Installation and User Manual
Suitable for installation indoors and in indoor coastal areas.
The fan is suitable for installation in a pergola or outside in
a sheltered area protected from wind and rain.
Isolation switch and wall plate required. To suit the location and décor
these parts must be supplied by the installing electrician.
CEILING FAN MUST BE INSTALLED
(NO OTHER PERSONS SHOULD ATTEMPT TO INSTALL THIS FAN)
*After installation, electricians must tick off all items on the
quick checklist and fill out their details towards the back of this
ELECTRICIANS - TO PROTECT YOUR CUSTOMER'S WARRANTY, PLEASE READ
PAGE 2 OF THIS BOOKLET PRIOR TO THE INSTALLATION OF THIS PRODUCT.
For online warranty bookings visit: www.hunterpacific.com.au (24hours, 7 days)
For technical advice call: 1300 360 280 (Monday to Friday from 9am to 5pm EST)
BY A LICENSED ELECTRICIAN
Installation Manual
Warranty Procedure*
* Warranty only available within Australia
®
Advertisement
Related Manuals for Hunter Pacific Intercept II
Summary of Contents for Hunter Pacific Intercept II
- Page 1 ® Installation and User Manual Suitable for installation indoors and in indoor coastal areas. The fan is suitable for installation in a pergola or outside in a sheltered area protected from wind and rain. Isolation switch and wall plate required. To suit the location and décor these parts must be supplied by the installing electrician.
- Page 2 Wall controls must only be types approved ® for use by Hunter Pacific International (b) The fan, light and bracket must be earthed. (c) Fan and light must be run from the same final circuit.
- Page 3 ® Installation & User Manual ® Parts List Intercept II without light Hanger Bracket Ceiling Canopy Screw Bracket Mounting Screw Ball Joint Pin Ball Joint Screw Ball Joint Down Rod Down Ceiling Canopy Rod Pin Screw Down Rod Short Screw Blade Motor Housing Blade...
- Page 4 ® Installation & User Manual ® Parts List - Intercept II with light (E27 Lamp Holders) Hanger Bracket Bracket Mounting Screw Ceiling Canopy Screws Ball Joint Pin Ball Joint Screw Ball Joint Down Rod Ceiling Canopy Down Rod Pin Down Rod Short Screw Blade Screw Motor Housing...
- Page 5 ® Installation & User Manual ® Parts List - Intercept II with CCT LED light (dimmable) Hanger Bracket Ceiling Canopy Bracket Mounting Screw Screws Ball Joint Pin Ball Joint Screw WARNING: Ball Joint Down Rod NOT REMOVE LED PLASTIC COVER. ONLY QUALIFIED Ceiling Canopy ELECTRICIANS...
- Page 6 ® Installation & User Manual IMPORTANT INFORMATION The table below contains information that can help you quickly identify the product you are installing. If you have any difficulties installing our product we recommend you to call our technical advice line on 1300 360 280 for advice. CODE SIZE FAN MODEL NAME...
-
Page 7: Installation Instructions
® Installation & User Manual Installation Instructions (Assembling the fan) Fig. 1 Fig. 2 Ø25mm Ø1-1/8” Fig. 3 Hanger Bracket Timber Nogging Fig. 4 1. Do not attempt to operate the fan (or optional light kit) with any wall control that is not approved by HPI for use with its fans. - Page 8 ® Installation & User Manual Installation Instructions (Assembling the fan) Wiring Instructions (with and without accessory light) WARNING: To comply with AS/NZS 60335.1 an Isolation switch must be fitted in series with the supply of this product. Fig. 5 Wire colours indicative only. Alternate colours marked with their function.
- Page 9 ® Installation & User Manual Installation Instructions (Assembling the fan) Fig. 8 Fig. 9 Fig. 10 Reverse Switch Direction fan will spin in FWD (Summer) mode when viewed from underneath Reverse Switch Direction fan will spin in REVERSE (Winter) mode when viewed from underneath 1.
- Page 10 ® Installation & User Manual Installation Instructions Assembling the fan (CCT LED light shown) This product uses real glass which can have sharp edges. Wear gloves and eye protection when replacing lamps or glass. Fig. 11 Fig. 12 LED light shown. Use same process for E27 light.
- Page 11 Warm White (3000K) to Cool White (4000K) to Daylight (6000K) at the flick of a light switch or a press of a button on a Hunter Pacific remote. CCT allows you to also set the lighting mood for the room to retain this colour each time the light is switched...
- Page 12 ® Installation & User Manual Installation Instructions (Attaching an extension rod - Hunter Pacific rods to be used ONLY) Fig. 16 ≥2.1m AU/NZ Fig. 17 Fig. 18 χ Ø6.5mm χ = Holes must be in centre of rod and drilled straight through.Crooked...
-
Page 13: Warranty Procedure
® Installation & User Manual Troubleshooting Tips for Installers - Fan Fan will not start • Check that the reversing switch is pushed into its Summer or Winter position. • Check wire connections in the wall switch and terminal blocks, ensure all wires are making proper contact. - Page 14 ® Installation & User Manual General Maintenance Changing Remote Batteries: - Batteries used in Handsets will weaken over time and should be replaced every 6 months. Batteries removed from the handset should be disposed of properly and kept out of reach of children. * Before maintenance ensure fan is switched off at the isolation switch or circuit breaker * Cleaning the Motor Housings: - Motor housings should be regularly cleaned to avoid build up of dust.
- Page 15 ® Installation & User Manual FORWARD (Summer) and REVERSE (Winter) Modes Explained Direction fan will spin in FWD Air is blown down, (Summer) mode when viewed from producing a cool breeze underneath FORWARD (Summer) Mode Ceiling fans are an environmentally smart choice to assist with cooling and warming your home. In FORWARD (Summer) mode your ceiling fan will spin to push air down the centre of the fan producing a cooling breeze.
-
Page 16: Quick Checklist
Ceiling fan is not installed using a solid-state wall controller. Neither leading nor lagging edge controllers will give satisfactory performance. Wall controllers must only be types approved for use by Hunter Pacific. The fan, fan light assembly and bracket are earthed. - Page 17 ® Installation & User Manual Fill out the details below and keep this manual. You will need to present your product information, installing electricians license number and proof of purchase for warranty claims. CUSTOMER DETAILS Customer Name: Installation Site Address: INSTALLING ELECTRICIAN DETAILS Electrical company and Electrician Name: License No:...
- Page 18 Attach receipt here. Attach electricians invoice here.
-
Page 19: Warranty Terms And Conditions
(which generally precedes hand over of the dwelling). Warranty periods are as follows: 3 years in-home warranty on all Hunter Pacific International AC and DC ceiling fans, including fans with fully integrated light combinations and DC remote controls and receivers. - Page 20 ® Warranty Procedure* For online warranty bookings visit: www.hunterpacific.com.au (24hours, 7 days) For technical advice call: 1300 360 280 (Monday to Friday from 9am to 5pm EST) * Warranty only available within Australia INTII-IUMv1.3...
