UROVO SQ47 Quick Start Manual

RT40
SQ47
Quick Start Guide
3.01.200.10139

Appearance and Buttons

Scan engine
System LED
Scan LED
Flash
Rear camera
Touch screen
Loudspeaker
Battery
Keypad
Volume
PTT custom
up+/down
button
Scan button Scan button
Scan engine
POGO PIN
Type C Charging port
Package Contents
Device x 1 Battery x 1 Power adapter x 1 USB cable x 1
Quick Start Guide & Warranty Policy x 1

Unpacking Instructions

SIM Card, TF Card Installation Method

Take card out(as shown )
Gently press SIM card into the tray to secure it. Follow the prompt to
insert TF card into Memory card slot (as shown).
NANO SIM2
TFslot
SIM2
PSAM SIM1
PSAM
SIM1
Note：1、SIM1 support PSAM or MINI SIM1 。
2、SIM 2 support NANO SIM。

Battery Installation

Install the battery in the direction as show.
NOTE: Overexertion should be avoided when installing
or removing the battery.
Press the buttons on both sides
to remove the battery

Power Options

Power on: Press and hold the power button until device vibrates.
Shutdown: Press and hold the power button until the shutdown
prompt appears Click"Shutdown".
Forced restart: Press and hold the power button for 10 seconds.
Do not press the shutdown prompt. Device will restart.

USB Data Cable Charging

Connect one end of the USB cable to the adapter, and the other
end to the device. Charging cradle is recommended for convenient
charging.

PC Connections

Connect device to PC using the USB cable provided. If additional
driver is required, PC will automatiaclly download from internet.
Once the USB port has been connected, drag the notification bar
from the top of the screen to display the USB setting interface.
1) Tap this to activate developer menu shown.(Figure 1)
2) Tap this to activate USB preference menu shown.(Figure 2)
Figure 1 Figure 2
Select this option
to access device
storage.
This device
Select this option
to share the device
data with the
computer.
Choose this option
to transfer images.
Choose this option
for charging the
device.
Click this to switch on
debug mode
On Windows PC, go to"My Computer". Click on"Removable Disk"
to view and transfer device data.
