- Page 1 KVLAE00WT Microwave combi-oven User Manual...
-
Page 2: Table Of Contents
WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time. -
Page 3: Safety Information
Children should be supervised to ensure that they do not • play with the appliance and mobile devices with My Electrolux Kitchen . 3/44... -
Page 4: General Safety
SAFETY INFORMATION Keep all packaging away from children and dispose of it • appropriately. WARNING: Keep children and pets away from the appliance • when it operates or when it cools down. Accessible parts become hot during use. If the appliance has a child safety device, it should be •... - Page 5 SAFETY INFORMATION WARNING: If the door or door seals are damaged, the • appliance must not be operated until it has been repaired by a qualified person. WARNING: Only a qualified person can carry out any • service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy.
-
Page 6: Safety Instructions
SAFETY INSTRUCTIONS Do not use harsh abrasive cleaners or sharp metal scrapers • to clean the glass door since they can scratch the surface, which may result in shattering of the glass. Failure to maintain the appliance in a clean condition could •... -
Page 7: Electrical Connection
SAFETY INSTRUCTIONS Built in depth of the appliance 546 mm Depth with open door 882 mm Ventilation opening minimum size. Opening placed 560x20 mm on the bottom rear side Mains supply cable length. Cable is placed in the 1500 mm right corner of the back side Mounting screws 3.5x25 mm... -
Page 8: Care And Cleaning
SAFETY INSTRUCTIONS • Do not let the appliance stay unattended during operation. • Deactivate the appliance after each use. • Be careful when you open the appliance door while the appliance is in operation. Hot air can release. • Do not operate the appliance with wet hands or when it has contact with water. •... -
Page 9: Glassware Use
SAFETY INSTRUCTIONS • Clean the appliance with a moist soft cloth. Use only neutral detergents. Do not use abrasive products, abrasive cleaning pads, solvents or metal objects. • If you use an oven spray, follow the safety instructions on its packaging. 2.5 Glassware use Handling your glassware without an appropriate degree of care could result in breakage, chipping, cracking or severe scratching:... -
Page 10: Product Description
PRODUCT DESCRIPTION 3. PRODUCT DESCRIPTION 3.1 General overview Control panel Display Heating element Microwave generator Lamp Shelf support, removable Shelf positions 3.2 Accessories Wire shelf For cookware, cake tins, roasts. Baking tray For cakes and biscuits. Microwave bottom glass plate To prepare food in microwave mode. -
Page 11: Display
HOW TO TURN OVEN ON AND OFF ON / OFF Press and hold to turn the oven on and off. Display Shows the current settings of the oven. Press Move Press and hold Touch the surface with finger‐ Slide fingertip over the sur‐ Touch the surface for 3 sec‐... - Page 12 HOW TO TURN OVEN ON AND OFF The display with the maximum number of func‐ B C D tions set. A. Menu / Back Conventional cooking B. Wi-Fi (selected models only) C. Time of day D. Information E. Timer H G F E F.
-
Page 13: Before First Use
To connect the oven you need: • Wireless network with the Internet connection. • Mobile device connected to your wireless network. Step 1 Download the mobile app My Electrolux Kitchen and follow the instructions for the next steps. Step 2 Turn on the oven. -
Page 14: Software Licences
5.4 Software licences The software in this product contains components that are based on free and open source soft‐ ware. Electrolux gratefully acknowledges the contributions of the open software and robotics com‐ munities to the development project. To access the source code of these free and open source software components whose license conditions require publishing, and to see their full copyright information and applicable license terms, please visit: http://electrolux.opensoftwarerepository.com (folder GTM3). -
Page 15: How To Set: Microwave Heating Functions
DAILY USE Step 5 Press: Step 6 Press: - press to turn off the heating function. Step 7 Turn off the oven. Take a shortcut! 6.2 How to set: Microwave heating functions Step 1 Remove all accessories and turn on the oven. Step 2 Select a microwave heating function. -
Page 16: How To Use: Microwave Quick Start
DAILY USE MICROWAVE POWER MAXIMUM TIME More than 600 W 7 minutes If you open the door, the function stops. To start it again, press Take a shortcut! 6.3 How to use: Microwave quick start Step 1 Press and hold: . -
Page 17: Heating Functions
DAILY USE Step 5 Press: Take a shortcut! 6.5 Heating functions STANDARD Heating function Application To grill thin pieces of food and to toast bread. Grill To roast large meat joints or poultry with bones on one shelf position. To make gratins and to brown. - Page 18 DAILY USE Heating function Application To bake cakes with crispy bottom and to preserve food. Bottom Heat Heating up, cooking, power range: 100 - 1000 W Microwave SPECIALS Heating function Application To preserve vegetables (e.g., pickles). Preserving To dry sliced fruit, vegetables and mushrooms. Dehydrating To preheat plates for serving.
- Page 19 DAILY USE Heating function Application Use this function to prepare bread and bread rolls with a very good pro‐ fessional-like result in terms of crispiness, colour and crust gloss. Bread Baking MICROWAVE Heating function Application Defrosting meat, fish, cakes, power range: 100 - 200 W Defrost Heating up pre-prepared meals and delicate food, power range: 300 - 700 Reheat...
-
Page 20: Clock Functions
CLOCK FUNCTIONS Heating function Application To roast large pieces of meat on one level. To make gratins and to brown. The function with MW boost. Turbo Grilling + 7. CLOCK FUNCTIONS 7.1 Clock functions description Clock function Application Cooking time To set the length of cooking. -
Page 21: How To Set: Clock Functions
CLOCK FUNCTIONS 7.2 How to set: Clock functions How to set the clock Step 1 Press: Step 2 Press: Settings / Setup / Time of day. Step 3 Slide and press to set the clock. Press: or . How to set cooking time Step 1 Choose a heating function and set the temperature. - Page 22 CLOCK FUNCTIONS How to delay start and end of cooking Step 1 Press: Step 2 Slide and press to set the clock. Press: Take a shortcut! How to delay start without setting the end of cooking Step 1 Set the heating function and the temperature. Step 2 Press: Step 3...
-
Page 23: How To Use: Accessories
HOW TO USE: ACCESSORIES How to set extra time Step 3 Press: How to change timer settings Step 1 Choose the value on the slider or press the preferred time value to change the timer value. Step 2 Press: You can change the set time during cooking at any time. 8. -
Page 24: Additional Functions
ADDITIONAL FUNCTIONS Wire shelf, Baking tray: Push the tray between the guide bars of the shelf support and the wire shelf on the guide bars above. Microwave bottom glass plate: Use the microwave bottom glass plate only with microwave function. It is not suitable for combined microwave function (e.g. -
Page 25: Cooling Fan
ADDITIONAL FUNCTIONS (°C) 30 - 115 12.5 120 - 195 200 - 230 The Automatic switch-off does not work with the functions: Light, End time, Slow Cooking. 9.3 Cooling fan When the oven operates, the cooling fan turns on automatically to keep the surfaces of the oven cool. -
Page 26: How To Use: Mechanical Door Lock
ADDITIONAL FUNCTIONS 9.5 How to use: Mechanical door lock Step 1 To lock the door pull the door lock forward until it locks. Step 2 To unlock the door push the door lock back into the panel. Opening the locked door You can open the door when the door lock is locked. -
Page 27: Hints And Tips
HINTS AND TIPS 10. HINTS AND TIPS 10.1 Cooking recommendations The temperature and cooking times in the tables are guidelines only. They depend on the recipes and the quality and quantity of the ingredients used. Your oven may bake or roast differently to the oven you had before. The hints below show recom‐ mended settings for temperature, cooking time and shelf position for specific types of the food. - Page 28 HINTS AND TIPS Cookware / Material Ovenproof glass and porcelain with no metal components, e.g. heat-proof glass Non-ovenproof glass and porce‐ lain without any silver, gold, plat‐ inum or other metal decorations Glass and glass ceramic made of ovenproof / frost-proof materi‐ Ovenproof ceramic and earthen‐...
-
Page 29: Recommended Power Settings For Different Kinds Of Food
HINTS AND TIPS Cookware / Material Cookware for microwave use, e.g. crisp pan 10.4 Recommended power settings for different kinds of food The data in the table is for guidance only. 700 - 1000 W Searing at the start of the cook‐ Cooking vegetables Heating liquids ing process... - Page 30 HINTS AND TIPS Use wire shelf unless otherwise specified. MICROWAVE FUNCTION (kg) (min) Sponge cake 0.475 Bottom 7 - 9 Turn container around by 1/4, half‐ way through the cooking time. Meatloaf 25 - 32 Turn container around by 1/4, half‐ way through the cooking time.
-
Page 31: Care And Cleaning
CARE AND CLEANING 11. CARE AND CLEANING WARNING! Refer to Safety chapters. 11.1 Notes on cleaning Clean the front of the oven with a soft cloth with warm water and a mild deter‐ gent. Use a cleaning solution to clean metal surfaces. Cleaning Clean stains with a mild detergent. -
Page 32: How To Replace: Lamp
TROUBLESHOOTING Install the shelf supports in the opposite sequence. 11.3 How to replace: Lamp WARNING! Risk of electric shock. The lamp can be hot. Always hold the halogen lamp with a cloth to prevent grease residue from burning on the lamp. Before you replace the lamp: Step 1 Step 2... - Page 33 TROUBLESHOOTING The oven does not turn on or does not heat up Possible cause Remedy The clock is not set. Set the clock, for details refer to "Clock Func‐ tions" chapter, How to set: Clock functions. The door is not closed correctly. Fully close the door.
-
Page 34: How To Manage: Error Codes
TROUBLESHOOTING Problems with Wi-Fi signal Possible cause Remedy The wireless signal is disrupted by a micro‐ Turn off the microwave appliance. wave appliance placed near the oven. 12.2 How to manage: Error codes When the software error occurs, the display shows error message. In this section, you will find the list of the problems that you can handle on your own. -
Page 35: Technical Data
TECHNICAL DATA The necessary data for the service centre is on the rating plate. The rating plate is on the front frame of the oven cavity. Do not remove the rating plate from the oven cavity. We recommend that you write the data here: Model (MOD.) ......... -
Page 36: Menu Structure
MENU STRUCTURE 15. MENU STRUCTURE 15.1 Menu Press to open Menu. Choose dish Cleaning Options Menu item Application Favourites Lists the favourite settings. Assisted Cooking Lists automatic programmes. Options To set the oven configuration. Settings Connections To set the network configuration. Setup To set the oven configuration. -
Page 37: Submenu For: Connections
MENU STRUCTURE 15.3 Submenu for: Connections Submenu Description Wi-Fi To enable and disable: Wi-Fi. Remote operation To enable and disable remote control. Option visible only after you turn on: Wi-Fi. Network To check network status and the signal power of: Wi-Fi. Auto remote operation To start remote operation automatically after pressing START. -
Page 38: Submenu For: Service
IT'S EASY! 15.5 Submenu for: Service Submenu Description Demo mode Activation / deactivation code: 2468 Licence Information about licenses. Software version Information about software version. Reset all settings Restores factory settings. Reset all popups Restores all pop-ups to the original settings. 16. - Page 39 IT'S EASY! Start using the oven MW quick start Start Microwave Press: at any time with the default set‐ tings: 30 sec / 1000W. Start cooking Step 1 Step 2 Step 3 Step 4 Step 5 Step 6 - move the - press to go - press to finger on the...
-
Page 40: Take A Shortcut
