Summary of Contents for Airvia medical Origin 40
-
Page 2: Table Of Contents
Table of Content I – Package Contents .................3 II – Getting started ................4 III – Technology Overview .............. 14 IV – Technical Characteristics ............17 V – Maintenance ................18 VI – Troubleshooting ..............21 VII – Safety Instructions ..............22 VIII –... -
Page 3: I - Package Contents
I – Package Contents Main Unit Power plug (includes filter) Remote Take all items out of the box and unpack them. Verify that you have all the items listed above and that they all appear to be in good condition. Please contact us if any item is missing or appears damaged. -
Page 4: Getting Started
II – Getting started 1) Product Overview Touch outlet Control panel Poignées Air quality indicator PM2.5 Sensor Display Air inlet Bottom Power plug cover socket FRONT VIEW BACK VIEW Figure 1 – Main unit Please note that, contrary to the bottom cover, the top cover cannot be removed. - Page 5 2) Using the main unit without the remote Figure 2 – Top view of the unit Start by plugging the main unit into an electrical outlet. The unit will emit a single beep and the power button will turn red. This means that the unit is plugged in and on stand-by.
- Page 6 Automatic mode When in automatic mode, the main unit automatically adjust its speed depending on the indoor particle pollution (PM2.5) level. Note that the unit will not automatically turn on or off. However, this can be programmed using the Tuya Smart app, see section II.4. With the main unit on, press the button to turn the automatic mode on/off.
- Page 7 2.1) Main unit display screen Connectivity: This symbol will appear permanently on the screen once the pairing between the unit and the mobile app is complete. During initial pairing, this symbol will flash for 3 minutes (while the app scans for the device). Negative ion functions This symbol appears on the screen when the negative ion function (ionization) is activated...
- Page 8 Pollution level: This corresponds to the PM2.5 fine particle level, measured in μg/m3. PM stands for “Particulate Matter” and corresponds to fine particle pollution, a mix of solid particles and liquid droplets present in the air. Some particles are large enough to be visible with the naked eye, such as dust or smoke.
- Page 9 3) Using the main unit with the remote Before first use, open the battery compartment at the back of the remote control and remove the round plastic film on the battery. Once done, the remote will be operational. To control the air purifier, please point the remote towards the display screen of the unit.
- Page 10 Tuya Smart app. You can either create an account or select the “Try Now” option. Use the “Scan” function to scan the QR code of the ORIGIN 40 which is located on the label on the back of the device as well as below.
- Page 11 Once the device is added in the app, long press (5 seconds) the button on the top of the unit until your hear a beep from the unit. You will then see the Wi-Fi indicator flashing on the unit's display screen.
- Page 12 Once the purifier is added to the app, you can control it from your phone. Simply select the device to access pollution data and control buttons:...
- Page 13 4.3) Voice controls (Google Assistant and Alexa) You can connect Alexa or Google Assistant to the Tuya Smart app. You can either use the device name (AIRVIA ORIGIN 40) or simply “air purifier”. If you have trouble getting the instructions to work, try renaming the device to something simpler in the Tuya Smart app, such as “ORIGIN”...
-
Page 14: Technology Overview
It measures the volume of air cleaned in a given time. At over 420m3/h, the ORIGIN 40 is one of the best on the market. It can clean the air in a space of 40 m2 in just a few minutes. - Page 15 2) Filtration technologies AIRVIA Medical air purifiers combine 8 different filtration technologies to filter all toxic particles without rejecting any ozone. The filtration process consists of a multi-layer filter with 6 different technologies, a UV lamp, and an ionizer. You will find the description of each of these functions below.
- Page 16 AIRVIA Medical uses a particularly powerful version of this technology to generate 5 million particles per cm3 at outlet, with a 1m range. Negative ions are commonly associated with a feeling of well-being due to their presence in natural environments such as mountains, forests and waterfalls.
-
Page 17: Technical Characteristics
IV – Technical Characteristics DONNÉE CARACTÉRISTIQUES Speed 1/Sleep Mode = 100; Speed 2 = 210; Speed 3 = CADR 330; Speed 4 = 420 Speed 1/Sleep Mode = 43 ; Speed 2 = 51 ; CADR HCHO Speed 3 = 95 ; Speed 4 = 100 HCHO “High Efficiency”... -
Page 18: Maintenance
V – Maintenance Turn off and unplug your device before any maintenance operation. Aside from replacing the filter, non-professionals are not allowed to disassemble the device in order to avoid electric shock. 1) Cleaning the Air Purifier (once a month) −... - Page 19 3) Replacement of Filter (once a year) − To ensure proper performances, you should only buy filters provided by AIRVIA Medical. − The “Filter” is actually a composite filter made of several layers each made of a different filtration technology. Refer to the Technical Characteristics table for more information.
- Page 20 Step 3: Use both hands to slowly slide the old filter out. Step 4: Take the new filter out of its plastic bag and use both hands to slowly slide it in. Place the bottom cover back in place and rotate it clockwise to lock it.
-
Page 21: Troubleshooting
VI – Troubleshooting Issue Possible Cause(s) Solution(s) Main unit is not plugged Plug the main unit into an outlet Main unit does not work Bottom cover not fitted Make sure cover is secure correctly and filter is inserted Main unit emits This is normal with a new a lasting smell filter and is due to the... -
Page 22: Safety Instructions
Main unit does not react to Automatic mode is off Turn Automatic mode on changing air pollution levels Main unit is off Turn the main unit on Display does not Check that Night mode is off turn on Main unit is on button) Please contact us at support@airpurifier.co.uk if you cannot solve your issue. - Page 23 If the device will not be used for a prolonged period of time, please unplug it. − For your safety and the device’s guarantee, only use filters and affiliated accessories provided by AIRVIA Medical. − Do not use the main unit as a ventilation fan. −...
-
Page 24: Warranty
Medical at support@airpurifier.co.uk or fill out the form here: www.airpurifier.co.uk/pages/after-sales-service 1) Air purifier The AIRVIA ORIGIN 40 is under warranty for three (3) years, from the date of purchase against any hardware failure. If you have a hardware problem with your AIRVIA Medical air purifier, please contact our customer service or the AIRVIA Medical distributor who sold you the product. - Page 25 Medical. If it turns out that the item cannot be repaired, an exchange or credit will be offered. Shipping, return, and repair costs will be covered by AIRVIA Medical during the first two years of warranty. Beyond that, shipping, return,...
- Page 26 Return shipping costs are the responsibility of the customer unless the purchase is eligible for free return shipping as specified in the Terms of Sale. AIRVIA Medical has 14 days to issue the refund. AIRVIA Medical can offer a credit or an exchange that the customer may choose to accept or not accept.
- Page 27 In the event that the product is incomplete, damaged, or deteriorated by the purchaser, including during transport for the return of the product, the customer cannot exercise the right of withdrawal. The product must be shipped in its original packaging. The customer will have to print the return slip by his or her own means.
- Page 28 AIRVIA Medical Website: airpurifier.co.uk Email: info@airvialmedical.com Phone: +44 (0)20 3878 4379...
