Titan Attachments LS3PT25 Operator's Manual

25 ton log splitter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
25 TON LOG SPLITTER
LS3PT25
198375
Operator's Manual
Read the Operator's Manual entirely. When you see this
symbol, the subsequent instructions and warnings are
serious follow without exception. Your life and the lives
of others depend on it!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LS3PT25 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Titan Attachments LS3PT25

Summary of Contents for Titan Attachments LS3PT25

  • Page 1 25 TON LOG SPLITTER LS3PT25 198375 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives of others depend on it!

  • Page 2: General Warnings

    GENERAL WARNINGS READ and UNDERSTAND this manual completely before using 3PT Hitch 25 Ton Log Splitter. Operator must read and understand all safety and warning information, operating instructions, maintenance, and storage instructions before operating this equipment. Failure to properly operate and maintain the log splitter could result in serious injury to the operator or bystanders.

  • Page 3: Hazard Signal Word Definitions

    HAZARD SIGNAL WORD DEFINITIONS This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. DANGER indicates imminently hazardous DANGER situation which, if not avoided, will result in death or serious injury.

  • Page 4: Controls And Features Identification

    CONTROLS AND FEATURES IDENTIFICATION Read this owner’s manual before operating the equipment. Familiarize yourself with the location and function of the controls and features. Save this manual for future reference. 1. Beam 2. Handle 3. Control Valve 4. Cylinder 5. Rear Support Leg 6.
  • Page 5 ASSEMBLY INSTRUCTIONS STEP 1: ATTACH SUPPORT LEGS 1. Attach front support leg (#2) to the main cross beam (#10) using hex bolt M12x100 (#4), flat washer Ø12 (#5) and nylon lock nut M12 (#6), loosely tighten the nut. 2. On the other side of the main cross beam (10) attach the rear support leg (#19) using hex bolt M12x90 (#18), flat washer Ø12 (#5) and nylon lock nut M12 (#6), loosely tighten the nut.

  • Page 6: Splitting Force And Cycle Time

    SPLITTING FORCE AND CYCLE TIME WARNING Splitting force is determined by cylinder size and the tractor PSI. The cycle time depends on the cylinder size and GPM’s that the tractor produces. Tractor should ideally produce 8-15 GPM at 1500 to 2500 PSI. Do not exceed 3200 PSI.

  • Page 7: Maintenance And Storage

    IMPORTANT: Leaving the valve in the “actuate” position at the end of the stroke may damage the pump. Always use extra care when splitting logs with unsquared ends. IMPORTANT: To extend the life of the hydraulic cylinder, avoid “bottoming out” the wedge plate to the foot piece.

  • Page 8: Specifications

    SPECIFICATIONS Ram Force: 19-25 Tons (*) Tractor Categories: CAT 1 & CAT 2 Hitch Tractor: 3 Point Cycle Time: 11.5 – 15 Sec Harden Steel Wedge: 8” Max. Log Length: 26” Hydraulic Cylinder: 4.13” x 24.5” Max. Pressure: 3200 PSI Valve: Auto Return Warranty:...
  • Page 9 PARTS DRAWING AND PARTS LIST...
  • Page 10 PARTS DRAWING AND PARTS LIST DRAWING NO. DESCRIPTION LSP25-00012-DX R Pin LTS25-01000 Front Support Leg LSP25-05000-DX Hitch Pin 9101-12100-DX8.8 Hex Bolt 12x100 9301-12000-DX Flat Washer Ø12 9206-12000-DX Nylon Lock Nut M12 LSP25-00006-DX Safety Pin A LSP25-00003-DX Spring 9404-03030-DX Cotter Pin 3x30 LTS25-03000 Main Cross Beam LSP25-00008-DX...
  • Page 11 Attach the log cradle to the beam with the Ø12 flat washer and M12 lock nut. LOG CRADLE Ø12 FLAT WASHER M12 LOCK NUT...
  • Page 12 ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY The use of any equipment, including this one, involves the potential risk of injury. Apart from any warranty claim that might be presented for a claimed defect in material or workmanship of the product, you accept and assume full responsibility for any and all injuries, damages (both economic and non- economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims,...
  • Page 13 NEED HELP? CONTACT US FIRST. 1-800-605-7595 info@palletworks.com www.palletforks.com © 2021 Titan Brands...
