533-9 BRACKET ASSY 99K31.03 MAGNET (4 ea) LVTL 161.16.500...
  • Page 20 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG 4,8,11 3,10 DETAIL Page 25-40-04-05 Original Issue...
  • Page 21 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG Part Number Description Vendor 4479562-2 AFT BULKHEAD CLOSET-CENTER CABINET V7-1B17D8-263 MICROSWITCH 91929 106070-1 AC POWER CONTROLLER MCCI 106087-1 AC OUTLET ASSY 10 AMP MCCI 1435-M09-F16-632 HEX STANDOFF MALE/FEMALE...
  • Page 22 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG DETAIL Page 25-40-04-06 Original Issue...
  • Page 23 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG Part Number Description Vendor 4479115-10 A/S 410 EQUIP INSTL 106071-1 AIRSHOW INTERFACE MODULE MCCI 4879388-1 AIRSHOW GND PLATE ASSY NOTE: Parts not available as complete installations. When ordering plated parts, the plating number found in section 25-00-06 must follow the part number without a space.
  • Page 24 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG DETAIL Page 25-40-04-07 Original Issue...
  • Page 25 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG Part Number Description Vendor 4479115-11 CABIN MANAGEMENT EQUIPMENT INSTL 104001-1 AUTO CONFIG BOX MCCI 106028-2 SOLID STATE RELAY -CABIN MCCI 4948003-3 SLIM DC FAN ASSY (2 ea) NOTE: Parts not available as complete installations.
  • Page 26 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG DETAIL Page 25-40-04-05 Original Issue...
  • Page 27 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG Part Number Description Vendor 4419283-10 AIRSHOW 410 INSTL MS27039-0823 SCREW (4 ea) 4616024-80 AIRSHOW PLACARD ASSY 4948003-3 SLIM DC FAN ASSY 920055 AIRSHOW 410 DIU 59959 NOTE: Parts not available as complete installations.
  • Page 28 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG DETAIL Page 25-40-04-09 Original Issue...
  • Page 29 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG Part Number Description Vendor 4490048-1 AFT BULKHEAD CLOSET MOD 13224D0350E0390 PLATE 4W953 NOTE: Parts not available as complete installations. When ordering plated parts, the plating number found in section 25-00-06 must follow the part number without a space.
  • Page 30 C. Prior to removal of the toilet assembly, service toilet externally and empty it of any waste and water- chemical solution. For servicing instructions, refer to Chapter 12, Servicing, Externally Serviceable Flush Toilet, in the 680 Production Maintenance Manual. A placard with servicing instructions is located inside service panel door.
  • Page 31 (a) Remove O-ring and clean drain collar. (b) Pack O-ring grooves in drain collar with silicone grease. Refer to Chapter 12 - Servicing, Externally Serviceable Flush Toilet in production 680 Maintenance Manual. (c) Put O-ring into drain collar. (2) Remove toilet drain line plug and plate. Refer to Waste Line Plug Installation/Removal in Production 680 Maintenance Manual.
  • Page 32 (16) Place toilet upper back cushion into place and press outboard to engage hook and pile fasteners. (17) Service toilet, Refer to Chapter 12 - Servicing, Externally Serviceable Flush Toilet in Production 680 Maintenance Manual. (a) Remove ground service unit.
  • Page 33 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG TOILET INSTALLATION - MAINTENANCE (3) Pull Cable and Tank Dump Test. (a) To drain water, toggle the push to open lever on the upper edge of the waste drain valve to open inner waste drain flapper valve.
  • Page 34 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG DETAIL Page 25-40-08-01 Original Issue...
  • Page 35 CESSNA AIRCRAFT COMPANY MODEL 680 INTERIOR MAINTENANCE MANUAL AND ILLUSTRATED PARTS CATALOG Part Number Description Vendor 4479045-33 TOILET FASCIA & SEAT ASSY 4479045-25 HINGE ANGLE ASSY 4479045-27 PANEL SUPPORT 4479045-3 FWD LOWER BRACKET 4479045-30 ANGLE 4479045-31 TOILET LID 4479045-32 TOILET SEAT PANEL & FASCIA...
