DPAS-2100
Pro Attachment
This product contains chemicals known to the State of California
to cause cancer, birth defects, or other reproductive harm. Cancer
and Reproductive Harm www.P65Warnings.ca.gov
Read and understand all provided literature before use.
Failure to do so could result in serious injury.
99922205734
© 08/2021 ECHO Incorporated
Operator's
Manual
Series™

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pro Attachment DPAS-2100 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Echo Pro Attachment DPAS-2100 Series

Summary of Contents for Echo Pro Attachment DPAS-2100 Series

  • Page 1 This product contains chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. Cancer and Reproductive Harm www.P65Warnings.ca.gov Read and understand all provided literature before use. Failure to do so could result in serious injury. 99922205734 © 08/2021 ECHO Incorporated...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS DPAS-2100 TABLE OF CONTENTS Introduction......................3 Servicing Information......................3 Parts / Serial Number....................3 Service........................4 ECHO Consumer Product Support................4 Product Registration....................4 Additional Literature....................4 Packing List.......................4 Safety..........................5 Manual Safety Symbols and Important Information...........5 International Symbols....................6 General Power Tool Safety Warnings................7 Enviromentally Battery Disposal................13 Description........................14...

  • Page 3: Introduction

    SERVICING INFORMATION Parts / Serial Number Genuine ECHO Parts and Assemblies for your ECHO products are available only from an Authorized ECHO Dealer. When you do need to buy parts always have the Model Number and Serial Number of the unit with you. For future reference write them in the space provided below.

  • Page 4: Service

    Due to packaging restrictions, some assembly may be necessary. After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list to check for missing parts. Power Head With Upper Drive Shaft Assembly...

  • Page 5: Safety

    Note: This enclosed message provides tips for use, care and maintenance of the unit. CIRCLE AND SLASH SYMBOL This symbol means the specific action shown is prohibited. Ignoring these prohibitions can result in serious or fatal injury. 99922205734 © 08/2021 ECHO Incorporated...

  • Page 6: International Symbols

    Do not expose to rain protection. or in damp condition. Thrown objects can Keep all bystanders ricochet and result at least 50'/15m in personal injury or away. property damage. Note: Not all symbols will appear on your unit. 99922205734 © 08/2021 ECHO Incorporated...

  • Page 7: General Power Tool Safety Warnings

    • If operating a power tool in a damp location is unavoidable, use a RESIDUAL CURRENT DEVICE (RCD) protected supply. Use of an RCD reduces the risk of electric shock. 99922205734 © 08/2021 ECHO Incorporated...
  • Page 8 Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users. • Maintain power tools and accessories. Check for misalignment or 99922205734 © 08/2021 ECHO Incorporated...
  • Page 9 A charger that is suitable for one type of battery may create a risk of fire when used with another battery. • Use only with ECHO eFORCE™ 56V battery series. Use of any other batteries may create a risk of injury and fire. •...
  • Page 10 Don’t force the machine – It will do the job better and with less likelihood of a risk of injury at the rate for which it was designed. • Don’t overreach – Keep proper footing and balance at all times. 99922205734 © 08/2021 ECHO Incorporated...
  • Page 11 Do not modify or attempt to repair the machine or the battery (as applicable) except as indicated in the instructions for use and care. Use machines only with ECHO eFORCE™ 56V battery series. Use of any other batteries may create a risk of injury and fire.
  • Page 12 Use only with the nylon cutting line of 0.095" (2.4 mm) diameter and smaller. Do not use heavier lines than recommended by the manufacturer and line materials of other types – for example, metal wire, rope, and the like. SAVE THESE INSTRUCTIONS 99922205734 © 08/2021 ECHO Incorporated...

  • Page 13: Enviromentally Battery Disposal

    Battery charging temperature range 39°F (4°C) - 104°F (40°C) Charger operation temperature range 39°F (4°C) - 104°F (40°C) Battery storage temperature range 32°F (0°C) - 113°F (45°C) Battery discharging temperature range 32°F (0°C) - 113°F (45°C) 99922205734 © 08/2021 ECHO Incorporated...

  • Page 14: Description

    Locate the safety label(s) on your unit. Make sure the label(s) is legible and that you understand and follow the instructions on it. If a label cannot be read, a new one can be ordered from your ECHO dealer. Safety label is for example only. Your label my appear slightly different.
  • Page 15 For use only with ECHO eFORCE™ 56V battery series. See operator's manual for list of compatible model numbers. À utiliser uniquement avec l a série d e batteries ECHO eFORCE™ 56V. V oir le m anuel de l'opérateur pour la liste des numéros de modèle compatibles.

  • Page 16: Assembly

    • If the parts are damaged or missing, speak to the service center. Open the package. Read the documentation in the box. Remove all the unassembled parts from the box. Remove the machine from the box. Discard the box and package in compliance with local regulations. 99922205734 © 08/2021 ECHO Incorporated...

  • Page 17: Assemble The Shaft

    (C). Turn the lower shaft until the locator pin (B) locks into the positioning hole. Locater pin (B) should snap flush in coupler. Full engagement will prevent further shaft rotation. Tighten the clamping knob (A). 99922205734 © 08/2021 ECHO Incorporated...

  • Page 18: Attach The Support Handle

    Attach the support handle and lower clamp on the shaft. Put screw holes (E) on the support handle towards the rear handle (F). Set the support handle in the most comfortable in use position. Tighten the screws. 99922205734 © 08/2021 ECHO Incorporated...

  • Page 19: Install The Battery

    Push the battery into the battery compartment until the battery locks into place. When you hear a click, the battery is installed. Remove the Battery Push and hold the battery release button (G). Remove the battery from the machine. 99922205734 © 08/2021 ECHO Incorporated...

  • Page 20: Operation

    Push the speed switch (4) to the desired operating speed. Push the speed switch to position (H, tortoise) for low speed or position (I, rabbit) for high speed. Stop the Machine Release the trigger switch to stop the machine. 99922205734 © 08/2021 ECHO Incorporated...

  • Page 21: Adjust The Length Of The Cutting Line

    14 in. (35.6 cm) for greater runtime and 16 in. (40.6 cm)for a larger cutting area. Remove the battery. Remove the knife screws (J) and nuts (K) from the cut-off knife (11). Turn the cut-off knife180°. Tighten the knife screws and nuts. 99922205734 © 08/2021 ECHO Incorporated...

  • Page 22: Operation Tips

    • Do not force the trimmer head into uncut grass. Best cutting area • Wire and picket fences cause cutting Direction of rotation line wear and breakage. Stone and brick walls, curbs, and wood can wear the cutting line quickly. 99922205734 © 08/2021 ECHO Incorporated...

  • Page 23: Maintenance

    • Keep the trimmer head free of grass, leaves, or excessive grease. • Keep the air vents clean and free of debris to avoid overheating and damage to the motor or the battery. • Do not spray water onto the motor and electrical components. 99922205734 © 08/2021 ECHO Incorporated...

  • Page 24: Nylon Line Replacement

    Hold trimmer head while turning knob clockwise to wind line onto spool until about 13 cm (5 in.) of each line remains exposed. Trimmer head is now fully loaded and ready for operation. 99922205734 © 08/2021 ECHO Incorporated...

  • Page 25: Nylon Line Head Disassembly Instructions

    Note: For normal use, Speed-Feed® head disassembly is not necessary. However, if circumstances require disassembly, follow these instructions. Press top of locking tabs (N) on both sides of Speed-Feed® head to release cover (O) from eyelet carrier (P). Remove cover from eyelet carrier. 99922205734 © 08/2021 ECHO Incorporated...

  • Page 26: Troubleshooting

    1. Cool the battery until its func-tion is too hot. returns to normal. 2. Cool the machine for approximately 10 minutes. The battery is Install the battery again. disconnected from the tool. The battery is depleted. Charge the battery. 99922205734 © 08/2021 ECHO Incorporated...
  • Page 27 Heavy The length of line on Make sure that the line on both sides vibration. one side is longer than is equal in length. Advance the line. the other side. 99922205734 © 08/2021 ECHO Incorporated...

  • Page 28: Storage

    • If battery is stored for longer than six months, charge it to 100% capacity. Charger • Remove battery from charger. • Disconnect charger from power supply. • Store in a dry, dust-free place, out of the reach of children. 99922205734 © 08/2021 ECHO Incorporated...

  • Page 29: Specifications

    Cutting line diameter 2.4 mm (0.095 in.) Cutting path diameter 406 mm (16 in.) / 356 mm (14 in.) Feed Type Bump Feed Battery model ECHO eFORCE™ 56V battery series batteries Type Li-Ion Voltage 56 (rated 50.4) Charger type CCCV...

  • Page 30: Product Registration

    If you do not have access to the Internet, you can complete the form below and mail to: ECHO Incorporated, Product Registration, PO Box 1139, Lake Zurich, IL 60047. 99922205734 © 08/2021 ECHO Incorporated...
  • Page 31 DPAS-2100 PRODUCT REGISTRATION 99922205734 © 08/2021 ECHO Incorporated...

  • Page 32: Warranty

    ECHO dealer within the warranty period. The expense of delivering the product to the service center for warranty work and the expense of returning it back to the owner after repair or replacement will be paid by the owner. ECHO Incorporated’s, responsibility in respect to claims is limited to making the...
  • Page 33 The warranty does not extend to repairs made necessary by normal wear or by the use of parts or accessories which are either incompatible with the ECHO brand 56 Volt outdoor product or adversely affect its operation, performance, or durability.
  • Page 34 This warranty applies to all ECHO brand 56 Volt outdoor products manufactured by or for ECHO Incorporated, and sold in the United States and Canada. To locate your nearest authorized ECHO dealer, visit www.ECHO-usa.com or dial 1-800-432-ECHO (3246).
  • Page 35 DPAS-2100 NOTES NOTES 99922205734 © 08/2021 ECHO Incorporated...
  • Page 36 404PAS000001 - 404PAS999999 ECHO INCORPORATED 400 Oakwood Road Lake Zurich, IL 60047 www.echo-usa.com...
