Summary of Contents for Sonoff DIY iFan04
- Page 1 iFan04 User manual V1.0 Wi-Fi Smart Ceiling Fan with Light Controller FCC Warning 中 文 ----------1-6 English----------7-13 ----------...
- Page 2 Shenzhen Sonoff Technologies Co., Ltd. 中⽂ 产品介绍 433MHz RF天线 Wi-Fi天线 配对按钮/灯开关 设备重量＜1kg， 建议安装⾼度＜2⽶。 产品特点 本设备为⼀款⻛扇灯控制器， ⻛扇灯通过与本设备相连可在易微联App端分别控制灯、 ⻛扇的开关， ⻛速控制、 设 时开/关和 给您的 ⼀ 制等等。 远程控制 智能定时/延时 语⾳控制 分享功能 风速控制 433MHz遥控控制 创建群组 智能场景 同步状态 局域⽹控制 使⽤说明 1.断电 设备安装、 故障维修请由专业资质电⼯操作。 切勿在设备通电时进⾏接线操作， 以免发⽣触电危险！...
- Page 3 Shenzhen Sonoff Technologies Co., Ltd. 中⽂ 2.接线 100-240V AC L端输⼊前需接保护装置 （如： 保险丝或空⽓开关） 确保线接⼊⽆误。 3.下载 “易微联” App 易 微 联 eWeLink Android™ & iOS...
- Page 4 Shenzhen Sonoff Technologies Co., Ltd. 中⽂ 4.上电 电 ， 设备⾸次使⽤， 默认进 快 配⽹模式。 设备蜂鸣器呈两短⼀⻓响声。 三分钟内没有进⾏配⽹， 设备将退出快速模式。 如需再次进⼊， ⻓按设备配对按钮5秒或将设备连续 上电3次 （开-关-开-关-开） 直到设备蜂鸣器呈两短⼀⻓响声即可。 5.添加设备 点击 “+” ， 选择 “ 快速添加” ， 再根据App提⽰进⾏操作。 兼容配⽹模式 如使⽤快速添加模式配⽹失败， 请使⽤ “兼容配⽹模式” 进⾏配对。 ⻓按设备配对按钮5秒直到设备蜂鸣器呈 两短⼀⻓ 响声， 松开。 再次⻓按配对按钮5秒直到设备 蜂鸣呈...
- Page 5 Shenzhen Sonoff Technologies Co., Ltd. 中⽂ 设备与RM433R2遥控器的学习⽅法： <RM433R2 在设备上电后的5秒内⻓按遥控器任意按键⾄设备蜂鸣器 “滴” ⼀声， 即全部按键学习成功， 如5秒内未进⾏ 下⼀步操作， 请重新上电。 设备最多配对10遥控器， 超过10个则会⾃动覆盖第⼀个学习的遥控器， 以此类推。 产品参数 型号 iFan04-L, iFan04-H 输⼊ 100-240V AC 50/60Hz 5A iFan04-L： 灯具:100-240VAC50/60Hz3AMax 钨丝灯:360W/120VMaxLED:150W/120VMax ⻛扇:100-240VAC50/60Hz2AMax 输 iFan04-H： 灯具:100-240VAC50/60Hz3AMax 钨丝灯:690W/230VMaxLED:300W/230VMax ⻛扇:100-240VAC50/60Hz2AMax 433MHz Wi-Fi IEEE 802.11 b/g/n 2.4GHz App⽀持系统...
- Page 6 Shenzhen Sonoff Technologies Co., Ltd. 中⽂ 更换设备⽹络 在eWeLinkApp设备设置界⾯选择 “ WiFi设 ” 进⾏更换。 设备设置 iFan04 创建群组 ⼩程序控制 局域⽹控制 设备设置 通电反应关闭 WiFi设置 WiFi设置 设备信息 设备ID 1000a3517f 低 中 ⾼ MAC地址 60:01:94:AC:CC:FD 固件名称 PSF-BFB-GL 删除设备 ⻛扇开关 定时 延时 灯开关 重新配对 ⽅法1： ⻓按设备...
- Page 7 Shenzhen Sonoff Technologies Co., Ltd. 中⽂ 遥控器参数 型号 RM433R2 433MHz 遥控器尺⼨ 87x45x12mm 86x86x15mm(可选) 遥控器底座尺⼨ 供电 3V纽扣电池x1 （ 电池型号:CR2450） 外壳材料 PCV0 遥控器介绍 iFan04⽀持使⽤RM433R2遥控器进⾏控制， 学习成功后， 即可根据下图按键说明控制设备， 此功能属于本地 近程⽆线遥控与Wi-Fi⽹络⽆关。 灯开/关按键 静⾳按键 三档⻛速 ⼆档⻛速 ⼀档⻛速 关闭⻛扇 RF清码按键 （⻓按5s） Wi-Fi配对按键 （⻓按5s） RF清码⽅法： ⻓按RF清码按键5秒⾄设备蜂鸣器发出 “滴滴” 两声， 即完成清码。 出⼚默认设备的蜂鸣器会在开/关⻛扇、...
-
Page 8: Product Introduction
Shenzhen Sonoff Technologies Co., Ltd. English Product Introduction 433MHz RF antenna Wi-Fi antenna Pairing button/On/Off (light) The device weight is less than 1 kg. The installation height of less than 2 m is recommended. Features This is a Wi-Fi smart controller for the ceiling fan with light that allows you to remotely turn on/off the fan and light separately, adjust the fan speed, schedule it on/off and share it with your families to control together, etc. - Page 9 Shenzhen Sonoff Technologies Co., Ltd. English 2. Wiring instruction 100-240V AC Please install protection devices before connecting the live wire. (e.g. fuses or air switches). Make sure all wires are connected correctly. 3. Download the eWeLink APP eWeLink eWeLink Android™ & iOS...
- Page 10 Shenzhen Sonoff Technologies Co., Ltd. English 4.Power on After powering on, the device will enter the quick pairing mode during the first use, then the device makes two short beeps and one long beep. The device will exit the quick pairing mode if not be paired within 3mins. If you want to enter the quick pairing mode again, press and hold the pairing button for 5s, or keep turning the device on and off...
- Page 11 Shenzhen Sonoff Technologies Co., Ltd. English Remove the Battery Insulation Sheet After factory setting, RM433R2 remote controller is bound to iFan04 by default. Simply remove the battery insulation sheet to use. If the device connected to iFan04 is not controlled by the remote controller, try to learn the remote controller again.
-
Page 12: Specifications
Shenzhen Sonoff Technologies Co., Ltd. English Specifications Model iFan04-L, iFan04-H Input 100-240V AC 50/60Hz 5A iFan04-L： Light:100-240V AC 50/60Hz 3AMax Tungsten lamp:360W/120V Max LED: 150W/120V Max Fan:100-240V AC 50/60Hz 2A Max Output iFan04-H： Light:100-240V AC 50/60Hz 3AMax Tungsten lamp:690W/230VMax LED: 300W/230VMax Fan:100-240V AC 50/60Hz 2AMax 433MHz Wi-Fi... -
Page 13: Factory Reset
Shenzhen Sonoff Technologies Co., Ltd. English Re-establish Pairing Method 1: Press the "pairing button" on the device for 5s until the buzzer makes two short beeps and one long beep then release, which means the device has entered quick pairing mode, so it can be added in the eWeLink App again. -
Page 14: Remote Controller Specifications
Shenzhen Sonoff Technologies Co., Ltd. English Remote Controller Specifications Model RM433R2 433MHz Remote controller size 87x45x12mm 86x86x15mm (not included) Remote controller base size Power supply 3V button cell x 1 (Battery model: CR2450) PC V0 Material Remote Controller Introduction iFan04 can be controlled by RM433R2 remote controller. After learning is successful, you can control the device connected with iFan04 according to the button instruction below. -
Page 15: Fcc Warning
Shenzhen Sonoff Technologies Co., Ltd. FCC Warning FCC Warning Changes or modifications not expressly approved by the party responsible for compliance could avoid the user ’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 16 Hereby, Shenzhen Sonoff Technologies Co., Ltd. declares that the radio equipment type iFan04-L, iFan04-H is in compliance with Directive 2014/53/EU.The full text of the EU declaration of conformity is available at the following internet address: https://sonoff.tech/usermanuals Shenzhen Sonoff Technologies Co., Ltd. 1001, BLDG8, Lianhua Industrial Park, shenzhen, GD, China ZIP code: 518000 Website: sonoff.tech...
