- Page 1 ® Classic Royal Reading Writing Center RC005 Assembly Guide RC005_2021_A Rc005 - Version A - Released October 28, 2021 - Copernicus Educational Products Inc.
- Page 2 ® Classic Royal Reading Writing Center RC005 Lifetime Frame Warranty 5 year Whiteboard Replacement Program Rc005 - Version A - Released October 28, 2021 - Copernicus Educational Products Inc.
- Page 3 This product is intended for indoor comercial use only. To reduce the risk of fire or electric Indoor Use shock, do not expose this product to rain or moisture. The internal components are not Only sealed from the environment. Rc005 - Version A - Released October 28, 2021 - Copernicus Educational Products Inc.
-
Page 4: Additional Tools Required
5 lbs Weight Limit 2” Twin Wheel Open Tub Locking Caster 10 lbs Weight Limit ‘S’ Chart Hook PTP2 Chart Loop Hooks Open Tub Small Tub Divided Tub Rc005 - Version A - Released October 28, 2021 - Copernicus Educational Products Inc. - Page 5 Fasten Front Frame Assembly & Rear Frame Together Note: Note: Placing the unit on its side will make Ensure bottom channels are facing in this assembly easier. towards each other. Rc005 - Version A - Released October 28, 2021 - Copernicus Educational Products Inc.
- Page 6 Install Bottom Racks into Frame Channels Note: Install Bottom Racks before fastening screws. Do not over tighten or Tub Racks will not slide. Repeat on the other side with remaining fasteners. Rc005 - Version A - Released October 28, 2021 - Copernicus Educational Products Inc.
- Page 7 Pass Shelf Through Back Frame Install Book Shelf onto Assembled Frame 2 Hook Shelf onto Front and Back Frames Rc005 - Version A - Released October 28, 2021 - Copernicus Educational Products Inc.
- Page 8 (Not to Scale) Chart Loop Hooks ‘S’ Chart Hook Attach ‘S’ Chart Hooks & Chart Loop Hooks Tip: place empty hardware bags over the frame to prevent scratching. Rc005 - Version A - Released October 28, 2021 - Copernicus Educational Products Inc.
- Page 9 Contents - Box 2 PTP1 Small Tub 5 lbs Weight Limit Install Tubs into Tub Frames Open Tub 10 lbs Weight Limit PTP2 Open Tub Small Tub Divided Tub Rc005 - Version A - Released October 28, 2021 - Copernicus Educational Products Inc.
