  • Page 1 Adit 3200 UICK TART UIDE Part Number: 002-0246-0010 Product Release: 1.6 September 2007...
  • Page 2 - electronic, mechanical, magnetic, optical, chemical, manual, or otherwise - any part of this manual or software supplied with the Adit 3200 for any purpose other than the purchaser’s personal use without the express written permission of Carrier Access Corporation.

  • Page 3: In This Guide

    Alarm/Status LEDs Web-Based Management Setting up a CLI Connection Log in Key Enabled Software Features Basic Configuration Setup Adit 3200 for access via Web-Browser Restore Factory Defaults Modify Default Admin User Configure Ethernet WAN Interface Configure Serial 1 as WAN UIDE...

  • Page 4: Unpacking And Inspection

    Maximum non-operating altitude: 40,000 ft. (12,192 m) Relative humidity (non-condensing) range: 0 to 95% WARNING! DESIGNED FOR DESKTOP USE ARE EXTREMELY SUSCEPTIBLE TO ELECTROSTATIC 3000 IS DESIGNED FOR WALL AND RACK MOUNTING ONLY DO NOT HANDLE T IS NOT Adit 3200 - Release 1.6...

  • Page 5: User Safety

    National Electrical Code. Installation The following are instructions for a compliant installation of the Adit 3200. Please note the following warnings, before installing the unit. For wall and rack mount instructions, use the links listed below to the appropriate section:...

  • Page 6: Compliant Installation

    3000 CLI Reference Manual, for detailed information. 9. To verify use the show version command. 10. Now you can proceed to provisioning the unit. See Basic Configuration on page 22 for information. Grounding the Unit ON PAGE Adit 3200 - Release 1.6...

  • Page 7: Wall Mounting

    2. Mount the unit to the wall using appropriate mounting screws (not included). Note: it is acceptable to mount on drywall with suitable anchor-type mounting screws. NOTE: The Adit 3000 must be mounted with the brackets on the top and bottom, as shown above. Adit 3200 - Release 1.6 Installation Back of unit...
  • Page 8 Note: Adit 3000 and wall mounting bracket are not assembled from the factory. Rack Mounting Tray 23 in rack Rack Mount Tray screws Mounting Ear Front 19 in rack Rack Mount Tray screws Front Mounting Ear Mounting Ear Adit 3200 - Release 1.6...
  • Page 9 Tray Slide 5. Slide the assembled piece (Adit 3000 and Tray Slide) onto the installed Rack Mounting Tray. 6. Secure the Tray Slide to the Rack Mounting Tray with the attached screws on the Tray Slide. Adit 3200 - Release 1.6...
  • Page 10 The Adit 3104, 3200, 3300 and 3400 Battery Backup (P/N 730-0132), is a wall-mount battery backup unit to provide up to 8 hours battery backup. Please see the Battery Backup User Manual for product information and installation instructions, which is provided with unit. Note: This is an optional feature. Adit 3200 - Release 1.6...

  • Page 11: Chassis Over View

    Chassis Overview Front (4) 10/100Base-T Ethernet (LAN) Back Ground Adit 3200 - Release 1.6 Alarm Status (1) DS1/E1 (WAN) Reset (E1-future) (1) 10/100Base-T Ethernet (WAN) Power/Battery/Status Chassis Overview RS-232 Management Port...

  • Page 12: Interface Connectors

    Interface Connectors Interface Connectors The following are the Adit 3200 interface connectors: Front of Adit (1) DS1 WAN port (RJ-48C). Note: E1 will be in a future release. (1) 10/100Base-T WAN port (RJ-45) (4) 10/100Base-T switched LAN ports (RJ-45) Back of Adit...

  • Page 13: Battery Connection

    Battery Connection The Adit 3000 Battery connection is provided for Battery Backup. See Adit 3104, 3200, 3300 and 3400 Battery Backup on page 8 for additional information. Adit 3200 - Release 1.6 PLEASE FOLLOW INSTRUCTIONS CAREFULLY Black = Ground (+)
  • Page 14 The pinouts are as follows: Pin Number Direction Description Outbound Carrier Detect Outbound Receive Data Inbound Transmit Data Inbound Data Terminal Ready Signal Ground Outbound Data Set Ready Inbound Request to Send Outbound Clear to Send Not connected Adit 3200 - Release 1.6...
  • Page 15 The LEDs are as follows (left LED only): State Green Yellow Flashing Green Flashing Yellow Flashing Red (Slow) Flashing Red (Fast) Adit 3200 - Release 1.6 Name Description Receive Ring Receive from DS1 network Receive Tip Receive from DS1 network Not connected...

  • Page 16: Reset Button

    The left LED shall show Link Status. Link Down Green Link Up Flashing Green Traffic on Link Yellow Collision status The right LED shall indicate Link Speed. 10 Mbit/sec, down or not connected Green 100 Mbit/sec Adit 3200 - Release 1.6...

  • Page 17: Alarm/Status Leds

    Minor Status Green Green Flashing Green/Yellow Yellow Yellow Flashing Adit 3200 - Release 1.6 Description No critical alarms present Critical alarms present. Critical alarms include: user-configured manor environmental inputs. No major alarms present Major alarm present. Major alarms include: user-configured manor environmental inputs, DS1 short, DS1 open, DS1 facility alarm, DS1 RAI, DS1 AIS, DS1 LOF, DS1 LOS, WAN fault, Ethernet fault and dead card alarms.

  • Page 18: Web-Based Management

    Log into the system (username and password). Enter the Privileged mode. Enter password for the Privileged mode. Enter the Configuration mode. Enable remote web admin. AME AND ASSWORD ARE SET TO THE DEFAULT SETTING IT IS Adit 3200 - Release 1.6...

  • Page 19: Setting Up A Cli Connection

    NOTE: For Adit 3200 CLI commands see the Adit 3000 CLI Reference Manual. This is a separate document and can be found on the CD that is provided with the product, or on the Carrier Access customer website.
  • Page 20 After successful connection, via telnet or HyperTerm, the user must login. Default Logins are: Login: admin Password: admin123 After successful login the prompt will be displayed as follows: Adit 3200> NOTE: It is recommended that you change your password from the default. Adit 3200 - Release 1.6...
  • Page 21 Key Enabled Software Features The Adit 3200 has additional features that are not provided on the base system. These features can be purchased with the product or added later as needed. These features are enabled via a Software Key (example: G.729). The number of keyed features may expand with the development of the product, therefore to see a list of current keyed features, or to purchase a key, contact Carrier Access Customer Service or Sales.

  • Page 22: Basic Configuration

    Configure Serial 1 as WAN Setup Adit 3200 for access via Web-Browser The following steps will configure the Adit 3200 to allow access to the Web Browser for configuration, through one of the 4 10/100Base-T LAN connections. Note: for LAN access, no additional configuration is required to access the Adit using the web browser.
  • Page 23 If the unit is not out-of-the-box, you may want to verify that the unit is set to defaults. Note: This will reset the IP address back to the default setting of 192.168.1.1. In the web-browser: Select Advanced from the Navigation bar Select Restore Defaults Select OK to restore defaults Adit 3200 - Release 1.6 Basic Configuration...
  • Page 24 For security purposes it is recommended that the Administrator User be changed from the default settings. Modify the Administrator User in the web-browser: Select Advanced from the Navigation bar Select Users icon Select Administrator, to open the profile. Adit 3200 - Release 1.6...
  • Page 25 Administrative Privileges. For users with other access levels, add a New User. Note: For security purposes, the password should be changed. You will be required to login again, if you have modified the User Profile that you are logged in with. Adit 3200 - Release 1.6...
  • Page 26 2. It is recommended that you disable/delete the Serial1 port. 3. Select (click) Ethernet 2 (WAN Ethernet) connection to configure. 4. Select the Enable button, to configure the WAN Ethernet up (or in-service). 5. Select the Settings button. Adit 3200 - Release 1.6...
  • Page 27 6. Set Internet Protocol to Obtain an IP Address Automatically, from the pulldown menu. This will enable the Adit 3200 as a DHCP Client. Leave the other fields to their default settings. 7. Select Apply to apply the new settings.
  • Page 28 Configure Serial 1 as WAN In the web-browser: 1. Select Network Connections from the Navigation bar. 2. Select Serial 1. 3. Select Settings button. 4. Set Network to WAN. 5. Select Apply to apply the new settings. Adit 3200 - Release 1.6...
