6. TROUBLE IN H. V SYNC
TROUBLE IN
HOR. OR VER. SYNC
YES
CHECK
CONNECTOR S701
(PIN6,7), SIGNAL
YES
CHECK
U701(PIN 39,40)
H/V SYNC.
SIGNAL
YES
CHECK
U701(PIN 32,33)
H/V SYNC.
SIGNAL
YES
CHECK
U701(PIN 1, 2)
YES
TROUBLE IN
U301
