Installation & User Manual
Suitable for installation indoors and in indoor coastal areas.
The fan is suitable for installation in a pergola or outside in
a sheltered area protected from wind and rain.
·
POWER OUTLETS OR FIXED WIRING MUST BE
INSTALLED BY A LICENSED ELECTRICIAN
·
PERMANENT 240V POWER ON HANGER BRACKET.
ISOLATE POWER AT SWITCHBOARD BEFORE
SERVICING THE FAN
After installation, electricians must tick off all items on the
•
quick checklist and fill out their details towards the back of
this Installation and User Manual.
Isolation switch and wall plate required. To suit the
•
location and décor, these parts must be supplied by the
installing electrician.
ELECTRICIANS - TO PROTECT YOUR CUSTOMER'S WARRANTY, PLEASE READ
PAGE 2 OF THIS BOOKLET PRIOR TO THE INSTALLATION OF THIS PRODUCT.
Warranty Procedure*
For online warranty bookings visit: www.hunterpacific.com.au (24 hours, 7 days)
For technical advice call: 1300 360 280 (Monday to Friday from 9am to 5pm EST)
®
* Warranty only available within Australia
