FM - 38
Assembly Directions for
Double Cozi-Back Glider
Package contents
2
Bases
1
Back
1
Seat
1
Hardware Package
2
Arms with Legs
2
Cross Supports
4
Stops
1
Glider Bracket Package
1
Double Gliders
#PCTG2400, #PZTG2400
Double Comfo-Back Glider
2
1/4 " x 41/2 " Carriage Bolts
2
1/4 " x 31/2 " Carriage Bolts
7
1/4 " x 3" Carriage Bolts
8
5/ 1 6" x 21/2 " Carriage Bolts
8
5/ 1 6" Lock Nuts
8
5/ 1 6" Flange Nuts
18
1/4 " Flange Nuts
4
5/ 1 6" Acorn Nuts
4
Glider Brackets
2
3
Use to measure bolts
Hardware Package
4
5
tools needed:
Hammer
7/16" Wrench
1/2 " Wrench
CORRECT
INCORRECT
Firmly tap bolts into pre-drilled
holes before tightening.
Advertisement
Related Manuals for Outdoor Furniture Plus Double Cozi-Back Glider
Summary of Contents for Outdoor Furniture Plus Double Cozi-Back Glider
- Page 1 FM - 38 Assembly Directions for Double Gliders #PCTG2400, #PZTG2400 Double Cozi-Back Glider Double Comfo-Back Glider Package contents Hardware Package tools needed: Hammer Bases 1/4 " x 41/2 " Carriage Bolts 7/16" Wrench Back 1/4 " x 31/2 " Carriage Bolts 1/2 "...
- Page 2 FM - 39 Assembly Directions for Glider Chair 1/4 " x 41/2 " Carriage Bolt STEP #1 - Fasten the Arm and Leg Assembly to the Seat and Back using 3- 1/4 " Carriage Bolts. Using a hammer, fi rmly tap the Bolts until they are fl ush with the poly surface.
- Page 3 FM - 40 Assembly Directions for Glider Base STEP #1 - Fasten the two Cross Supports to the Base using 8- 1/4 " x 2" Carriage Bolts and 8- 1/4 " Flange Nuts. 1/4 " x 2" Carriage Bolts STEP #2 - Attach the four Glider Stops to the Base using 4- 1/4 "...
- Page 4 FM - 41 Assembly Directions for Glider Chair and Base STEP #1 - First slide the Glider Base Glider Bracket Diagram underneath the Glider Chair, ensuring the correct end of the ⁄ " Acorn Nut base is pointed forward (see photo).
