Summary of Contents for Lennox R22
- Page 1 APPLICATION GUIDE • Heat pump • Cooling Capacities of 8 a 13 kW FLOOR STANDING...
-
Page 2: Installation
VERTICAL FLOOR SPLIT. HEAT PUMP R22 HEAT PUMP UNIT Cooling capacity Heating capacity Cooling mode power input Heating mode power input Current Cool Heat Voltage: 50 Hz Indoor U. air flow (Height) Compressor Sound level Indoor U. Outdoor U. Bevel coupling pipe... -
Page 3: Features And Specifications
Features and Specifications Features Designed for cooling and heating Super energy efficiency Micom control Whisper quiet operation Wireless remote control Specifications Air Outlet Vent Remote Signal Receptor Air Inlet Vent Removable air filter Anti-Bacteria filter 3 minutes delay circuit Auto restart Air Inlet Vent (Rear) Air Outlet... - Page 4 Features of the Remote Control- Door Closed 10 12 13 14 DOOR ROOM TEMP SET TEMP (Heat Pump Model) START/STOP BUTTON Operation starts when this button is pressed and stops when the button is pressed again. OPERATION MODE SELECTION BUTTON Used to select the operation Mode.
- Page 5 Auto Airflow Direction Control Button • The vertical louvers swing left and right. • The horizontal louvers can be set by hand. Heating Button (Heat Pump Model Only) Auto Mode Operation Button (Cooling Model Only) Soft Dry Operation Button Indoor Fan Operation Button (Cooling...
-
Page 6: Remote Control Preparation
Remote Control Preparation How to mount onto a wall Use the screws to secure the holder to the wall or attach the holder side of indoor unit. To insert the remote control to the holder. Insert How to insert batteries Remove the cover from the back of the remote controller. -
Page 7: Air Conditioner Operation
• Each time the Fan speed Button is pressed, the Fan speed is shifted in the arrow direction. DOOR ROOM TEMP SET TEMP Cooling Operation DOOR ROOM TEMP SET TEMP Heating + E/Heater Operation (model only with Electirc heater) (Heat pump Model) DOOR ROOM TEMP SET TEMP ROOM TEMP Cooling Operation Soft Dry Operation (Cooling Model) High... - Page 8 Cooling Operation Mode Press the Start/Stop Button. Select Cooling Operation. Press the Operation Mode Selection Button. Press the Cooling Operation Button on the remote controller. Set the temperature lower than the room temperature. The temperature can be set within a range of 16°C~30°C by 1°C. Set the Fan Speed.
- Page 9 Soft Dry Operation Press the Start/Stop Button. Select Soft Dry Operation. Press the Operation Mode Selection Button. Press the Soft Dry Operation Button on the remote controller. Set the temperature lower than the room temperature. The temperature can be set within a range of 16°C~30°C by 1°C. During soft Dry Operation •...
- Page 10 Heating Operation Mode(Heat Pump Model Only) Press the Start/Stop Button. Select heating Operation. Press the Operation Mode Selection Button. Press the heating Operation Button on the remote controller. Set the temperature upper than the room temperature. The temperature can be set within a range of 16°C~30°C by 1°C.
- Page 11 Electric Heater Operation Mode(Option) Press the Start/Stop Button. Select heating+ E/heater Operation. Press the Operation Mode Selection Button. Press the Heater Operation Button on the remote controller.(When the unit operates in heating mode.) Set the temperature upper than the room temperature. The temperature can be set within a range of 16°C~30°C by 1°C.
- Page 12 Auto Operation Mode(Cooling Model Only) Press the Start/Stop Button. Select Auto Operation. Press the Operation Mode Selection Button. Press Auto Operation Button on the remote controller. Set the temperature upper than the room temperature. The temperature can be set within a range of 16°C~30°C by 1°C. During Auto Operation •...
- Page 13 Fan Operation Mode(Cooling Model Only) Press the Start/Stop Button. Set the Fan Speed. Airflow Direction Procedure Press the Start/Stop Button. (Operation will start when the button is pressed, and stop when the button is pressed again.) Note Always use the remote control to adjust the right/left airflow direction, manually moving the vertical airflow direction louver by hand could change the air conditioner.
- Page 14 OFF Timer Setting Procedure(OFF TIMER Setting, or CANCEL) Press the Start/Stop Button. Press the Timer Button. • If you press the button, the selected off timer is displayed as follows; • If you select ‘ When you finish the Off Timer setting, the Timer indicator lights off. ROOM TEMP SET TEMP During off-timer operation if you press the Timer Button, the rest time will be displayed.
- Page 15 Child Lock Operation Procedure Press the low and high temperature setting buttons simultaneously for 3 seconds. The unit will respond with beep. During Child Lock Operation Whenever you press any Button on Display Panel, it will immediately display “ ”, which means Display panel is Locked. All the Button on the indoor unit Display panel will not work.
-
Page 16: Care And Maintenance
Care and Maintenance CAUTION: Before performing any maintenance, turn off the main power to the system. During the season Cleaning of the air filters. Recommended about once every two weeks Remove the Air Filter. Take hold of the tab and pull slightly forward to remove the filter. -
Page 17: Troubleshooting Tips! Save Time And Money
Before you call for service... Troubleshooting Tips! Save time and money! Check the following points before requesting repairs or service... If the fault persists, please contact your dealer or service center. Case Does not operate. The room has a peculiar odor. - Page 18 info@lennoxpolska.pl w w w. L e n n oxe u ro p e . c o m AGU-FS-April 02...
