Summary of Contents for Cobalt Aquatics C-VUE 18
- Page 2 C-VUE STAND PARTS LIST Door Hinges Camlocks Camlock Screws ½” Hinge Screws 1” Cabinet Foot Screws Plastic Cabinet Feet Stand Panels Special Note on installing Camlock screws When installing camlock screws into pre-installed nylon adapters. Be sure not to over tighten, or cams will not engage correctly.
- Page 3 C-VUE 18, 26, 45 ASSEMBLY INSTRUCTIONS Step 1- Attaching Right Side Panel to Back Panel [requires two (2) Camlocks and two (2) Camlock Screws] • Insert two (2) Camlock Screws into the Right Side Panel. • Be sure to screw in just until the threads are not visible, no more.
- Page 4 Step 2- Attach Left Side Panel to Back Panel [requires two (2) Camlocks and two (2) Camlock Screws] • Insert two (2) Camlock Screws into the Left Side Panel. • Be sure to screw in just until the threads are not visible, no more. •...
- Page 5 Step 4- Attaching Front Panel to Stand [requires two (2) Camlocks and two (2) Camlock Screws] • Insert two (2) Camlock Screws into the Front Panel. • Be sure to screw in just until the threads are not visible, no more. •Insert one(1) Camlocks into the Right Side Panel •Insert one (1) Camlocks into the Left...
- Page 6 Step 6- Insert Shelf into stand [requires four (4) shelf holders] • Insert four (4) shelf holders into pre-drilled holes. • Press in firmly, you may need to tap lightly with hammer. • Place shelf onto shelf holders Step 7- Attaching Hinges [requires four (4) ½”...
- Page 7 Step 8- Installing the door [requires four (4) ½” screws] • Mount Door to the Hinge on the Side Panel using ½” screws. • Line up hinges with pilot holes and secure with 1/2” screws. • Be sure to make screws with tight snug fit, but do not over tighten.
- Page 8 C-VUE 40, 50 ASSEMBLY INSTRUCTIONS Step 1- Attaching Right Side Panel to Back Panel [requires two (2) Camlocks and two (2) Camlock Screws] • Insert two (2) Camlock Screws into the Right Side Panel. • Be sure to screw in just until the threads are not visible, no more. •...
- Page 9 Step 2- Attach Left Side Panel to Back Panel [requires two (2) Camlocks and two (2) Camlock Screws] • Insert two (2) Camlock Screws into the Left Side Panel. • Be sure to screw in just until the threads are not visible, no more. •...
- Page 10 Step 4- Attaching Front Panel to Stand [requires two (2) Camlocks and two (2) Camlock Screws] • Insert two (2) Camlock Screws into the Front Panel. • Be sure to screw in just until the threads are not visible, no more. •Insert one(1) Camlocks into the Right Side Panel •Insert one (1) Camlocks into the...
- Page 11 Step 6- Insert Shelf into stand [requires four (4) shelf holders] • Insert four (4) shelf holders into pre-drilled holes. • Press in firmly, you may need to tap lightly with hammer. • Place shelf onto shelf holders Step 7-Installing middle support beam.
- Page 12 Step 8- Attaching Hinges [requires eight (8) ½” screws] • Attach the Hinges to the Left Side Panel and Right Side Panel • Line up hinges with pilot holes and secure with 1/2” screws. • Be sure to make screws with tight snug fit, but do not over tighten. Step 9- Installing the doors [requires eight (8) ½”...
- Page 13 Step 10- Installing the cabinet feet [requires four [4] cabinet feet and four (4) 1” cabinet feet screws] • Align feet with pilot holes • Secure with 1” screws. • Be sure to make screws with tight snug fit, but do not over tighten.
-
Page 14: Warranty
WARRANTY Cobalt International, Inc will warrant this product to be free of manufacturer defects for a period of ninety (90) days. Co- balt will repair or replace, at its option, any C-VUE aquarium stand or component which is deemed defective in workman- ship or materials. -
Page 15: Warranty Registration
WARRANTY REGISTRATION Please Fill Out Completely and Return within 14 days from date of purchase. (Please Print) Customer Name: _____________________________________ Address: ____________________________________________ City: ________________________________________________ State: ___________________Zip:_________________________ Phone#:______________________________________________ Email:____________________________________________ Yes I would like to receive emails on Cobalt News New Products, Sales, Rebates No I do not want receive emails on Cobalt News Date of Purchase: ______________ Model_______________ Dealer Purchased From: ________________________________... - Page 16 Distributed By: Cobalt International 624 Wilkerson Rd Rock Hill, South Carolina 29730 www.cobaltaquatics.com 803-591-9500 • info1@cobaltinternational.com...
