Delayed Egress 57- 80 Series Exit Device General Description The SARGENT 57-Delayed Egress Exit Device is designed to work with an external electromagnetic lock in areas that require a delayed egress which alarms at the door when any attempt is made to violate the door. The 57- device can be tied into a fire alarm system. -
Page 5: Installation Instructions
Delayed Egress 57- 80 Series Exit Device Installation Instructions 1. Determine locations of components at the door 2. Mount all hardware and peripheral equipment according to manufacturer’s instructions NOTE: For exit device mechanical installation, refer to mechanical instruction sheets and templates included with product. - Page 6 Delayed Egress 57- 80 Series Exit Device Installation Instructions (Continued) Verify hand and bevel of door. Exit devices are always reverse bevel and are mounted on the inside of the door. Outside View Outside view On inside of door, exit devices are oriented as follows: 8800 LHRB shown 8800 RHRB shown Lights from top to bottom:...
- Page 7 Delayed Egress 57- 80 Series Exit Device Installation Instructions (Continued) ElectroLynx Connector System Notes: ® The system is designed to be installation friendly with Locking Mechanism pluggable connectors from the electric hinge through the door to the rail. The only wiring required is to the flying leads on the pigtail harness assembly on the frame side of the electric hinge.
- Page 8 Delayed Egress 57- 80 Series Exit Device Installation Instructions (Continued) Cylinder Installation 1. Prepare door according to template(s) and instructions supplied with exit device. 2. Verify cylinder (size varies; consult factory) is installed in rail insert with collar prior to installing exit device on door. Side View Top View of Insert To Remove/Replace Cylinder...
-
Page 9: Factory Default Settings
Delayed Egress 57- 80 Series Exit Device Factory Default Settings Default factory presets for the 57- are as follows: Status LEDs/Time Horn Armed (Delayed Egress) Solid GREEN Momentary Egress (Passage Delay) Flashing RED for (5) seconds Disarmed Solid RED Alarm Flashing RED &... -
Page 10: Delayed Egress 57- Dip Switch Settings
Delayed Egress 57- 80 Series Exit Device Delayed Egress 57- Dip Switch Settings S2-1 Nuisance Delay - (Field selectable 0 or 1 second) A one second nuisance delay can be enabled by setting Dip Switch (S2-1) to the “On” position. When nuisance delay is enabled, the unit will require the push bar to be depressed for more than one second in order to trigger an irreversible alarm condition. -
Page 11: Delayed Egress 57- Wiring
B. Installation Notes: 1. With new applications, a raceway harness with 8 & 4-pin connectors will be pre-installed inside the door by ASSA ABLOY door manufacturer when specified during the ordering process. Raceway harness kits are also available for retrofit applica- tions. - Page 12 Delayed Egress 57- 80 Series Exit Device Delayed Egress 57- Wiring (Continued) The following are the input and output connector designations. Harness Circuit Connector Board Input/ Harness Function Pin No.* Pin No. Output Wire Color J1-1 input +24VDC power N.C. N.O.
- Page 13 Delayed Egress 57- 80 Series Exit Device Delayed Egress 57- Wiring (Continued) Harness I/O Circuit Connector Board Function Pin No. Pin No. J1-1 24VDC Power Supply Input (+) This input may be tied to the normally closed contact of a building’s fire alarm system. If the fire alarm is activated, this contact will open, voiding the 15 second delay for egress.
-
Page 14: Exit Device Plug-In Connector Installation
Delayed Egress 57- 80 Series Exit Device Exit Device Plug-in Connector Installation Mounting bracket Screw locations 1” dia. hole in door Ring terminal (from harness) Insert bracket mounting screw through *ground ring terminal. Fasten mounting bracket with mounting bracket screws (ring terminal). *Ring terminal must be grounded as indicated. -
Page 15: System Wiring Examples
Delayed Egress 57- 80 Series Exit Device System Wiring Examples Sample Wiring #1 – Basic 57- Delayed Egress with Fire Alarm and Remote Reset During a fire alarm condition, the fire alarm contact opens which de-energizes the rail magnet and allows immediate egress. 24VDC 1.0AMP Regulated and Filtered Power Supply NOTE: This drawing shows the 110-120 VAC... - Page 16 Delayed Egress 57- 80 Series Exit Device System Wiring Examples (Continued) Sample Wiring #2 – 57- Exit Device with inside Keypad, Fire Alarm, Door Status and Remote Horn A valid code entry at the 4291 (Inside) keypad shunts the 57- exit device and allows egress for a time period programmable at the keypad.
- Page 17 Delayed Egress 57- 80 Series Exit Device System Wiring Examples (Continued) Sample Wiring #3 – 57- Exit Device with Fire Alarm, Keypads and Fail Safe ET During a fire alarm condition, the contact opens which de-energizes the rail electromagnet and allows immediate egress. A valid code entry at the 4291 (Inside) keypad shunts the 57- exit device and allows egress for a time period program- mable at this keypad.
-
Page 18: Operating Instructions
Delayed Egress 57- 80 Series Exit Device Operating Instructions Note: Power-up sequence is as follows: • Both insert LEDs illuminate "red" for 2 seconds while concurrently sounding buzzer for 500ms. • Both insert LEDs illuminate "green" for 2 seconds (no buzzer) •... - Page 19 Delayed Egress 57- 80 Series Exit Device Operating Instructions (Continued) Maintained Egress Mode 1. Rotate key fully clockwise (one click) and return key to center position (remove key). 2. Red (default) or Green LED will illuminate. See Dip Switch Settings section 5 for LED color settings.
- Page 20 Delayed Egress 57- 80 Series Exit Device Operating Instructions (Continued) Unit Tied Into A Fire Alarm System – Optional for Non-Labeled Devices 1. In case of a fire/emergency, the rail assembly will release the external electromagnet instantaneously, voiding the 15 second delay, allowing im- mediate egress and continuous immediate egress.
-
Page 21: Troubleshooting
Delayed Egress 57- 80 Series Exit Device Troubleshooting The tables below are provided to assist in the installation and troubleshooting of the 57- exit device. The following table lists the status and function of the (2) Green/Red LEDs located on the rail insert. Visible Insert LEDs Function Green (Default) or Red ON only... - Page 22 Delayed Egress 57- 80 Series Exit Device Troubleshooting (Continued) NOTES With Rim, Mortise and Vertical Rod Exit Devices: When jumper is missing or in wrong position, the Yellow Diagnostic LED turns ON. To locate (J5) jumper, remove Insert Assembly and Insert Assembly Plate: 1 2 3 Default factory setting for 57- shown...
- Page 23 Delayed Egress 57- 80 Series Exit Device Troubleshooting (Continued) Symptom / Failure *Refer to Diagnostic LED Table/Description and Minimum Requirements to Arm Rail sections. A. Rail won’t arm - (Armed LED won’t turn ON / Horn sounds immediately or after a delay) - When trying to arm, the rail goes into alarm immediately after momentary egress times out or after a short delay after the momentary egress times out.
