- Page 1 3PT HITCH LOG SPLITTER LSWX310, LSWX350 198331,198335 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives of others depend on it!
-
Page 2: Important Safety Information
INTRODUCTION The 20 Ton Vertical Hydraulic Log Splitter is an easy and efficient way to split lumber into firewood with just a pull of a lever. With a standard Cat 1 3-point attachment system, it is a breeze to transport and install. Integrating with your tractor's standard hydraulic system to produce 20 tons of force making it perfect for the toughest jobs. -
Page 3: For Your Protection
BE AWARE OF SAFETY ALERT WORDS DANGER: Indicates imminently hazardous practices. A situation that, if not avoided, will result in death or severe injury. The signal word is limited to the most extreme situation, typically for machine components that, for functional purposes, cannot be guarded. WARNING: Indicates a potentially hazardous situation that, if not avoided, could result in death or severe injury, and includes hazards that are exposed when guards remove. - Page 4 Understand procedure before doing work. Use proper tools and equipment; refer to • Operator’s Manual for additional information. Work in a clean, dry area • Lower the implement to the ground, put the tractor in park, turn off the engine, and •...
-
Page 5: Safety Sign Locations
SAFETY SIGN LOCATIONS The types of safety signs and locations on the equipment are shown in the illustration below. Good safety requires that you familiarize yourself with the various safety signs, the type of warning and the area, or particular function related to that area, that requires your SAFETY AWARENESS. OPERATIONS 4.3 MACHINE BREAK-IN Although there are no operational restrictions on the Wood Splitter when used for the first time, it is... -
Page 6: Pre-Operation Checklist
4.4 PRE-OPERATION CHECKLIST Before operating the machine and each time thereafter, the following areas should be checked off: 1. Use only with tractor under 100 horsepower. 2. Check that the machine is properly attached to the tractor. Be sure retainers are used on the mounting pins. -
Page 7: Field Operation
4.7 CONTROLS The 3-position lever controls the flow of oil to the cylinder. Move the lever toward the base and hold for the cylinder ram to extend and split the wood. Move the lever away from the base and place in detent to retract the cylinder ram. Release the lever, it will return to its centered neutral position when the pressure builds up enough to kick the lever out of detent at the end of the stroke. -
Page 8: Fluids And Lubricants
SERVICE AND MAINTENANCE 5.1.1 FLUIDS AND LUBRICANTS 1. Grease: Use an SAE multi-purpose high temperature grease with extreme pressure (EP) performance or SAE multipurpose lithium base grease. 5.1.2 GREASING 1. Use a hand-held grease gun for all greasing. 2. Wipe grease fitting with a clean cloth before greasing to avoid injecting dirt and grit. 3. -
Page 9: Checking Bolt Torque
BOLT TORQUE CHECKING BOLT TORQUE ENGLISH TORQUE SPECIFICATIONS Torque figures indicated above are valid for non-greased or non-oiled threads and heads unless otherwise specified. Therefore, do not grease or oil bolts or cap screws unless otherwise specified in this manual. When using locking elements, increase torque values by... - Page 10 WX310 PARTS DIAGRAM / EXPLODED VIEW...
- Page 11 WX350 PARTS DIAGRAM / EXPLODED VIEW...
- Page 12 ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY The use of any equipment, including this one, involves the potential risk of injury. Apart from any warranty claim that might be presented for a claimed defect in material or workmanship of the product, you accept and assume full responsibility for any and all injuries, damages (both economic and non- economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims,...
- Page 13 NEED HELP? CONTACT US FIRST. 1-800-605-7595 info@palletworks.com www.palletforks.com © 2021 Titan Brands...
