- Page 1 CVT10 Fiber Converter Specifications...
-
Page 2: Change History
For rack mounting, two CVT10 devices, or one CVT10 device and a connecting piece can be combined into one assembly that is 1U in width. -
Page 3: Front Panel
If the input device has 8 or 16 Ethernet ports, the first 8 Ethernet ports of the CVT10 are available. If the input device has 10 or 20 Ethernet ports, all the 10 Ethernet ports of the CVT10 are available. If Ethernet ports 9 and 10 are found unavailable, they will be available after upgrading in the future. -
Page 4: Rear Panel
CVT10 Fiber Converter Specifications Name Description MODE The button to switch the device working mode The default mode is CVT mode. Only this mode is currently supported. CVT/DIS Working mode indicators Always on: The corresponding mode is selected. CVT: The fiber converter mode. OPT1 is the master port and OPT2 is the backup port. - Page 5 The Sending Card Has No Optical Ports Assembling Effect Diagram A single CVT10 device is half-1U in width. Two CVT10 devices, or one CVT10 device and a connecting piece can be combined into one assembly that is 1U in width.
-
Page 6: Specifications
CVT10 Fiber Converter Specifications Assembly of Two CVT10 Assembly of a CVT10 and a Connecting Piece The connecting piece can be assembled to the right or left side of the CVT10. Specifications Electrical Power supply 100-240V~, 50/60Hz, 0.6A Specifications Rated power consumption... -
Page 7: Notes And Cautions
CVT10 Fiber Converter Specifications Notes and Cautions Notes for Installation Caution: The equipment must be installed in a restricted access location. Attention: L'équipement doit être installé dans un endroit à accès restreint. When the product needs to be installed on the rack, 4 screws at least M5*12 should be used to fix it. The rack for installation shall bear at least 9kg weight. - Page 8 CVT10 Fiber Converter Specifications interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Others This is Class A product. In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures.
