Page 1: User Manual
Thunderview_V1 Video Processor User Manual Document Version V1.0.0 Document Number: NS160110174... - Page 2 Xi’an NovaStar Tech Co., Ltd. Statement You are welcome to use the product of Xi’an NovaStar Tech Co., Ltd. (hereinafter referred to as NovaStar). This document is intended to help you understand and use the product. For accuracy and reliability, NovaStar may make improvements and/or changes to this document at any time and without notice.
-
Page 3: Table Of Contents
4.4 Input Settings ............................... 6 4.5 Output Settings ............................7 4.6 Scaling ................................. 8 4.7 PIP ................................9 4.8 Splicing ................................ 9 4.9 Image Quality ............................. 10 4.10 Advanced Settings ............................ 11 4.11 Factory Reset ............................13 5 Web Control ..........................14 http://www.novastar.tech... -
Page 4: Overview
1 Overview Overview The Thunderview_V1 is a video processor developed by NovaStar based on the powerful FPGA processing platform. It is designed with various signal inputs, including 2 SDI, 1 DP, 1 CVBS, 1 VGA, 3 HDMI, 1 DVI, 1 HDBT and 1 S/PDIF. It supports input resolutions up to 4096x2160@60Hz and UHD input and output displays. -
Page 5: Hardware
Ethernet cable, it is required to visit 192.168.0.111 to configure the IP. ⑥ To display the PIP menu screen ⑦ Custom button: Users can set it to be the blackout, freeze or test function. ⑧ To display the scaling menu screen ⑨ USB: For MCU upgrade http://www.novastar.tech... -
Page 6: Rear Panel
SDI video source output DVI video source output HDMI HDMI video source output HDBT HDBT video source output Ethernet Quantity Function RJ45 Ethernet port: Connects to the upper computer. FPGA firmware update Power AC 100-240V, 50/60HZ AC power input ON/OFF Power switch http://www.novastar.tech... -
Page 7: Applications
Thunderview_V1 User Manual 3 Applications Applications Note: Before connecting other devices to the Thunderview_V1, please power off the Thunderview_V1 first. Figure 3-1 Application http://www.novastar.tech... -
Page 8: Operations
After the Thunderview_V1 is turned on, the home screen is shown as below. INPUT: Input source resolution OUTPUT: Output source resolution HDMI3: Currently used input source : PIP enabled − : PIP disabled − Scaling − : Scaling function enabled − : Scaling function disabled http://www.novastar.tech... -
Page 9: Main Menu
Figure 4-1 Main menu 4.3 Brightness Set the output display brightness which ranges from 0 to 100 and defaults to 50. 4.4 Input Settings Input settings include selecting an input source and setting the EDID of the input source. http://www.novastar.tech... -
Page 10: Output Settings
Output settings include setting the resolution and refresh rate of the output source, the aspect ratio and the synchronization mode of the output display. Figure 4-3 Output settings Output Resolution: 720x576p, 800x600p, 1024x768p, 1080x1920p, 1280x720p, 1280x768p, 1280x800p, 1280x1024p, 1360x768p, 1366x768p, 1400x1050p, 1440x900p, 1600x1200p, 1680x1050p, 1920x1080i, 1920x1080p, http://www.novastar.tech... -
Page 11: Scaling
Aspect Lock: Enable or disable the aspect lock function Zoom H: Horizontal width of the scaled display Zoom V: Vertical height of the scaled display H Offset: Horizontal position offset V Offset: Vertical position offset Scale Reset: Reset the parameters of scaling. http://www.novastar.tech... -
Page 12: Pip
Set the splicing mode and parameters. Figure 4-6 Splicing Splicing Zoom: Enable or disable the splicing function. Splicing Width: Number of screens that are horizontally spliced together Splicing Height: Number of screens that are vertically spliced together http://www.novastar.tech... -
Page 13: Image Quality
Advanced Enable: Enable Start X: 1920 Start Y: 0 Wall Width: 3840 Wall Height: 2160 4.9 Image Quality The Thunderview_V1 is designed with five modes of image quality. Users can also customize templates under the Custom menu item and save them. http://www.novastar.tech... -
Page 14: Advanced Settings
To modify a template, enter the Template Para menu item and select a target template. Then, press the knob to enter the screen of contrast, saturation and hue adjustment. 4.10 Advanced Settings Note: To exit the test pattern, you need to switch input sources. http://www.novastar.tech... - Page 15 Hardware Version: View the hardware version of the Thunderview_V1. Software Version: View the version of the web control page of the upper computer. Note: The IP address of Thunderview_V1 is a fixed one and it cannot be changed. http://www.novastar.tech...
-
Page 16: Factory Reset
Thunderview_V1 User Manual 4 Operations 4.11 Factory Reset Clear all setting data set by the users and reset the Thunderview_V1 to factory default settings. Figure 4-10 Factory reset http://www.novastar.tech... -
Page 17: Web Control
The main menu of the web control page includes the Inputs and Main Menu areas. In the Inputs area, you can switch the input sources. In the Main Menu area, you can set input sources, output source and other functions. http://www.novastar.tech... - Page 18 Thunderview_V1 User Manual 5 Web Control Figure 5-2 Main menu http://www.novastar.tech...
