PVs 18 Sub
Enclosure
Operating
Manual
www.peavey.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the PVs 18 Sub and is the answer not in the manual?

Questions and answers

Related Manuals for Peavey PVs 18 Sub

Summary of Contents for Peavey PVs 18 Sub

  • Page 1 PVs 18 Sub Enclosure Operating Manual www.peavey.com...

  • Page 2: Fcc Caution

    FCC CAUTION: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
  • Page 3 A typical signal source for the line-level inputs of the Peavey PVs 18 Sub would be a sound reinforcement mixing console (mixer) or the output from a CD player, MP3 player or tape deck. The high-pass filtered signal from the PVs 18 Sub would...
  • Page 4 Specifications Frequency Response, 1 meter on-axis, swept-sine in half space Environment (-6 dB): 46 Hz – 180 Hz (Crossover Control Full CW) 46 Hz – 90 Hz (Crossover Control full CCW) Low Frequency range (-10 dB, half space): 43 Hz Power Amp Rating: 1,000 watts peak available power Sine wave Power: 500 watts into 4 ohms (Output duration is limiter controlled)
  • Page 5 Greater than 90 dB below rated power THD and IM: Typically less than 0.1 % Power requirements of Peavey PVs 18 Sub System: Nominal 160 Watts, 100-120 VAC 50-60 Hz (Domestic) 220-240 VAC 50-60 Hz (Export) Enclosure Materials & Finish: Black acrylic painted enclosure with 15 mm MDF, with a full-length, black powder coated perforated steel grille.

  • Page 6: Rear Panel

    If it does not match, then to change the voltage to the correct one, follow the steps outlined below. Changing the Voltage Range of the PVs 18 Sub First, make sure the PVs 18 Sub is disconnected from the power line, and that the power switch (4) is in the OFF position.
  • Page 7 This receptacle is for the IEC line cord (normally supplied with the correct pins and wiring for your lo- cale) that provides AC power to the unit. It is very important that you ensure the PVs 18 Sub has the proper AC line voltage supplied.
  • Page 8 REAR PANEL Rear Panel TOP – OPERATING CONTROLS, INPUTS & OUTPUTS INPUT (5) INPUT (5) The line-level input is of the medium impedance balanced type. The jack is a combo female XLR and 1/4” TRS The line-level input is of the medium impedance balanced type. The jack is a connector.

  • Page 9: Polarity Switch

    CAUTION! SETTING THIS CONTROL TOO LOW MAY ALLOW THE SATELLITE SPEAKER TO BE OVERLOADED BY DEEP BASS! Setting the control lower DOES NOT increase the deep bass output of the PVs 18 Sub, a middle range (9:30 to 2:30 clock face position) setting works best for most speakers.
  • Page 10 Placing A Satellite Speaker System On Top Of The PVs 18 Sub The PVs 18 Sub has a threaded pole mount built-in to the top of the unit, and this is designed to mate with an M20 threaded pole of approx. 32” in length or less. This pole is designed to be used with speaker systems less than 33”...
  • Page 11 The best option is a shielded balanced cable no lon- ger than necessary to reach the PVs 18 Sub. It is usually a good idea to leave some slack at the input to the PVs 18 Sub and also to tape the cables down or run them under a cable guard to avoid anyone tripping over them or pulling the PVs 18 Sub over when it is holding a speaker on top of its pole.
  • Page 12 If the satellite speaker is on top of a pole above the PVs 18 Sub, then a 6 foot cable will be plenty long. A 10, or 20 foot cable could also be used, but cables longer than that will only allow more interference pickup, and possi- bly start to lose high frequency information.
  • Page 13 Frequency & Polarity SUB MODEL> PVs 18 Top Box Model PA12 Frequencies corresponding to the Xover Frequency 135 Hz/110 Hz Crossover knob position: Polarity Either/Reverse Full CCW (7 o’ c lock) equals 90 Hz Top Box Level/Gain 3 o’ c lock Half-way between full CCW and PA15 straight up (9:30 o’...
  • Page 14 2:30 clock face position) setting works best for most speakers. If the powered full-range speakers are not set on top of the PVs 18 Sub on the pole, then the polarity switch set- tings may need to be different than what is provided here. The Crossover Frequency Control may need to be set to a slightly lower point in order for the Subwoofer and the satellites to sum well through the crossover region.

  • Page 15: Troubleshooting

    Hum or Buzz If the PVs 18 Sub is producing a hum or buzz, this can be AC outlet related. Try plugging the PVs 18 Sub into a different AC outlet. Sometimes, if a different circuit (breaker) is used for the mixer and for the PVs 18 Sub, it can cause hum problems.
  • Page 16 Touchup For a touch-up of any damage to the black painted finish of the PVs 18 Sub, you can use a black spray paint such as Peavey Commercial Sound, Black Touch-Up Paint, Peavey part number 00052110. Follow the directions on the can for safety and best results.
  • Page 17 Typical Hook-up Connections Loudspeaker System Specifications...
  • Page 18 Loudspeaker System Specifications Architectural and Engineering Specifications The powered loudspeaker system shall have a frequency response from 46 Hz to 180 Hz with the Crossover knob turned all the way CW, and from 46 Hz to 90 Hz with the Crossover knob turned all the way CCW, at the - 6 dB points. The peak SPL with inaudible distortion shall reach 127 dB with music as a source, when measured at a distance of 1M and driven to full output capacity.
  • Page 19 (67.9 cm) deep (including the casters), and the weight shall be 94.5 lbs. Power requirements shall be: 160 Watts nominal, 120 VAC, 50/60 Hz Domestic and 220-240 VAC, 50/60 Hz (Export). The loudspeaker system shall be called a Peavey® PVs 18 Sub.
  • Page 20 253.50 9.980 11.339 22.677 8.071 6.535 110.50 4.350 8.819 26.142 25.354 19.961 1.339 2.677 18.386...
  • Page 21 1.339 17.283...
  • Page 22 Warranty registration and information for U.S. customers available online at www.peavey.com/warranty or use the QR tag below Features and speci cations subject to change without notice. Peavey Electronics Corporation 5022 Hartley Peavey Drive Meridian, MS 39305 (601) 483-5365 FAX (601) 486-1278 Logo referenced in Directive 2002/96/EC Annex IV (OJ(L)37/38,13.02.03 and defined in EN 50419: 2005...
