EPSON OPOS ADK MANUAL
APPLICATION DEVELOPMENT
GUIDE
POSPrinter (TM-J7200/ TM-J7700)
Version 3.00 Feb. 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TM-J7200 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Epson TM-J7200 Series

Summary of Contents for Epson TM-J7200 Series

  • Page 1 EPSON OPOS ADK MANUAL APPLICATION DEVELOPMENT GUIDE POSPrinter (TM-J7200/ TM-J7700) Version 3.00 Feb. 2019...
  • Page 2 (3) Comments and notification of any mistakes in this documentation are gratefully accepted. (4) This software cannot be used with other equipment that the specified. (5) EPSON will not be responsible for any consequences resulting from the use of any information in this documentation. Trademarks Microsoft®, Windows®, Visual Basic®...

  • Page 3: Table Of Contents

    Version 3.00 Feb. 2019 Contents SECTION 1. INTRODUCTION ..................1 SECTION 2. DETAILS ON SETTINGS ................2 2.1 References of Firmware Versions ................2 2.2 Settings of DIP Switches ..................2 2.3 Port Information ....................... 2 2.4 Device Settings ......................3 2.4.1. Usable Device Specific Settings................ 3 2.4.2.

  • Page 4: Section 1. Introduction

    The generic term for TM-J7200,TM-J7700 are also referred to as TM-J7x00. Compatibility mode The compatibility mode for upward compatibility was added in OPOS Ver2.60. For the details of the compatibility mode, please refer to “EPSON OPOS ADK MANUAL APPLICATION DEVELOPMENT GUIDE Compatibility Mode”. APPLICATION DEVELOPMENT GUIDE...

  • Page 5: Section 2. Details On Settings

    Version 3.00 Feb. 2019 Section 2. Details on Settings This section describes connection configurations and how to make the settings for the TM-J7x00 printers. 2.1 References of Firmware Versions Refer to the release notes (Relnote.txt). 2.2 Settings of DIP Switches Not applicable 2.3 Port Information 1) Port information when using USB port...

  • Page 6: Device Settings

    2.4.1. Usable Device Specific Settings For the TM-J7x00, the following Device Specific Settings are settable by the SetupPOS utility. For the detail, please refer to the Section 2 of “EPSON OPOS ADK MANUAL APPLICATION DEVELOPMENT GUIDE POSPrinter (TM Series)” Settings...

  • Page 7: Paper Width Setting

    Version 3.00 Feb. 2019 2.4.2. Paper Width Setting models support following paper width. After adding TM-J7200,TM-J7700 by the SetupPOS utility, open the “Device Specific Settings” dialog box. In the “Paper” tab the paper width could be selected. The settable paper widths are as follows: 76.0 mm [480 dots] 82.5 mm [512 dots] 69.5 mm [432 dots]...

  • Page 8: Section 3. Function Details

    Version 3.00 Feb. 2019 Section 3. Function Details This section describes the functions of the printers in details. Supplementary explanation of the parts not described in detail in the "UPOS" is also given here. 3.1 Property Set Values and Default Values The following explanation is about the property set values and the default values.
  • Page 9 Version 3.00 Feb. 2019 CapRecLeft90 TRUE CapRecItalic FALSE CapRecEmptySensor TRUE CapRecDwideDhigh TRUE CapRecDwide TRUE CapRecDhigh TRUE CapRecColor PTR_COLOR_PRIMARY CapRecCartridgeSensor PTR_CART_REMOVED PTR_CART_EMPTY PTR_CART_NEAREND PTR_CART_CLEANING CapRecBold TRUE CapRecBitmap TRUE CapRecBarCode TRUE CapRec2Color FALSE CapRecPresent TRUE CapSlpUnderline TRUE CapSlpRotate180 TRUE CapSlpRight90 TRUE CapSlpNearEndSensor TRUE CapSlpLeft90 TRUE...

  • Page 10: List Properties

    Version 3.00 Feb. 2019 3.1.2. List Properties The List Properties are explained in the following. List Property Settings CharacterSetList “997” JrnLineCharsList “” RecLineCharsList “42,56” / “46,64" (When 82.5 mm is set) RecLineCharsList “40,53” / "43,60" (When 76 mm is set) RecLineCharsList “36,48”...

  • Page 11: Width And Height Properties

    Version 3.00 Feb. 2019 3.1.3. Width and Height Properties The width and height properties are explained in the following. Property Settings Default Maximum Minimum Value value [dot] value [dot] RecLineSpacing JrnLineSpacing SlpLineSpacing SlpLineHeight [dot] 24,17 RecLineHeight [dot] 24,17 JrnLineHeight [dot] SlpLineWidth [dot] (TM-J7200) 576 (TM-J7700) 960...
  • Page 12 Version 3.00 Feb. 2019 SlpSidewaysMaxChars (TM-J7200) 61, 66 (When Font A is selected) (TM-J7700) 36, 40 SlpSidewaysMaxChars (TM-J7200) 81, 92 (When Font B is selected) (TM-J7700) 48, 55 SlpMaxLines X : No settings Memory SW8-7 is set to ON. Depends on PageMode in “Device Specific Settings” of the SetupPOS utility It can be changed by the settings of the RecLineSpacing or the character height.

  • Page 13: Common Property Strings

    Version 3.00 Feb. 2019 3.1.4. Common Property Strings The Device information properties are described below. DeviceName DeviceDescription TM-J7200U EPSON TM-J7200U POS Printer TM-J7700U EPSON TM-J7700U POS Printer TM-J7200E EPSON TM-J7200E POS Printer TM-J7700E EPSON TM-J7700E POS Printer I/F indicate the connected interface.

  • Page 14: Pagemode Print Properties

    Version 3.00 Feb. 2019 3.1.5. PageMode Print Properties The Device information properties are described below. TM-J7200 Station Property Receipt Slip PageModeArea (82.5mm)“512”, “832” “576”, “736” (76.0mm)“480”, “880” (69.5mm)“432”, “984” (57.5mm)“360”, “1176” PageModeDescriptor BM/BC/BMR/BCR BM/BC/BMR/BCR TM-J7700 Station Property Receipt Slip PageModeArea (82.5mm)“512”, “832”...

  • Page 15: Methods

    Version 3.00 Feb. 2019 3.2 Methods The following explanation is about supported/unsupported Methods, and the detailed information. Compatibility with the Method Supported/Unsupported PageMode printing PrintNormal PrintTwoNormal PrintImmediate PrintBarCode PrintBitmap PrintMemoryBitmap CutPaper (1~100: One point remains uncut) MarkFeed ChangePrintSide ValidateData TransactionPrint SetLogo SetBitmap RotatePrint...

  • Page 16: Escape Sequences

    Version 3.00 Feb. 2019 3.3 Escape Sequences The following figure is about supported/unsupported Escape Sequences. Escape TM-J7200 Sequence Receipt Slip Compatibility with the PageMode printing 0~100 0~100 0~9999 0~9999 0~ approx. 50 cm 0~ approx. 50 cm #rF Maximum [inch] 0~65535 0~65535 !rvC...
  • Page 17 Version 3.00 Feb. 2019 Escape TM-J7700 Sequence Receipt Slip Compatibility with the PageMode printing 0~100 0~100 0~9999 0~9999 0~ approx. 50 cm 0~ approx. 50 cm #rF Maximum [inch] 0~65535 0~65535 !rvC !tbC !tpC #stC !stC *#dL O : Supported X : Unsupported Numbers: Settable range Regardless of the PageModeHorizontalPosition property setting, center or right adjust what is to...
  • Page 18 Version 3.00 Feb. 2019 be printed based on the PageModePrintArea property setting in the horizontal direction. APPLICATION DEVELOPMENT GUIDE POSPrinter (TM-J7200/ TM-J7700)

  • Page 19: Printable Barcode Type

    Version 3.00 Feb. 2019 3.4 Printable Barcode type The TM-J7x00 models allow the following barcode types. • Code 128 • Code 128 Parsed • Code 93 • Codabar • • Code 39 • JAN 13 (EAN 13) • JAN 8 (EAN 8) •...

  • Page 20: Printing Positions

    Version 3.00 Feb. 2019 3.7 Printing Positions The TM-J7x00 models support the function for setting printing position. Function Receipt Left margin Printing Position O : Supported X : Unsupported When the left margin setting function is supported, it is possible to specify the horizontal printing position of the bitmap or barcode by dots unit.

  • Page 21: Electronic Logo Function (Nvram)

    To print image files registered with NVRAM, please use the either of the following DirectIO: PTR_DI_FLASH_BITMAP PTR_DI_FLASH_BITMAP2. Please refer to the corresponding part of the Section 4 of “EPSON OPOS ADK MANUAL APPLICATION DEVELOPMENT GUIDE POSPrinter (TM Series)” for detail. The available NVRAM sizes are as follows: TM-J7x00 :393216 bytes.

  • Page 22: Maintenance Counter

    Version 3.00 Feb. 2019 3.10 Maintenance Counter The TM-J7x00 models feature a maintenance counter function for retaining an operation log of the printer. The following chart shows the available maintenance counters for the TM-J7x00. Counter number Counter Counter Unit Max. Value Hexadecimal Type Number of line feeds...

  • Page 23: Ocr-B Font Printing

    Version 3.00 Feb. 2019 interruption. The recovery processing restores the printer to the condition it was in before the power was turned off. 3.12 OCR-B Font Printing The FontTypefaceList property is guaranteed correct after the device is claimed. The TM-J7200,TM-J7700 can switch to the OCR-B font using the Escape sequence.

  • Page 24: Output Without Flow Control On The Usb/Ethernet Interfaces

    Version 3.00 Feb. 2019 3.13 Output without Flow Control on the USB/Ethernet Interfaces The TM-J7x00 models support outputting without flow control on the USB/Ethernet interfaces. APPLICATION DEVELOPMENT GUIDE POSPrinter (TM-J7200/ TM-J7700)

  • Page 25: Section 4. Warnings

    Version 3.00 Feb. 2019 Section 4. Warnings This section describes precautions in use of TM-J7200,TM-J7700. Due to hardware limitations and the position of the Slip, it is not possible to change the printing side and then search for the position where printing should start.
