Summary of Contents for Airvia medical CAR
-
Page 2: Table Of Contents
Table of Contents I – Introduction .................. 3 II – Installation ................... 6 III – Quick start guide ................ 9 IV – The AIRVIA Connect mobile app ........... 12 V – Our technology ................. 14 VI – Technical Characteristics ............16 VII –... -
Page 3: I - Introduction
I – Introduction 1) Package contents Main Unit Mount Charger (includes filter) User manual Pillow for headrest Take all items out of the box and unpack them. Verify that you have all the items listed above and that they all appear to be in good condition. - Page 4 2) Overview of product and accessories Air outlet Sensor input Digital display Air inlets (on three sides) Air outlet Clasps Filter cover Filter Power plug Partition board Rest button for filter status Figure 1 – AIRVIA CAR components...
- Page 5 Mounting hooks Back buckles Back straps Front strap Front buckles Power cable Cigarette lighter plug Power button Snap fasteners to attach the straps onto the pillow Figure 2 – Accessories...
-
Page 6: Installation
Step 1: Insert the unit into the mount as shown below. Please make sure to orient the unit in the right direction: the power plug should be facing the right side of the car. Make sure that the air outlets are facing up. - Page 7 Installing it on the passenger side will make it easier to plug the charging cable on the CAR. Pass the straps under the headrest. Back...
- Page 8 Step 5: Connect the charging cable to a cigarette lighter plug. Step 6: Connect the charging cable to the unit.
-
Page 9: Quick Start Guide
III – Quick start guide 1) Display Filter change indicator Negative ion function Air quality is ON indicator Fine particles (PM2.5) level Fan speed Humidity Automatic mode Temperature level Negative ion function: Off by default Turns off automatically when the level of fine particles (PM2.5) is below 10 μg/m Filter change indicator : when the filter needs to be changed, the following icon will appear :... - Page 10 Automatic mode: when it is activated, the following icon will be displayed: Note: for energy saving reasons, the purifier switches off automatically after 3 hours of continuous operation. If you want to continue using it, simply turn it back on manually. 1.1) Understanding pollution data To ensure the accuracy of the measurements, please allow the unit to run for one minute before reading the data.
- Page 11 To turn the unit on or off manually, simply long press the power button. Automatic mode is enabled by default, which means that the fan speed will adjust in real-time to the pollution level. To adjust the speed manually, simply short press the power button: Short press Short press Long press...
-
Page 12: The Airvia Connect Mobile App
IV – The AIRVIA Connect mobile app In order to control your AIRVIA CAR© from you smartphone, you can download our AIRVIA Connect companion app, available on both Android and iOS. You can turn automatic mode on and off, adjust the fan speed, and check pollution levels, among many other features. - Page 13 Access the app menu Once the air purifier is synchronized with the app, click here to access the control functions and the pollution data Synchronize your air purifier with the app Search for the Bluetooth signal of your air purifier Turn ON / OFF your air purifier Fine particle pollution rate (PM2.5) Change the speed level...
-
Page 14: Our Technology
At over 45 m /h, the AIRVIA CAR is one of the most power car air purifier on the market. It can clean the entire air volume in a car in just a few minutes. It comes with three different speeds to adapt to any pollution level. - Page 15 AIRVIA Medical uses a particularly powerful version of this technology to generate 5 million particles per cm3 at the outlet. Negative ions are commonly associated with a feeling of well-being due to their presence in natural environments such as mountains, forests and waterfalls.
-
Page 16: Technical Characteristics
VI – Technical Characteristics TYPE SPECIFICATIONS CADR Speed 1 = 15; Speed 2 = 32; Speed 3 = 45 CADR Speed 1 = 6.4; Speed 2 = 13.7; Speed 3 = 19.3 HCHO “High Efficiency” grade (η Purification Efficiency = 6.43 m /(W·h)) “High Efficiency”... -
Page 17: Maintenance
VII – Maintenance Turn off and unplug your device before any maintenance operation. Aside from replacing the filter, non-professionals are not allowed to disassemble the device in order to avoid electric shock. 1) Cleaning the Air Purifier (once a month) ... - Page 18 3) Remplacement du filtre (deux fois par an) To ensure proper performances, you should only buy filters provided by AIRVIA Medical. The “Filter” is actually a composite filter made of several layers each made of a different filtration technology. Refer to the Technical Characteristics table for more information.
- Page 19 Step 4: you now need to reset the Filter Step 3: Plug the change indicator. Use a needle-shaped unit back in and object to press the filter reset button. turn it on. The button will emit a click when pressed. Step 6: Turn off the unit and unplug Step 5: Take the new it a second time.
- Page 20 Step 7: Plug the unit Step 8: Verify that the Filter back in and turn it on. change indicator disappeared Step 9: Take the small cotton square set aside in step 5. Take it out of its packaging using tweezers rather than your fingers so as not to soil it.
-
Page 21: Troubleshooting
Make sure to only use the not work The wrong charging charging cable provided by cable is being used AIRVIA Medical This is normal with a new filter and is due to the New filter natural bamboo fibre. The smell will go away after a... - Page 22 This is normal in high- Air flow has dust environments or if decreased over Clean or replace the filter the filter is nearing the time end of its lifetime Main unit does not react to Automatic mode is off Turn Automatic mode on. changing air pollution levels Please contact us at support@airpurifier.co.uk if you cannot solve your...
-
Page 23: Safety Instructions
Do not move the main unit while it is operating. For your safety and the device’s guarantee, only use filters and affiliated accessories provided by AIRVIA Medical. The unit cannot filter carbon monoxide. Do not use in an environment where carbon monoxide is present or may leak, it could lead to burns or fires. - Page 24 3) Charging cable Please make sure to only use the charging cable supplied by AIRVIA Medical To avoid electric shock, fire or smoke, stop using the unit and unplug the power cord immediately in the following cases: ...
-
Page 25: Warranty
1) Air purifier AIRVIA Medical air purifiers are under warranty for three (3) years from the date of purchase against any hardware failure. If you have a hardware problem with your AIRVIA Medical air purifier, please contact our customer service or the AIRVIA Medical distributor who sold you the product. - Page 26 In the event of a complaint or material defect in the purifier during the first three years of the date of receipt, the parts are insured by AIRVIA Medical. If it turns out that the item cannot be repaired, an exchange or credit will be offered.
- Page 27 Return shipping costs are the responsibility of the customer unless the purchase is eligible for free return shipping as specified in the Terms of Sale. AIRVIA Medical has 14 days to issue the refund. AIRVIA Medical can offer a credit or an exchange that the customer may choose to accept or not accept.
- Page 28 AIRVIA Medical Website : www.airpurifier.co.uk Email: info@airvialmedical.com Phone: +44 (0)20 3878 4379...
