- Page 1 DUCATO AUTOMATIC SLIDING DOOR AND STEP SYSTEMS VELDO SSH...
- Page 2 CONTENTS • Main components of door system ……………………………… 3 - 9 • Advantages of door system ……………………………… 9 – 10 • Security systems of door system .……………………… 10 • Working way of door system ……………………..……10 • Assembling of door system ………………………………...
- Page 3 MAIN COMPONENTS OF DOOR SYSTEM PART DESCRIPTION FRONT FOOT GROUP MOTOR (ENGINE) GROUP MIDDLE FOOR GROUP BELT TURNBUCKLE GROUP REAR FOOT VELDO SSH...
- Page 4 MAIN COMPONENTS OF DOOR SYSTEM Control Unit Electrical Wiring: It provide to movement and signal control of automatic door. In-door electrical wiring: It provides to spent less power of automatic door for bring from the open position to the closed position Door drive mechanism: it is the part that contains the system units and is placed under the...
- Page 5 MAIN COMPONENTS OF DOOR SYSTEM Unbolting System: It is the mechanism that automatically opens the door without changing the original lock mechanism of the vehicle door. Motor(Engine) Group Lock Puller System: The automatic door ensures that less force is exerted to bring it from the open position to the closed position. Cable Sheaves: Cable sheaves absorb the belt looseness that occurs during sudden changes in direction of the automatic door.
- Page 6 MAIN COMPONENTS OF DOOR SYSTEM Encoder: It allows automatic position information of the door to be transferred to the control unit and distance adjustment can be made. RF receiver cable Bottom engine grasp cable Main system engine socket VELDO SSH...
- Page 7 MAIN COMPONENTS OF DOOR SYSTEM ( - ) ve ( + ) points of main system wiring Note: This has to be connected to the vehicle's battery. Main wiring cable points 1. km (speed ) signal cable 2. Ignition open signal cable 3.
- Page 8 MAIN COMPONENTS OF DOOR SYSTEM The way the RF receiver module is installed. Inner door wiring cable points Switch signal and motor Unbolting engine Door handle switch Security wick lock signal points will be cable cable cable connected here VELDO SSH...
- Page 9 SECURITY SYSTEMS OF VELDO DOOR Security wick: The automatic door allows the door to open automatically in case of any obstruction or jamming. Overcurrent control: It is a security system that is switched on when the security wick is disabled. User controlled security system: When the door is automatically closed, the door automatically opens when the user commands from the front panel button or the door opening lever.
- Page 10 SECURITY SYSTEMS OF VELDO DOOR Speed-controlled safety system: When the vehicle is moving when the vehicle speed is above a certain limit (5 km / h) and the door is not open and the door is open; it automatically closes when a certain speed limit (5km / h) is exceeded.
- Page 11 ASSEMBLING OF AUTOMATIC DOOR Driver and passenger seats are first removed and removed from the car in order to mount Veldo automatic sliding doors. The batteries under the driver's seat of the vehicle are removed as shown in the figure. Ø...
- Page 12 ASSEMBLING OF AUTOMATIC DOOR The wiring is put under the vehicle through the holes drilled. The section on the top of the vehicle is as seen in the figure. Images of the wiring under the vehicle are like the way. VELDO SSH...
- Page 13 ASSEMBLING OF AUTOMATIC DOOR The security wick is installed according to the form of the door. Security wick the cable pass hole is drilled from the spot marked in the figure. The security wick cable is connected to the inner door installation color to color.
- Page 14 ASSEMBLING OF AUTOMATIC DOOR Cutting process is done with air saw. It is then cut from drawn places. The vehicle's original lock counterpart is dismantled. Centering is done according to the original equivalent for the lock puller mechanism. It is marked with the corresponding sheet as shown in the figure.
- Page 15 ASSEMBLING OF AUTOMATIC DOOR It is drilled from corners with Ø 10 mm drill. The cut is done as in the figure. The cut is done as in the figure. The lock puller mechanism is installed as shown in the picture.
- Page 16 ASSEMBLING OF AUTOMATIC DOOR The lock puller mechanism is installed as shown in the picture. (from inside) The front mast connection is connected according to the diagram. The door on/off button cable plugs in the main system installation are attached to the button. The panel is then assembled into place.
- Page 17 ASSEMBLING OF AUTOMATIC DOOR 40 mm and 60 mm marks are made for the rear foot connection by reference to the region seen in the figure. Ø 30 mm punch hole is drilled from the marked area. Rear foot assembly is done. VELDO SSH...
- Page 18 ASSEMBLING OF AUTOMATIC DOOR The parts seen in the figure are cut with the help of an air saw. The cut section is as seen in the figure. The parts seen in the figure are cut with the help of an air saw.
- Page 19 ASSEMBLING OF AUTOMATIC DOOR The area shown in the figure is cut for the main chassis assembly. The cut section is as seen in the figure. VELDO SSH...
- Page 20 ASSEMBLING OF AUTOMATIC DOOR The original foot of the vehicle is removed for the belt connection process. The belt mounting bracket is connected to the original foot of the vehicle as shown in the figure. VELDO SSH...
- Page 21 ASSEMBLING OF AUTOMATIC DOOR The belt crossing route is as in the figure. VELDO SSH...
- Page 22 ASSEMBLING OF AUTOMATIC DOOR The locking mechanism is as shown in the figure. VELDO SSH...
- Page 23 ASSEMBLING OF AUTOMATIC DOOR The wire removed from the rear lock is assembled as seen in the figure. VELDO SSH...
- Page 24 ASSEMBLING OF AUTOMATIC DOOR The assembly process of the locking mechanism to the vehicle's cover is as follows. VELDO SSH...
- Page 25 ASSEMBLING OF AUTOMATIC DOOR The door switch is installed in the area seen in the figure. The installation process is performed under 2 mm of the original insulation material on the B pillar of the vehicle The red cable for the ignition signal connects to the blue white cable in the vehicle installation.
- Page 26 WORKING AND CONTROL OF AUTOMATIC DOOR SYSTEM Initial working status: Control unit is connect to facilities and when the insurance is installed and the first energy is supplied; -The remote control of the car is activated by pressing the central locking buttons, then the central locking button is activated and the remote control is activated.
- Page 27 WORKING AND CONTROL OF AUTOMATIC DOOR SYSTEM General Working: When the door is closed - The door starts closing the engine door, during which time the buzzer alerts you that the door is closing in short tones. - When the door is completely the buzzer finishes the hoisting operation, - The lock pull mechanism pulls the door in.
- Page 28 WORKING AND CONTROL OF AUTOMATIC DOOR SYSTEM Door operation settings: It is the part where the operation settings of the control unit are made. These settings are made when the ignition is switched off. These settings are; 2- Doorhandle Activation: - Press and hold the panel button to enter the learning mode.
- Page 29 WORKING AND CONTROL OF AUTOMATIC DOOR SYSTEM 3- When the door is closed: If one of the following events occurs, the door stops and reopens. - If a jamming door in the closing direction detects excessive current, - If there is a impact in the safety wick while the door is closed - If the door is pulled out while the door is closed - If the panel button is pressed while the door is closed - If the control is pressed while the door is closed...
- Page 30 ATTENDANCE OF DOOR SYSTEM • Automatic Automatic door and step systems must be maintained once a year. • System General Checks are done. • The system belt changes. • The unlocking pattern changes. NOTE: Uncared products will be evaluated outside the scope of the Guarantee. TERMS OF GUARANTEE OF DOOR SYSTEM The terms of the warranty are part of the purchase agreement between the Veldo authorized dealer and the customer.
- Page 31 DISCLAIMER OF WARRANTY TERMS • Maintenance and repair of the automatic door / step must be carried out on time, regularly, by the appropriate technical knowledge and competent services and in accordance with the periodic maintenance and repair procedures. • Failure to follow the instructions in the user manual.
