Imation M-Class Specification Sheet

+
A Whole New Class of Solid State Drives
Imation's new M-Class SSDs will change the way you look at computing.
Lightning fast boot times, applications that load in a fraction of the time, the
power to run graphics, design applications and games the way they were
meant to run are all possible with Imation M-Class SSDs!
Operating on multilevel cell (MLC) technology, the Imation M-Class SSD
combines performance with a sleek, elegant design unseen in the market
today. Although it emulates a hard disk drive (HDD), it has no motors or
moving parts, providing faster and more reliable data storage than traditional
HDDs with reduced heat and noise generation. The energy-efficient controller
technology combined with the innovative, rugged design positions the Imation
M-Class SSD as an ideal solution for progressive end users, custom developers
and IT managers.

Features and Benefits

+ FAST
The shear speed of the Imation M-Class SSD enables users to boot
up faster, find applications and files more quickly and run more
efficiently than hard disk drives.
+ ENERGY EFFICIENT
Imation SSDs run on about 1/2 the power needed to run an HDD;
use of less power generates less heat and subsequently requires less
energy to keep cool.
+ RUGGED
Designed to withstand wear and tear, Imation M-Class SSDs feature
a rugged design for extreme endurance and performance in harsh
environments.

Product Description

+ PRIMARY
Ordering UPC Description
27509 2.5" M-Class SSD, 32GB
27510 2.5" M-Class SSD, 64GB
2 75 1 1 2.5" M-Class SSD, 128GB
27512 3.5" M-Class SSD, 32GB
27513 3.5" M-Class SSD, 64GB
27514 3.5" M-Class SSD, 128GB
© Imation Corp 2009 Imation Enterprises Corp 1 Imation Way Oakdale, MN 55128-3414 Ph: 651.704.4000 Fax: 651.537.4675 www.imation.com
Imation and the Imation logo are trademarks of Imation Corp. All other trademarks are the property of their respective owners. 52-0003-8230-0 (5/09)
M-CLASS SOLID
UPC Size (LxWxH)
051122275098 7.44" x 5.88" x 2.63"
051122275104 7.44" x 5.88" x 2.63"
051122275111 7.44" x 5.88" x 2.63"
051122275128 7.44" x 5.88" x 2.63"
051122275135 7.44" x 5.88" x 2.63"
051122275142 7.44" x 5.88" x 2.63"
STATE DRIVE
2.5" and 3.5" MLC-based Solid State Drives

Technical Specifications

CAPACITIES
32GB, 64GB, 128GB
FORM FACTOR
2.5" or 3.5"
INTERFACE
SATA II – 3.0 Gbps
TRANSMISSION MODES
PIO mode (0-4), DMA mode (0-2),
Ultra DMA mode (0-6)
INPUT VOLTAGE
5VCC+/-10%
OPERATING TEMPERATURE
0-70°C (32-158°F)
CASE FINISH
Burnished Carbon
SEQUENTIAL READ
150MB/s
SEQUENTIAL WRITE
90MB/s
SEQUENTIAL WRITE IOPS
9,500
SEQUENTIAL READ IOPS
71,000
RANDOM WRITE IOPS
380
RANDOM READ IOPS
6,000
WARRANTY
2 years limited
+ MASTER CARTON
Weight UPC
0.5lbs 50051122275093
0.5lbs 50051122275109
0.5lbs 50051122275116
0.5lbs 50051122275123
0.5lbs 50051122275130
0.5lbs 50051122275147
Introducing
Size (LxWxH) Weight Units
12.25" x 7.0" x 8.5" 3.5lbs 4
12.25" x 7.0" x 8.5" 3.5lbs 4
12.25" x 7.0" x 8.5" 3.5lbs 4
12.25" x 7.0" x 8.5" 3.5lbs 4
12.25" x 7.0" x 8.5" 3.5lbs 4
12.25" x 7.0" x 8.5" 3.5lbs 4
