OWNER'S MANUAL

Subwoofer Driver

Congratulations on your purchase of a JL Audio subwoofer component. Your JL Audio subwoofer is a

precision loudspeaker which has been engineered to produce the highest quality sub-bass performance

in your vehicle. Authorized JL Audio dealers have extensive technical information for many different

applications of your new speaker. They also have the knowledge, skills and tools to build a high-quality

enclosure that will maximize the performance of your speaker. We highly recommend that you have your

enclosure built by an authorized JL Audio dealer.

Inside you will find specifications and two recommended enclosures for your speaker; one is a sealed

enclosure, the other is a ported design. Both types of enclosures will give you excellent sound quality and

low-frequency extension. The sealed enclosure is a better choice if space is extremely tight, but the ported

enclosure will produce 3dB more output at the same power if you have the extra space to work with.

Do you have a question about the 12WX and is the answer not in the manual?

Page 1: Subwoofer Driver
OWNER’S MANUAL Subwoofer Driver Congratulations on your purchase of a JL Audio subwoofer component. Your JL Audio subwoofer is a precision loudspeaker which has been engineered to produce the highest quality sub-bass performance in your vehicle. Authorized JL Audio dealers have extensive technical information for many different applications of your new speaker.
Page 2 Nominal Diameter: Overall Diameter (A): Mounting Hole Diameter (B): Bolt Hole Circle (C): Magnet Diameter (D): Mounting Depth (E): Net Weight: Driver Displacement: JL AUDIO 12WX-4 U.S. PATENT: #6,219,431 SUBWOOFER 12.0 in. 305 mm 12.52 in. 318 mm 11.0625 in.
Page 3 We do not recommend the use of this subwoofer with a passive crossover (coil), as this type of device will adversely affect performance. JL AUDIO 12WX-4 All specifications are subject to change without notice. External Dimensions (Width x Height x Depth) (Hz) 16 in.
Page 4: Power Range For One Subwoofer Driver
JL Audio offers an extensive line of high-performance subwoofer drivers to fit a wide variety of enclosure and power applications. When designing systems with our drivers, it is very important to achieve a good power match between the subwoofer amplifier and the subwoofer driver's capabilities. The power levels listed in the above chart represent continuous (RMS) amplifier power per woofer and assume that the user will regularly make full use of that power without drastically overdriving the amplifier(s).

12wx-4
