Outdoor Furniture Plus Vinyl A-Frame Assembly Directions

FM - 84
Assembly Directions for
Leg/Top Beam
1/4" x 4"
Lag Bolts
1/4" x 4"
Lag Bolts
1/4" x 4" Lag Bolts
! To avoid personal injury or
damage to your A-Frame,
assembly requires two people.
Package content
1 Top Beam 2 Long Leg Braces
4 Legs 4 Top Braces
2 Short Leg Braces 1 Hardware Package
1
Vinyl A-Frame
#VAF920
See
⁵⁄ 1 6" x 51/2" Machine Bolts " x 51/2" Machine Bolts " x 51/2" Machine Bolts
Inset
Short Leg
Brace
2 ⅜" x 7" Machine Bolts
2 ⁵⁄ 1 6" x 51/2" Machine Bolts
20 1/4" x 4" Lag Bolts
4 ⅜" Washers
2 ⅜" Nuts
2
3
Use to measure bolts
Hardware Package
2 ⁵⁄ 1 6" Washers
2 ⁵⁄ 1 6" Flange Nuts
20 1/4" Washers
2 ⅜" NY Glides
2 Vinyl Hole Plugs
4 5
Leg/Top Beam
Inset
⅜" x 7"
Machine Bolt
tools needed:
Hammer, 1/2" Wrench,
⁷⁄ 1 6" Wrench, ⁹⁄ 1 6" Wrench,
& Screw Gun
CORRECT INCORRECT
Firmly tap bolts into pre-drilled
holes before tightening.
