Summary of Contents for Schill Aerosonic Travel
- Page 1 ® aerosonic Inhaling with ultrasonic Instructions for Use...
-
Page 2: Overview Of Unit
Overview of unit Air filter cover Mask for children and adults Air filter Tubing Dome Nebuliser cover Mouthpiece Mask adapter Medicine cup Fan wheel Cone insert Rechargeable Water level display battery pack (optional) Oscillator (ceramic) Operating and Vehicle power recharging display supply unit ON/OFF switch (optional) -
Page 3: Table Of Contents
Table of Contents Overview of unit Introduction Important safety information Starting the unit Cleaning Fault diagnosis Rechargeable battery pack Spare parts, optional User sets Technical data Guarantee Service information... - Page 4 Dear Patient The aerosonic® travel is a powerful ultrasonic neb- uliser for prophylactic and therapeutic deep inhala- tion. This unit has been designed and developed so that it reflects the latest medical research find- ings. The aerosonic® travel can be used both at home and whilst travelling thanks to its flexible power supply options –...
-
Page 5: Introduction
Introduction If used with care your nebuliser will provide you 1 base unit with many years of reliable service. 1 cone insert 1 fan wheel This nebuliser requires either distilled water or tap water (as transfer water) and the medicine that has 1 nebuliser cover with air filter been prescribed by your physician to generate a and air filter cover... -
Page 6: Important Safety Information
Important safety information Use of the aerosonic® travel • If the unit falls into water then do not touch it Please observe the general safety precautions given under any circumstances. Pull the plug out of the below when using the aerosonic® travel inhalation wall socket immediately. - Page 7 • The unit should not be left unattended if it is con • Change the water in the water reservoir after nected to an electrical power supply. every use. • Do not tilt or shake the unit during operation. • Do not use the unit whilst driving a vehicle or any similar activity.
-
Page 8: Starting The Unit
Filling of the water reservoir Fig. 1 Fig. 2 Fig. 3 1. Remove the nebuliser cover 2. Remove the medicine cup 3. Check that the cone insert is by squeezing the 2 short sides (if applicable). sitting securely in the recess and lifting it upwards. - Page 9 Caution Fill the water reservoir with water only. Other fluids could damage or even destroy the ceramic oscillator. Ensure that the correct quantity of water is used. Fig. 4 Fig. 5 4. Fill the water reservoir with 5. Fill the water reservoir up distilled water* or tap water to the indicated level (in the (as transfer water).
- Page 10 Filling of the medicine cup Fig. 1 Fig. 2 Fig. 3 1. Place the medicine cup on 2. Fill the medicine cup direct- 3. Replace the nebuliser cover the water reservoir. Ensure ly with the prescribed quantity on the unit. that you use only one medi- of medicine.
- Page 11 Use of the mouthpiece or mask Fig. 1 Fig. 2 Fig. 3 Place the mouthpiece on the Place the adapter for the mask For inhalation, for instance dome of the nebuliser cover. on the dome of the nebuliser whilst lying down, use the cover and then plug the noz- extension tube together with zle of the mask into the adap-...
- Page 12 Connection of the power supply unit Fig. 1 Fig. 2 Fig. 3 2. Then plug the power supply 1. First plug the 12 V plug of unit into a mains socket. the power supply unit into the socket on the underside of the nebuliser (Fig.
- Page 13 Switching on the unit Adjustment of aerosol flow rate • Ensure that the water reser • The ultrasonic nebuliser has voir and medicine cup 3 aerosol flow settings: are correctly filled, that the Maximum, medium and mini- LOW BATTERY mouthpiece (mask) is cor- mum.
- Page 14 Start of treatment 1. Place your lips around the Note mouthpiece or put on the mask. The nebuliser will start to oper- ate at a lower output and the 2. Breathe in calmly at a uniform output will increase after a few rate.
- Page 15 End of treatment LOW BATTERY POWER Fig. 1 Fig. 2 Fig. 3 1. Once treatment is complete 2. Pull the plug out of the mains 3. Allow the unit to cool down press the ON/OFF button (Power) socket, then remove the 12 V fully, for a minimum of 20 –...
- Page 16 Fig. 4 Fig. 5 Fig. 6 4. Remove the nebuliser cover. 5. Carefully remove the medi- 6. Empty the water reservoir aft- cine cup and shake out the er each inhalation or 1x daily medicine left in it. after the last inhalation proce- dure.
-
Page 17: Cleaning
Cleaning and disinfection Note • Never immerse the unit, • It is recommended that the power supply unit, recharge- unit and accessories be clean- able battery pack or vehicle ed and disinfected after every power cable in water as it inhalation procedure and aft- could damage them irrevers- er it has been stored for a... - Page 18 In the home In medical practices All parts that come into contact with the patient or All movable parts that come into contact with the the aerosol (the mouthpiece, mask, mask adapter, patient or the aerosol must be replaced before the medicine cup, nebuliser cover, air filter and its unit is used by a different patient.
-
Page 19: Fault Diagnosis
Investigation of faults If the unit does not operate as it should then please check the following: Condition Corrective action The unit does not respond when the ON/OFF Check that the power supply unit is correctly plug- button is pressed. ged into the nebuliser and that the power cable is correctly plugged into the nebuliser socket. -
Page 20: Rechargeable Battery Pack
Re-charging of the battery pack • A fully-charged battery pack Rechargeable battery pack Note the following when using will supply the unit with enough The aerosonic® travel ultraso- the rechargeable battery pack power for 20 – 30 minutes of nic nebuliser can be operated •... - Page 21 Use of the rechargeable battery pack Fig. 1 Fig. 2 Fig. 3 1. Place the nebuliser carefully 3. Start the nebuliser as descri- 4. After using the unit shake out on the right-hand side of the bed above. the remaining medicine and wa- surface of the charged battery If the operating lamp of the ter before removing the battery...
-
Page 22: Spare Parts, Optional
Spare parts, user sets and optional parts The user sets, spare parts and optional parts are available from your local dealer or may be ordered by post. Spare parts Travelset 1 15 medicine cups Mouthpiece Order No. 82120 Nebuliser cover with air filter, Fan wheel with air filter cover 6 air filters 5 medicine cups... -
Page 23: Technical Data
-18 °C - 45 °C Dimensions: 8 x 4.9 x 8.7 cm Technical Data for the nebuliser with rechargeable Weight: approx. 240 g battery pack aerosonic travel (82000) The right to make changes without prior notice is For data see above reserved. -
Page 24: Guarantee
Only original accessories may be used with the unit. with sufficient postage and proof of purchase. The Otto Schill Medizintechnik will not assume any lia- unit is guaranteed for a period of 24 months from bility if these conditions are not adhered to. - Page 25 Otto Schill GmbH & Co. KG Medizintechnik Auwiesen 12 D-07330 Probstzella Phone +49 (0) 3 67 35 / 4 63 - 0 +49 (0) 3 67 35 / 4 63 - 44 info@multisonic.de www.multisonic.de...
