Summary of Contents for Poolspa VICTORIA SPA
- Page 1 SPA Bath VICTORIA SPA ø178 Installation and user manual...
- Page 2 Dear customers, Thank you for trusting us and buying our product! The POOL-SPA company, one of the leaders in the European hydromassage bath market, has been offering its world class quality products for many years. The endurance, reliability and safety of our baths has always been of greatest importance to us;...
-
Page 3: Table Of Contents
2.5. Preparation of water and electrical connections ............. 18 2.6. Grounding cable connection ................... 19 2.7. Main connection ......................19 2.8. Maintenance of acrylic elements ..................20 2.9. Electrical scheme of the Victoria SPA ................21 WARRANTY FOR SPA ......................23 TECHNICAL PRODUCT SHEET ................... 27... -
Page 4: Introduction
Introduction In order to be able to fully use all functions of a SPA Victoria, please read all sections of this manual. You should remember that despite the therapeutic and relaxing function of a hydromassage treat- ment, seriously ill persons or persons suffering from heart disorder diseases or high blood pressure need to consider special conditions created inside the SPA baths and consult their physician before using such baths. -
Page 5: Part 1 - Instruction Manual
PART 1 – INSTRUCTION MANUAL Congratulations on buying a portable Victoria SPA! SPA Victoria allows you to appreciate the ad- vantages of hydromassage for four people sitting places) both outside a building and in- side a large bathroom. The bath is equipped with an ozonator which makes it easier to keep the water clean and is very effective in beauty treatment. -
Page 6: Technical Specifi Cation
1.1. Technical specifi cations 1765 1580 SPA Victoria dimensions: - width: 1765 mm, - depth: 765 mm, - height: 870 mm +/- 20 mm. Capacity: 800 l. Weight: ~ 275 kg (without water). Material and construction: Sanitary acrylic strengthened by laminated polyester, insulated with polyurethane foam, on an aluminium frame. -
Page 7: Conservation Substances
• All these functions are not available until ICE symbol disappered. Is possible to take a bath but use of any pump. • If electronic system detects temperature below 15 C degrees of the surrounding air then ANTI- FROST systems starts after 15 minutes from last pump switch off. •... -
Page 8: Ventilation
Such problem does not exist in case of a bath operating in open air conditions. 1.5. Main functions accessible from the electronic control panel. Victoria SPA control panel 1.5.1. Switching on/off the pump The hydromassage pump can be switched on/off directly from the electronic control panel. After... - Page 9 1.5.4. Setting the right time The controller is fi tted with the RTC system (real-time clock), which works permanently even after disconnecting the main power. The RTC system makes it easier to use the SPA, since the controller memorize the clock, fi ltration and the economy mode setting even after the main power is off. It is not necessary to set the fi...
- Page 10 water pump work at the highest speed, while the heater is on. When one pump works in a low gear along with the water ozonator and the electric heater. The duration of fi ltration depends on the time setting. Filtration mode is indicated by this special icon on the display.
- Page 11 temperature is 42° C. To return to a normal mode of setting the water temperature, press the down arrow button a few times until the normal temperature, ranging from 15 to 40° C, appears on the display. 1.5.10. “Stand-By” function This function blocks access to all devices connected to the controller for 60 minutes.
-
Page 12: Massage
1.6. Hydromassage There are water and air massage systems installed in the bath. 1.6.1. Hydromassage (whirl bath) Hydromassage is the pressure on defi ned muscles exerting by stream of water or stream of air and water. Water or air and water at high pressure bring out from regulated jets and hit on body surface. -
Page 13: Water Ozonizing
1.6.2. Airmassage (pearl bath) In airmassage, heated air is pumped into water by a blower. Millions of bubbles come from the perforated bath bottom, actively massaging the body. The bubbles stimulate the circulatory system, relax muscles and joints. Their activity may be compared to a normal hand massage. It soothes the nervous and respiratory system, and improves metabolism. - Page 14 Underwater lighting must not be used when there is no water in the bath!!! Underwater lighting must be switched off before water is drained from the bath !!! SPA Victoria Filtration System: The system is composed of the following elements: •...
-
Page 15: Disinfection
1.9. Disinfection Disinfection process in the SPA Victoria, is ozone based. Ozone is used during fi ltration. Additionally, the bath is equipped with a START SET of measurement and treatment agents for pH correction and disinfection with active oxygen (more information in part 1.11). 1.10. - Page 16 It is a natural phenomenon that in SPA baths the pH value of water tends to increase. However, very rarely the pH value decrease can be observed. It is then recommended to use Dinoplus granules, which can be ordered through the sho- wroom of the Victoria SPA manufacturer.
-
Page 17: Part 2 - Installation Manual
2.2. Site preparation The portable Victoria SPA may be operated both indoors and outdoors. The site for the bath should comply with the following conditions: a) the proper area and the proper transportation routes (in case of closed premises), b) 230V electrical supply and ensured effi... -
Page 18: Assembly/Disassembly Of The Wooden Housing (Additional Option)
2.4. Assembly/disassembly of the wooden housing (additional option) Fig. 2-2. Assembly/disassembly scheme for the wooden housing for SPA Victoria Disassembly and assembly of the housing is based on unscrewing (using a T 15 size star spanner) of two screws located at the ends of the timber elements (in their lower section) and moving them aside. -
Page 19: Grounding Cable Connection
The fi xed piping system includes release valves lo- cated near the skimmer-fi lter; at the outlets of which fi xed or removable hose connection with the sewage system should be made (See Fig. 2-5). Fig. 2-5. Sewage connection for SPA Victoria 2.6. -
Page 20: Maintenance Of Acrylic Elements
Water connection 1/2” for water filling Sewage connection 50 mm 230 V (3 x 2,5 mm ) electric connection with 5 kW efficiency, protected by a circuit breaker (30 mA cut-off value) Fig. 2-8. Location of SPA Victoria connections 2.8. Maintenance of acrylic elements Only mild fl... -
Page 21: Electrical Scheme Of The Victoria Spa
2.9. Electrical scheme for SPA Victoria - standard version 20AT 20AT L/HI N PE L/LO N PE L/HI N PE L/LO N PE N PE PUMP 1 PUMP 1 PUMP 2 PUMP 2 INPUT VOLTAGE... - Page 22 Electrical scheme for SPA Victoria - option 20AT 20AT L/HI N PE L/LO N PE L/HI N PE L/LO N PE N PE PUMP 1 PUMP 1 PUMP 2 PUMP 2 INPUT VOLTAGE...
-
Page 23: Warranty For Spa
Before using the equipment, read carefully through the instructions included with the Spa. POOL-SPA Sp. z o.o. ul. D bskiego 35, 72-300 Gryfi ce tel. biuro: +48 91 38 777 00 tel. serwis: +48 91 38 777 48 fax. +48 91 38 777 01 e-mail: info@poolspa.pl, www.poolspa.pl... - Page 24 Notes ....................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
- Page 25 Notes ....................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
- Page 26 Notes ....................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
-
Page 27: Technical Product Sheet
TECHNICAL PRODUCT SHEET MODEL, FITTINGS Victoria SPA FACTORY NUMBER DATE OF PRODUCTION AND TESTING NOMINAL POWER REQUIREMENTS ~5 kW FUSING REQUIREMENTS 25 A VOLTAGE / FREQUENCY 230V/50 Hz THERMAL PROTECTION QUALITY CONTROL... - Page 28 72-300 Gryfi ce tel. +48 91 38 777 00 fax +48 91 38 777 01 e-mail: info@poolspa.pl www.poolspa.pl POOL-SPA company has the policy of constant improvement of products and reserves the right to introduce changes to the specifi cation and colours without a prior notifi ca- tion.
